TOF-5 / TOF-6 AUTOMATIC SPRAY GUN
TOF-5R / TOF-6R (round pattern) AUTOMATIC SPRAY GUN
Before use, adjustment or maintenance, it is important to read
GB
this instruction manual very carefully. This manual must be
stored in a safe place for any future reference that may be necessary.
This ANEST IWATA spray guns kit complies to ATEX regulations 94/9/EC
Protection level: II 2 G X Suitable for using in Zones 1 and 2.
X marking: Any static electricity discharge from the spray gun is to be diverted to the ground via the conductive air hose as stipulated.
IMPORTANT
This automatic spray gun should be operated only by an adequately trained operator for safe use and maintenance of the equip-
ment. Any misuse or handling other than those indicated in this Instruction Manual is not covered by guarantee.
ANEST IWATA disclaims all responsibility for any accident or damage caused by failure observing the operational and safety pro-
cedures as from this manual. In the interest of user friendliness, this manual contains information in a brief and concise form.
For any additional information you may require regarding the automatic spray gun operations, or if any missing parts or any dam-
age during transportation is found, or details of training courses, please contact your nearest ANEST IWATA Company (see last
cover page).
Be sure to observe warnings and cautions in this instruction manual.
If not, it can cause paint ejection and serious bodily injury by drawing organic solvent.
Be sure to observe following marked items which are especially important.
WARNING Indicates a potentially hazardous situation which, if not avoided, may result in serious injury or loss of life.
CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or pro-
perty damage.
IMPORTANT Indicates notes which we ask you to observe. The safety precautions in this instruction manual are the mini-
mum necessary conditions. Follow national and local regulations regarding fire prevention, electricity and
safety as well as your own company regulations.
IMPORTANT SPECIFICATIONS
Max. Pressure: 6.8 bar (98 PSI)
Noise Level (LAeqT) 69.4 dB(A)*
Air connection: G 1/8"
Fluid connection: G 1/8"
*Measuring point: 1m backwards from gun, 1,6 m height
TECHNICAL SPECIFICATIONS
Model Nozzle orifice Air cap Fluid output Air consumption
ø mm (in) set ml/min
TOF-6 / TOF-5 / TOF-6R / TOF-5R Pressure feed
TOF-5/5R - 05
0.5 (0.02) 05
TOF-6/6R - 05
TOF-5/5R - 10
1.0 (0.04) 10
TOF-6/6R - 10
TOF-5/5R - 13
1.3 (0.05)
13
TOF-6/6R - 13
TOF-5/5R - 20
20
2.0 (0.08)
TOF-6/6R - 20
Measuring conditions: Tested with water at 3.0 bar.
* Spray distance 300 mm
Manufactured by: ANEST IWATA Corporation 3176,Shinyoshida-cho, Kohoku-ku, Yokohama, 223-8501 Japan
Instruction Manual
Max. Temperature:
Atmosphere 5 ~ 40 °C
Air and fluid 5 ~ 43 °C
*Pattern width Mass
l/min (cfm) mm (in) g (lbs)
Fan Round Fan Round
60 60 (2.1) 40 (1.4) 200 (7.9) 50 (2.0)
250 80 (2.8) 50 (1.8) 250 (9.8) 70 (2.8)
350
(0.77)
80 (3.1)
360 100 (3.5) 55 (1.9) 350 (13.8)
90 (3.5)
600 140 (4.9) 85 (3.0) 400 (15.7)
