Storage - Dell Vostro 15 3510 Service Manual

Table 8. Integrated Devices (continued)
Options
Enable Audio
USB Configuration

Storage

This section provides storage details and settings.
Table 9. Storage
Options
SATA Operation
SATA Operation
Storage Interface
Port Enablement
SMART Reporting
Enable SMART Reporting
Drive Information
Enable MediaCard
Description
This section contains a toggle switch that allows the user to
enable or disable the audio on the computer. It also allows the
user to:
● Enable Microphone (Enabled by default.)
● Enable Internal Speakers (Enabled by default.)
This section helps the user to make changes to the USB
settings on the computer. The options available are as follows:
● Enable USB Boot Support - Allows the system to boot
from an external USB device (Enabled by default.)
● Enable External USB Ports - Allows the user to enable
or disable the USB ports on the computer (Enabled by
default)
Description
This section allows the user to select the operating mode
of the integrated SATA hard drive controller. The following
options are available:
● Disabled - SATA controllers are disabled.
● AHCI - SATA is configured in AHCI mode.
● RAID On - SATA is setup to support RAID (Intel Rapid
Storage Technology). (Selected by default)
This section allows the user to enable or disable the onboard
drives on the computer. The following options is available:
● M.2 PCIe SSD-0 (ON by default)
● SATA-0 (ON by default)
This section contains a toggle switch that allows the user
to enable or disable the S.M.A.R.T(Self-Monitoring, Analysis,
and Reporting Technology) option on the system (OFF by
default).
This section provides information about the connected and
active drives on the computer. The following options are
available:
● M.2 PCIe SSD-0
○ Type
○ Device
This section allows the user to switch all media cards On/
Off, or enable/disable the media card in read-state only. The
options are as follows:
● Secure Digital (SD) Card (Enabled by default).
System setup 91
