- Page 1 Vostro 3525 Setup and Specifications Regulatory Model: P112F Regulatory Type: P112F005/P112F006 February 2022 Rev. A00...
- Page 2 A WARNING indicates a potential for property damage, personal injury, or death. © 2022 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 3: Table Of Contents
Contents Chapter 1: Set up your Vostro 3525....................4 Chapter 2: Views of Vostro 3525....................6 Right....................................... 6 Left......................................6 Top......................................8 Front....................................... 9 Bottom....................................10 Service Tag..................................10 Battery charge and status light ............................11 Chapter 3: Specifications of Vostro 3525..................12 Dimensions and weight..............................12 Processor..................................... -
Page 4: Chapter 1: Set Up Your Vostro 3525
000131676 at www.dell.com/support. For Windows: Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: ● Connect to a network for Windows updates. NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when prompted. - Page 5 SupportAssist proactively checks the health of your system's hardware and software. When an issue is detected, the necessary system state information is sent to Dell to begin troubleshooting. SupportAssist is preinstalled on most of the Dell devices running Windows operating system.
-
Page 6: Chapter 2: Views Of Vostro 3525
Views of Vostro 3525 Right 1. SD-card slot Reads from and writes to the SD card. The computer supports the following card types: ● Secure Digital (SD) ● Secure Digital High Capacity (SDHC) ● Secure Digital Extended Capacity (SDXC) 2. USB 2.0 port Connect devices such as external storage devices and printers. - Page 7 Connect devices such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps. 5. USB 3.2 Gen 1 Type-C port (optional for Barcelo/Lucienne) Connect devices such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps. Views of Vostro 3525...
-
Page 8: Top
If the power button has a fingerprint reader, place your finger on the power button to log in. NOTE: You can customize power-button behavior in Windows. For more information, see Me and My Dell at www.dell.com/support/manuals. 2. Touchpad Move your finger on the touchpad to move the mouse pointer. -
Page 9: Front
Slide the privacy shutter to cover the camera lens and protect your privacy when the camera is not in use. 4. Camera-status light Turns on when the camera is in use. 5. Right microphone Provides digital sound input for audio recording and voice calls. 6. LCD panel Provides visual output to the user. Views of Vostro 3525... -
Page 10: Bottom
To prevent the computer from overheating, ensure that the air vents are not blocked when the computer is running. Service Tag The service tag is a unique alphanumeric identifier that allows Dell service technicians to identify the hardware components in your computer and access warranty information. Views of Vostro 3525... -
Page 11: Battery Charge And Status Light
Battery charge and status light The following table lists the battery charge and status light behavior of your Vostro 3525. Table 2. Battery charge and status light behavior Power Source LED Behavior System Power State Battery Charge Level AC Adapter... -
Page 12: Chapter 3: Specifications Of Vostro 3525
Specifications of Vostro 3525 Dimensions and weight The following table lists the height, width, depth, and weight of your Vostro 3525. Table 3. Dimensions and weight Description Plastic Aluminum Height: Front height 15.52 mm (0.61 in.) 16.96 mm (0.66 in.) Rear height 17.50 mm (0.69 in.) -
Page 13: Chipset
Chipset The following table lists the details of the chipset supported by your Vostro 3525 Table 5. Chipset Description Option one Option two Processors AMD Athlon series AMD Ryzen series Chipset Integrated Integrated DRAM bus width Two channels, 64-bit Two channels, 64-bit... -
Page 14: External Ports
To learn more about the features of different types of M.2 cards, search in the Knowledge Base Resource at www.dell.com/support. Ethernet The following table lists the wired Ethernet Local Area Network (LAN) specifications of your Vostro 3525. Table 9. Ethernet specifications Description Values... -
Page 15: Wireless Module
Wireless module The following table lists the Wireless Local Area Network (WLAN) modules supported on your Vostro 3525. Table 10. Wireless module specifications Description Option one Option two Model number Realtek RTL8821CE MediaTek MT7921 Transfer rate 433 Mbps 1200 Mbps Frequency bands supported 2.40 GHz/5 GHz... -
Page 16: Storage
Up to 2 TB M.2 2280 solid-state drive, QLC PCIe NVMe 3x4 Up to 1 TB Media-card reader The following table lists the media cards supported by your Vostro 3525. Table 13. Media-card reader specifications Description Values Media-card type One SD card Media-cards supported ●... -
Page 17: Camera
NOTE: You can define the primary behavior of the function keys (F1–F12) changing Function Key Behavior in BIOS setup program. Camera The following table lists the camera specifications of your Vostro 3525. Table 15. Camera specifications Description Plastic Aluminum Number of cameras... -
Page 18: Power Adapter
For more information about touchpad gestures available on Windows, see the Microsoft knowledge base article 4027871 at support.microsoft.com. Power adapter The following table lists the power adapter specifications of your Vostro 3525. Table 17. Power adapter specifications Description Values Type... -
Page 19: Display
CAUTION: Dell recommends that you charge the battery regularly for optimal power consumption. If your battery charge is completely depleted, connect the power adapter, turn on your computer, and then restart your computer to reduce the power consumption. -
Page 20: Fingerprint Reader (Optional)
4.55 W Anti-glare vs glossy finish Anti-glare Anti-glare Touch options Fingerprint reader (optional) The following table lists the specifications of the optional fingerprint-reader of your Vostro 3525. Table 20. Fingerprint reader specifications Description Values Fingerprint-reader sensor technology Capacitive Fingerprint-reader sensor resolution... -
Page 21: Gpu-Integrated
GPU—Integrated The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your Vostro 3525. Table 21. GPU—Integrated Controller Memory size Processor AMD Radeon Graphics Shared system memory ● AMD Athlon Silver ● AMD Ryzen 3 ●... - Page 22 Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components. * Measured using a random vibration spectrum that simulates user environment. † Measured using a 2 ms half-sine pulse. Specifications of Vostro 3525...
-
Page 23: Chapter 4: Comfortview
ComfortView mode can be enabled and configured using the Dell CinemaColor application. ComfortView mode complies with TÜV Rheinland's requirement for low blue light displays. Low blue light: Dell ComfortView software technology reduces harmful blue light emissions to make extended screen time easy on your eyes. -
Page 24: Chapter 5: Keyboard Shortcuts Of Vostro 3525
Keyboard shortcuts of Vostro 3525 NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations. Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. - Page 25 Fn + R System request Fn + Ctrl Open application menu Fn + Esc Toggle Fn-key lock Fn + PgUp Page up Fn + PgDn Page down Fn + Home Home Fn + End Keyboard shortcuts of Vostro 3525...
-
Page 26: Chapter 6: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 27. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com My Dell app...
