Summary of Contents for Frico SH17521
- Page 1 Original instructions Bench heater SH ..8 ..10 ..12 ..14 ..16 ..18...
- Page 2 Regulation also does not apply to installations in vehicles, offshore or outdoors. Many of Frico's products can be used as both local space heaters (as defined in (EU) 2015/1188) and for technical heating purposes. It is up to the installer responsible for the installation to assess whether the Ecodesign Regulation is applicable or not.
-
Page 3: Minimum Distances
Bench heater SH 41,5 [mm] SH17521/SH17531 SH25021/SH25031 1000 SH37521/SH37531 1500 Minimum distances Minimum distances Minimiavstånd Minsteavstand Distances minimales Mindestabstand Минимальные расстояния при установке... - Page 4 Bench heater SH Bench heater SH (IP21) Item Type Output Voltage Amperage LxH*xW Weight number [mm] [kg] 10201 SH17521 230V~ 700x110x200 10202 SH17531 400V~ 700x110x200 10203 SH25021 230V~ 1000x110x200 10204 SH25031 400V~ 1000x110x200 SH37521 10206 230V~ 1500x110x200 10207 SH37531 400V~...
- Page 5 Bench heater SH Wiring diagrams Internal wiring diagrams 230V ~ 400V ~ SHxxx21 SHxxx31 NL1L2L3 NL1L2L3 Control by thermostat 230V~ 230V TAP16R °C TAP16R 230V SHxxx21 SHxxx21 SHxxx21 NL1L2L3 NL1L2L3 NL1L2L3...
- Page 6 Bench heater SH Control by thermostat 400V~ 230V TAP16R °C TAP16R 230V A1 2 SHxxx31 SHxxx31 SHxxx31 NL1L2L3 NL1L2L3 NL1L2L3...
- Page 7 Bench heater SH Frico control 230V~ Sensor Sensor FCPOBH FCBB G 1 2 A1 A2 B1 B2 FCRTX FCOTX Sensor G 1 2 BUS 1 BUS 2 L2 L2 PE PE L FCCH +12V +12V 230V~ Max 16A SHxxx21 SHxxx21...
-
Page 8: Electrical Installation
Bench heater SH Installation and operating instructions General Instructions Control Read these instructions carefully prior to When using this product as a local space installation and use. Keep this manual for heater according to Ecodesign Regulation future reference. (EU) 2015/1188, it must be supplemented with The product may only be used as set out in one of the following approved controls. - Page 9 Bench heater SH Safety • For all installations of electrically heated products a residual current circuit breaker 300 mA for fire protection should be used. • The unit must not be fully or partially covered as overheating can result in a fire risk! •...
- Page 10 Main offi ce Frico AB Tel: +46 31 336 86 00 Industrivägen 41 SE-433 61 Sävedalen mailbox@frico.se Sweden www.frico.net For latest updated information and information about your local contact: www.frico.se...
