DESi utopic R User Manual

Wireless motorized cylinder
Hide thumbs Also See for utopic R:
Table of Contents

Advertisement

Quick Links

Download this manual
Wireless Motorized Cylinder
USER MANUAL
update 11.02.2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the utopic R and is the answer not in the manual?

Questions and answers

Related Manuals for DESi utopic R

Summary of Contents for DESi utopic R

  • Page 1 Wireless Motorized Cylinder USER MANUAL update 11.02.2021...

  • Page 2: General Information And Warnings

    GENERAL INFORMATION and WARNINGS - Before using your motorized cylinder, Locking way (right or left handed door) and Number of turns should be adjusted properly. Otherwise, the device will not work in the correct way and maybe broken. - For emergency conditions, we recommend you to put the keys in an accessible place (like car, bag etc.) - If there is any problem with the door or the locking mechanism, first of all, those problems have to be solved.

  • Page 3: Features Of The Device

    Your motorized cylinder is equipped with rechargeable Lithium Ion batteries. 2. BOX CONTENT According to DESi labratory tests, with a usage of 10 operations per day on a 2 turns lock, battery life of (May vary according to model) motorized cylinder is as follows:...
  • Page 4 3. PARTS OF DEVICE and INSTALLATION 1.STEP Remove Control Cylinder existing Buttons cylinder. microUSB 2. STEP Charging Port Install motorized cylinder and Handle for tighten Manual Operation the screw...
  • Page 5 In some security doors, even if you remove cylinder screw, you cannot remove cylinder due to cramped installation of cylinder defender. Follow the instructions below, for that kind of situations: - Untighten the screws of the cylinder defender (don’t remove the screws) - Remove cylinder screw and take out the old cylinder.

  • Page 6: Mobile Application

    MOBILE APPLICATION In this section, you can find details about usage of Mobile Application If you enroll your smart phone as first controller, it will be master controller of your motorized cylinder. Before you use your motorized cylinder, you should adjust it properly according to the lock which motorized cylinder will work together.
  • Page 7 For how to video, please click on the link https://www.youtube.com/watch?v=kjLH2HGA7k8 - Search “Desi Utopic” on application stores. Download, install and run the application. - Choose language and set a password or skip it. - Press and hold two buttons on motorized cylinder until you hear a long warning tone and then release buttons. After that you will hear a short warning tone.

  • Page 8: Application Settings

    5.2. APPLICATION SETTINGS If you touch the menu button in the top right corner when it is not connected to motorized cylinder, you will reach settings menu of application. Related menu items are as follows: PASSWORD: You can disable, enable or change the password of application.

  • Page 9: Device Info Tab

    5.3. MOTORIZED CYLINDER SETTINGS / ADMINISTRATION MENU If you touch the menu button in the top right corner when the application is connected to motorized cylinder as master controller, you will reach to settings menu of connected motorized cylinder. You can change settings of your motorized cylinder and perform administrative activities via this menu.
  • Page 10 5.3.2. KNOB SETTINGS TAB Menu In this tab, there are following menu items: Button SETUP WIZARD: You can reach quick setup settings and easily follow steps. DELAYED LOCKING: If this feature is enabled, the device will lock the door 10 seconds after the locking button on the device is pressed. When you are going out, if you press the locking button on the device and than close the door, it will automatically lock your door in 10 seconds.

  • Page 11: Advanced Settings Page

    5.3.2.a. ADVANCED SETTINGS PAGE BUZZER OF KNOB: You can enable / disable activation sounds coming from motorized cylinder. INVERT LOCKING WAY: You should set locking way of the device in accordance with your door’s locking way. ADJUST NUMBER OF TURNS: You should set how long the device will rotate to lock the door in accordance with your door’s lock.

  • Page 12: Users Tab

    5.3.3. USERS TAB In this tab, you can manage controllers of motorized cylinder including auto-locking module, home automation interface, keypad, fingerprint reader etc. If you touch “Controllers” line, you can edit enrolled controllers. If you touch any user, you reach dedicated controller page which you can edit name or delete the controller one by one. You can enroll new controller if you touch Menu “Enroll New Controller”...
  • Page 13 For how to video, please click on the link https://youtu.be/7iKNoLvnvN8?t=30 For fingerprint reader; For keypad; For remote controller; For auto-locking module; DESi DESi wake it up and touch the wake it up and touch the press and hold any take the magnet closer to locking button.
  • Page 14 NOTE: For Android phones, all the requested permissions need to be given without any restriction during installation of app. NEW MOBILE PHONE, search “Desi Utopic” on application stores. Download, install and run the application. - With - Choose desired language and define a password or skip it.

  • Page 15: Report Tab

    DELETE ALL REMOTE CONTROLLERS If you want to delete all the controllers of motorized cylinder, touch “Delete All Controllers”. The master controller cannot be deleted by using this menu item. 5.3.4. REPORT TAB Menu In this tab, you can see which user unlocked or locked the device with Button time and date information.

  • Page 16: Locking The Door

    5.4. USAGE Before you use your motorized cylinder, you should adjust it properly according to the lock which motorized cylinder will work together. First, you should adjust “direction of locking” and then “number of rotation” (see page 10 and 11) 5.4.1.

  • Page 17: Maintenance

    5.5. MAINTENANCE You can clean external surfaces by soft, slightly damp cloth. Never use abrasive chemicals or water for this purpose. Don’t try to disassemble your motorized cylinder. 5.5.1. CHARGING YOUR MOTORIZED CYLINDER If you hear three short tones after operation of the motorized cylinder or if the rotation speed is too slow compared to normal working speed, you need to charge your motorized cylinder.
  • Page 18 9. TROUBLESHOOTING IF THE MOTORIZED CYLINDER CANNOT FULLY LOCK/UNLOCK THE DOOR There can be high friction on the lock or latch bold. It may be caused by sag of the door or unadjusted locking mechanism. Check if you can open the lock and latch with a key easily. If there is a problem on door or lock, that need to be fixed. Batteries of motorized cylinder may be weak.
  • Page 19 10. HOW TO RESET MOTORIZED CYLINDER If you want to change master controller of your motorized cylinder or if you want to delete all controllers enrolled to the device, you can reset your motorized cylinder as follows: - Press and hold 2 buttons on the motorized knob. A long warning tone will be heard. Continue to hold the buttons. After a while, second warning tone will start.
  • Page 20 © DESi Alarm and Security Systems Inc.
