Summary of Contents for DESi utopic R OD CONVERT
- Page 1 Smart Lock INSTALLATION MANUAL...
- Page 2 INDEX • INSTALLATION FOR DOOR THICKNESS 1.57'' - 1.96'' (40mm to 50mm) (non-Kwikset Deadbolts)......3-4 • INSTALLATION FOR DOOR THICKNESS 1.37'' to 1.96'' (35mm to 50mm) ALL KWIKSET DEADBOLTS ....5-7 • INSTALLATION FOR DOOR THICKNESS 1.37'' (35mm) non-KWIKSET DEADBOLTS..........8-10...
-
Page 3: General Information And Warnings
GENERAL INFORMATION and WARNINGS - Before using your motorized cylinder, Locking way (right or left handed door) and Number of turns should be adjusted properly. Otherwise, the device will not work in the correct way and maybe broken. - For emergency conditions, we recommend you to put the keys in an accessible place (like car, bag etc.) - If there is any problem with the door or the locking mechanism, first of all, those problems have to be solved. -
Page 4: Features Of The Device
Control Options and Compatible Accessories 1. FEATURES OF THE DEVICE Structure Wireless Fingerprint Readers Wireless Keypad ABS Plastic Wireless Auto-Locking Module Compatible Cylinder Type Wireless Home Automation Interface US Deadbolts Remote Controllers Batteries and Battery Life Remote Access Module Your motorized knob is equipped with rechargeable Lithium Ion batteries. - Page 5 INSTALLATION FOR DOOR THICKNESS 1.57'' - 1.96'' (40mm to 50mm) (non-Kwikset Deadbolts) 1) Apply a piece of tape band to exterior unit of your existing 5) Check and verify that chassis's top position is same as at the deadbolt photo 2) Remove the screws of the thumbturn (interior unit) 6) Verify that your cam bar is that the horizontal position and 3) Take out the thumbturn of your door...
- Page 6 INSTALLATION FOR DOOR THICKNESS 1.57'' - 1.96'' (40mm to 50mm) (non-Kwikset Deadbolts) 9) Insert the adaptor to Utopic Covert 10) Verify that marked points are at same position as shown at the photo 11) Insert the Utopic Conver to cam bar till the middle of the cam bar 12) Rotate Utopic Convert slightly to left and push to fit it...
- Page 7 INSTALLATION FOR DOOR THICKNESS 1.37'' to 1.96'' (35mm to 50mm) ALL KWIKSET DEADBOLTS 1) Apply a piece of tape band to exterior unit of your existing 5-6) Install chassis but don't tighten the screws. deadbolt. 7) Insert adaptor to cam bar. 2) Remove the screws of the thumbturn (interior unit).
- Page 8 INSTALLATION FOR DOOR THICKNESS 1.37'' to 1.96'' (35mm to 50mm) ALL KWIKSET DEADBOLTS 9) Remove the tape band. 13) Check and verify that chassis's top position is same as at the 10) Remove both outside and inside units of the deadbolt. photo.
- Page 9 INSTALLATION FOR DOOR THICKNESS 1.37'' to 1.96'' (35mm to 50mm) ALL KWIKSET DEADBOLTS 17 -18) Insert the adaptor to Utopic Covert. 19) Verify that marked points are at same position as shown at the photo. 20) Insert the Utopic Conver to cam bar till the middle of the cam bar.
- Page 10 INSTALLATION FOR DOOR THICKNESS 1.37'' (35mm) non-KWIKSET DEADBOLTS 1) Apply a piece of tape band to exterior unit of your existing 5-6) Install chassis but don't tighten the screws. deadbolt. 7) Insert adaptor to cam bar. 2) Remove the screws of the thumbturn (interior unit). 8) You will see a piece left out of the adaptor.
- Page 11 INSTALLATION FOR DOOR THICKNESS 1.37'' (35mm) non-KWIKSET DEADBOLTS 9) Remove the tape band. 13) Check and verify that chassis's top position is same as at the photo. 10) Remove both outside and inside units of the deadbolt. 14) Verify that your cam bar is that the horizontal position as 11) Cut 1 mm larger than the marked point on the interiour unit's cam shown at the photo and install chassis and screws.
- Page 12 INSTALLATION FOR DOOR THICKNESS 1.37'' (35mm) non-KWIKSET DEADBOLTS 17 -18) Insert the adaptor to Utopic Covert. 19) Verify that marked points are at same position as shown at the photo. 20) Insert the Utopic Conver to cam bar till the middle of the cam bar. 21) Rotate Utopic Convert slightly to left and push to fit it.
- Page 13 © DESi Alarm and Security Systems Inc.
