DESi Utopic R User Manual

Wireless motorized cylinder
Hide thumbs Also See for Utopic R:
Table of Contents

Advertisement

Quick Links

Wireless Motorized Cylinder
USER MANUAL

Advertisement

Table of Contents
loading

Related Manuals for DESi Utopic R

Summary of Contents for DESi Utopic R

  • Page 1 Wireless Motorized Cylinder USER MANUAL...
  • Page 2 GENERAL INFORMATIONS and WARNINGS - Before using your motorized cylinder, Locking way and Number of turns should be adjusted properly. Otherwise, the device would not work in a correct way. - For emergancy conditions, we recommend you to put the keys to an accessible place (like car, bag etc.) - If there is any problem with door or locking mechanism, first of all, those problems need to be solved.

  • Page 3: Features Of The Device

    1. FEATURES OF THE DEVICE Controlling Options and Compatible Accessories Structure Wireless Fingerprint Readers ABS Plastic Wireless Keypad Wireless Auto-Locking Module Cylinder Length Wireless Home Automation Interface (outside) 31 mm x 35 mm (inside) Remote Controllers Inside part can extensile up to 47 mm Remote Access Module (Different cylinder lengths are available) Batteries and Battery Life...
  • Page 4 2. PARTS OF DEVICE and INSTALLATION 1.STEP Remove Control Cylinder Buttons existing cylinder. microUSB 2. STEP Charging Port Install motorized cylinder and Handle for tighten Manual the screw Operation...

  • Page 5: Set Screw

    In some security doors, even if you remove cylinder screw, you cannot remove cylinder due to cramped installation of cylinder defender. Follow the instructions below, for that kind of situations: - Untighten screws of cylinder defender (don’t remove the screws) - Remove cylinder screw and take out the old cylinder.
  • Page 6 WIRELESS FINGERPRINT Display READER (V1) In this section, you can find details about installation and Touch Button #1 usage of Wireless Fingerprint Reader Version 1. If motorized cylinder bundled with fingerprint reader, Touch Button #2 it would be the master controller of your motorized cylinder. Wake Up Button Before you use your motorized cylinder, you should adjust it properly according to the lock which motorized...
  • Page 7 4.1. INSTALLATION OF WIRELESS FINGERPRINT READER V1 First of all, unscrew the set screw at the bottom of reader with a 19 mm (3/4") hex key and seperate metal part and plastic part. After that, remove the battery, if it is already placed. Use one of the methods below: 4.1.1.
  • Page 8 4.1.2. Second Method (from Outside) Place reader Install Tighten 1st Step 1st Step 2nd Step 2nd Step 3rd Step 3rd Step to the door battery and the set and tighten it place the screw. with short metal cover. screws from two holes.
  • Page 9 4.3. SETTINGS / ADMINISTRATION MENU You can change settings of your motorized cylinder and perform administrative activities via this menu. Before using your smart cylinder, “number of turns” and “locking way” settings should be adjusted properly. Otherwise, it would damage the device’s mechanical structure.
  • Page 10 4.3.1. ENROLLING A NEW FINGERPRINT (LR) If you want to enroll a new fingerprint to the reader, follow the steps below: - Touch “WAKE UP”. Two arrows will appear on display. Than touch “2”. “AD” will be shown. - Put one of the master fingers to the reader. First “OK” and than “LR” will be shown. - Touch to “1”...
  • Page 11 4.3.2.DELETING ENROLLED FINGERPRINTS ONE-BY-ONE (DL) If you want to delete an enrolled fingerprint which you know the id number, follow the steps below: - Touch “WAKE UP”. Two arrows will appear on display. Than touch “2”. “AD” will be shown. - Put one of the master fingers to the reader.
  • Page 12 4.3.3. DELETING ALL FINGERPRINTS / RESET FINGERPRINT READER (CL) If you want to delete all enrolled fingerprint readers (including masters) , follow the steps below: - Touch “WAKE UP”. Two arrows will appear on display. Than touch “2”. “AD” will be shown. - Put one of the master fingers to the reader.
  • Page 13 4.3.4. ADJUSTING MOTORIZED CYLINDER ACCORDING TO LOCK’S NUMBER OF ROTATION TO LOCK/UNLOCK (TC) To adjust your motorized cylinder according to lock’s number of rotation, follows the steps below: - First of all, close the door. - Touch “WAKE UP”. Two arrows will appear on display. Than touch “2”. “AD” will be shown. - Put one of the master fingers to the reader.
  • Page 14 4.3.5. ADJUSTING DIRECTION OF LOCKING ACCORDING TO DOOR’S OPENING WAY (MW) To adjust your motorized cylinder’s locking way according to the door, follows the steps below: - Touch “WAKE UP”. Two arrows will appear on display. Than touch “2”. “AD” will be shown. - Put one of the master fingers to the reader.
  • Page 15 4.3.6. REPORTING TOTAL NUMBER OF ENROLLED FINGERS (UC) To adjust your motorized cylinder’s locking way according to the door, follows the steps below: - Touch “WAKE UP”. Two arrows will appear on display. Than touch “2”. “AD” will be shown. - Put one of the master fingers to the reader.
  • Page 16 4.3.7. ENABLING OR DISABLING BUZZER SOUND (BU) You can disabled (or enable) activation sounds by following steps below: - Touch “WAKE UP”. Two arrows will appear on display. Than touch “2”. “AD” will be shown. - Put one of the master fingers to the reader. First “OK” and than “LR” will be shown. - Touch to “2"...
  • Page 17 4.3.8. AUTO-LOCKING FEATURE (RF) Your device has an automatic locking feature which locks itself 1 minute after it is unlocked. If you enable this feature, you will be sure that your door is always locked. You can enable or disable this feature by following steps below: - Touch “WAKE UP”.
  • Page 18 4.3.9. DELAYED LOCKING FEATURE (MA) Your motorized cyclinder has a delayed locking feature which locks itself 5 second after you press the locking button on the motorized cylinder. If this feature is enabled, when you are going out, if you touch locking button on motorized cylinder and close the door in 5 seconds, it will lock the door automatically.
  • Page 19 4.3.10. SHIFTING MOTORIZED CYLINDER TO ENROLLING NEW CONTROLLER MODE (ML) Your motorized cylinder may learn up to 40 different controllers. To shift your motorized cylinder to enrolling new controller mode, follows the steps below: - Touch “WAKE UP”. Two arrows will appear on display. Than touch “2”. “AD” will be shown. - Put one of the master fingers to the reader.
  • Page 20 4.3.11. DELETING ALL ENROLLED CONTROLLERS OF MOTORIZED CYLINDER EXCEPT MASTER CONTROLLER (MD) To delete all enrolled controllers of your motorized cylinder, follows the steps below: - Touch “WAKE UP”. Two arrows will appear on display. Than touch “2”. “AD” will be shown. - Put one of the master fingers to the reader.
  • Page 21 4.3.12. REPORTING NUMBER OF ENROLLED CONTROLLERS VIA BUZZER SOUND (MC) Your motorized cylinder can report number of enrolled controllers via buzzer sound. To do this, follows the steps below: - Touch “WAKE UP”. Two arrows will appear on display. Than touch “2”. “AD” will be shown. - Put one of the master fingers to the reader.
  • Page 22 4.3.13. ADJUSTING LATCH RETRACTION PERIOD (HT) According to type of your lock and usage, you would need to adjust the time period which the motorized cylinder will keep latch of the lock inside when it unlocks the lock. To adjust latch retraction period, follows the steps below: - Touch “WAKE UP”.

  • Page 23: Locking The Door

    4.4. USAGE Before using your motorized cylinder, you should adjust “direction of locking (4.3.5)” and “number of rotation (4.3.4)” according to lock which will be used with motorized cylinder. 4.4.1. UNLOCKING AND OPENING THE DOOR Touch to “WAKE UP” and put an enrolled finger to sensor. Fingerprint id will be displayed and motorized cylinder will unlock and open the door.

  • Page 24: Maintenance

    4.5. MAINTENANCE You can clean external surfaces by soft, slightly damp cloth. Never use abrasive chemicals or water for this purpose. Watch electronic parts of the system during changing batteries. Don’t contact sharp or conductive materials to those parts. 4.5.1. REPLACING FINGERPRINT READER’S BATTERY If you start to see “BL”...
  • Page 26 Display WIRELESS FINGERPRINT DESi READER (V2) Touch Button #1 - Lock In this section, you can find details about installation and - Enter Shown Item usage of Wireless Fingerprint Reader Version 2. - Confirm Selection If motorized cylinder bundled with fingerprint reader, it would be the master controller of your motorized cylinder.
  • Page 27 Unscrew back plate screw at the bottom of reader and seperate pack plate from device. After that, follow the steps below: 1st Step 2nd Step Place back plate to Place the device and DESi the desired location tighten back plate and fix it with 2 screw.
  • Page 28 - Put the same finger again till you see “OK” and remove. . “L1" will be displayed. - Put the same finger again till you see “OK”. After this step, your finger will be enrolled as first master. Schematic representation of operation is as follows: DESi OK LEARN...
  • Page 29 5.3. SETTINGS / ADMINISTRATION MENU You can change settings of your motorized cylinder and perform administrative activities via this menu. Before using your smart cylinder, “number of turns” and “locking way” settings should be adjusted properly. Otherwise, it would damage the device’s mechanical structure.
  • Page 30 - Put the same finger again till you see “OK” and remove. . “L1" will be displayed. - Put the same finger again till you see “OK”. In this way, the new finperprint will be enrolled to the device. Schematic representation of operation is as follows: DESi ADMIN OK LEARN NOTE 1: System assigns an id to fingers and this id is shown when finger is read.
  • Page 31 - “OK” will be shown. In this way, the related finperprint will be deleted. Schematic representation of deleting a fingerprint (e.g. id is “07") is as follows: DESi ADMIN DELETE NOTE 1: System assigns an id to fingers and this id is shown when finger is read. By mistake, if you pass the id of fingerprint you want to delete, wait a few seconds till display goes off and restart the procedure.
  • Page 32 - Touch to “2" till you see “17" and touch to “1". - “OK” will be shown. In this way, all the finperprints (including masters) will be deleted. Schematic representation of operation is as follows: DESi ADMIN RESET NOTE: If you pass “17" by mistake, don’t touch any button and wait a few seconds till display goes off. After that restart the...
  • Page 33 - When desired way is displayed, touch to “1". “OK” will be displayed. In this way, motorized cylinder’s direction of locking will be set. Schematic representation of changing direction of locking from right to left is as follows: DESi ADMIN MOTOR...
  • Page 34 - Touch to “2" till “TURN” appears and touch to “1" when “TURN” is on display. ”OK" will be shown and cylinder will automatically lock and unlock the door. In this way, motorized cylinder will learn how many rotations is needed to lock / unlock the door. Schematic representation of operation is as follows: DESi ADMIN TURN...
  • Page 35 - Touch to “2" till “USER” appears and touch to “1" when “USER” is on display. In this way, number of enrolled fingerprints will be displayed. Schematic representation of this operation (which shows 8 fingerprints enrolled to reader) is as follows: DESi ADMIN USER...
  • Page 36 “ON” - buzzer is enabled. - When desired choice is displayed, touch to “1". “OK” will be displayed. In this way, desired buzzer choice will be set. Schematic representation of disabling buzzer sound is as follows: DESi ADMIN SOUND NOTE: To transfer settings to motorized cylinder, you need to lock or unlock motorized cylinder via master controller.
  • Page 37 “ON” - auto-locking is enabled. - When desired choice is displayed, touch to “1". “OK” will be displayed. In this way, desired auto-locking choice will be set. Schematic representation of enabling auto-locking is as follows: DESi ADMIN NIGHT NOTE: To transfer settings to motorized cylinder, you need to lock or unlock motorized cylinder via master controller.
  • Page 38 “ON” - delayed locking is enabled. - When desired choice is displayed, touch to “1". “OK” will be displayed. In this way, desired delayed locking choice will be set. Schematic representation of enabling delayed locking is as follows: DESi ADMIN MANUAL...
  • Page 39 If enrolling will be succesful, you will hear two short warning tones from motorized cylinder. Schematic representation of operation is as follows: DESi ADMIN R.LEARN...
  • Page 40 - “OK” will be shown. In this way, motorized cylinder will delete all enrolled controllers of motorized cylinder with a long warning tone. Schematic representation of operation is as follows: DESi ADMIN R.DELETE NOTE: This operation doesn’t delete master controller from motorized cylinder’s memory. If you want to delete master...
  • Page 41 - Touch to “2" till “R.COUNT” appears and touch to “1" when “R.COUNT” is on display. - “OK” will be displayed. In this way, motorized cylinder will start to report number of enrolled controllers via short warning tones. Schematic representation of operation is as follows: DESi ADMIN R.COUNT...
  • Page 42 - When desired choice is displayed, touch to “1". “OK” will be displayed. In this way, latch retraction period of motorized cylinder will be adjusted. Schematic representation of adjusting latch retraction period of 5 seconds is as follows: DESi ADMIN HOLD.TM...
  • Page 43 5.4. USAGE Before using your motorized cylinder, you should adjust “direction of locking (5.3.5)” and “number of rotation (5.3.4)” according to lock which will be used with motorized cylinder. 5.4.1. UNLOCKING AND OPENING THE DOOR Touch to device with your palm to wake it up and put an enrolled finger to sensor. Fingerprint id will be displayed and motorized cylinder will unlock and open the door.
  • Page 44 Don’t contact sharp or conductive materials to those parts. 5.5.1. REPLACING FINGERPRINT READER’S BATTERY DESi If you start to see “BL” message on fingerprint reader’s display, you need to replace the battery. Please get 2x AAA Alkaline batteries and follow steps below: - Unscrew back plate screw.

  • Page 46: Mobile Application

    MOBILE APPLICATION In this section, you can find details about usage of Mobile Application If there is no controller with your motorized cylinder and if you enroll your smart phone as first controller, it will be master controller of your motorized cylinder. Before you use your motorized cylinder, you should adjust it properly according to the lock which motorized cylinder will work together.
  • Page 47 6.1. ENROLLING A MOBILE PHONE AS MASTER CONTROLLER - Search “Desi Utopic” on stores. Download, install and run the application. - Choose desired language and define a password. - Touch “+” on the top left corner to see the list of Utopic motorized cylinders around.

  • Page 48: Application Settings

    6.2. APPLICATION SETTINGS If you touch to menu button on the top right corner when it is not connected to motorized cylinder, you will reach to settings menu of application. Related menu items are as follows: PASSWORD: You can disable, enable or change the password of application. Menu LANGUAGES: You can change language of the application.

  • Page 49: Device Info Tab

    6.3. MOTORIZED CYLINDER SETTINGS / ADMINISTRATION MENU If you touch to menu button on the top right corner when the application is connected to motorized cylinder as master controller, you will reach to settings menu of connected motorized cylinder. You can change settings of your motorized cylinder and perform administrative activities via this menu.
  • Page 50 6.3.2. KNOB SETTINGS TAB (for master user only) Menu In this tab, there are following menu items: Button BUZZER OF KNOB: You can enable / disable activation sounds coming from motorized cylinder. DELAYED LOCKING: Your motorized cyclinder has a delayed locking feature which locks itself 5 second after you press the locking button on the motorized cylinder.
  • Page 51 ENROLL NEW REMOTE CONTROLLER: Your motorized cylinder may learn up to 40 different controllers. To shift your motorized cylinder to enrolling new controller mode, touch to “Green Plus” button. In this way, motorized cylinder will shift to enrolling new controller mode with a long warning tone. After that tone, you need to send locking or unlocking signal via the new controller that you want to enroll to the motorized cylinder in following ways: - For fingerprint reader, wake it up and touch to lock button.

  • Page 52: Users Tab

    AUTO DISCONNECTION TIME: According to type of your lock and usage, you would need to adjust the time period which the motorized cylinder keeps latch of the lock inside when it unlocks the lock. You can use the slider to adjust latch retraction period in 4 different way: From left to right;...

  • Page 53: Reports Tab

    6.3.4. REPORT TAB (for master user only) Menu In this tab, you can see which user unlocked or locked the device. For Button mobile devices, you can see date and time but for controllers like fingerprint reader, remote controller, keypad etc. you cannot see date and time.
  • Page 54 - With NEW MOBILE PHONE , search “Desi Utopic” on stores. Download, install and run the application. - Choose desired language and define a password. - Touch “+” on the top left corner to see the list of Utopic motorized cylinders around.
  • Page 56 - After a while, double tone and than triple tone will be heard. In this way, motorized cylinder will be reset and all the controllers, including master controller, enrolled to the device will be deleted. Desi Alarm and Security Systems Inc. www.desi.com.tr...
