Utopic2 Smart Lock
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Utopic2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DESi Utopic2

Summary of Contents for DESi Utopic2

  • Page 1 Utopic2 Smart Lock USER MANUAL...
  • Page 2 GENERAL INFORMATIONS and WARNINGS - We recommend you to put the keys to an accessible place (like car, bag etc.) in an emergancy condition. - If there is any problem with door or locking mechanism, first of all, those problems need to be solved.

  • Page 3: Features Of The Device

    1. FEATURES OF THE DEVICE Controlling Options and Compatible Accessories Structure Wireless Fingerprint Readers Engraved Aluminum, ABS Plastic, Zamak Wireless Keypad Wireless Auto-Locking Module Cylinder Length Wireless Home Automation Interface (outside) 31 mm x 37 mm (inside) Remote Controllers Inside part can extensile up to 43 mm Remote Access Module (Different cylinder lengths are available) Batteries and Battery Life...
  • Page 4 2. PARTS OF DEVICE and INSTALLATION Handle Handle Screw Cylinder Metal Extending Parts (used if needed) The hole Hex Screw for hex key DEMOUNTING OF MOTOR AND CYLINDER - Open “handle screw” and remove the handle by pulling. - Remove the batteries. - Rotate “hex screw”...
  • Page 5 EXTENDING INSIDE PART OF THE CYLINDER (if needed) 26 10 If the door thickness is not suitable to the cylinder of the device, inside part of the cylinder may be extended up to 6 mm by 2 mm steps. To extend the cylinder’s inside part, follow the instructions below: - Open “handle screw”...

  • Page 6: Mobile Application

    MOBILE APPLICATION If you enroll your smart phone as first controller, it will be master controller of your smart lock. Both master and user controllers can lock/unlock the smart lock. Besides, only the master controller can change settings of smart lock. Before using your smart lock, you should adjust it properly by setting “locking way”...
  • Page 7 3.1. ENROLLING A MOBILE PHONE AS MASTER CONTROLLER 1. Search “Desi Utopic” on stores. Download, install and run the application. 2. Choose language and confirm. 3. Press and hold “set/reset button” on smart lock until you hear a long and short warning tone and then release button.

  • Page 8: Application Settings

    3.2. APPLICATION SETTINGS If you touch to menu button on the top right corner when it is not connected to smart lock, you will reach to settings menu of application. Related menu items are as follows: PASSWORD: You can disable, enable or change the password of application. Also you can enable biometric login or face ID from that menu.

  • Page 9: Device Info Tab

    3.3. SMART LOCK SETTINGS / ADMINISTRATION MENU If you touch the menu button in the top right corner when the application is connected to smart lock as master controller, you will reach to settings menu of connected smart lock. You can change settings of your smart lock and perform administrative activities via this menu.
  • Page 10 3.3.2. KNOB SETTINGS TAB Menu In this tab, there are following menu items: Button NIGHT MODE AVAILABILITY: Night mode is a security option which temporarily disables all controllers of motorized cylinder. In this way, the door can only be opened by knob or the key. If this feature is enabled, when you rotate your motorized cylinder through locking way 2 times, the device will shift to night mode till you rotate the know or key through unlocking way.
  • Page 11 NOTE 1: LATCH RETRACTION PERIOD, MOTOR POWER, MOTOR TYPE features are only available for device type N2 and firmware version is 87 or higher. NOTE 2: Utopic2 Gold Edition models have coreless motor, please be sure that coreless motor is set. Otherwise your smart lock will not work properly.

  • Page 12: Users Tab

    3.3.3. USERS TAB In this tab, you can manage controllers of smart lock including auto-locking module, home automation interface, keypad, fingerprint reader, remote controllers etc. If you touch “Controllers” line, you can edit enrolled controllers. If you touch any user, you reach dedicated controller page which you can edit name or delete the controller one by one. In addition, you can apply time limited access to any user or controllers from this menu.
  • Page 13 For how to video, please click on the link https://youtu.be/7iKNoLvnvN8?t=31 For fingerprint reader; For keypad; For remote controller; For auto-locking module; DESi DESi wake it up and touch the wake it up and touch the press and hold any take the magnet closer to locking button.
  • Page 14 3.3.5. GENERATING ONE TIME/LIMITED TIME ACCESS CODE VIA MASTER PHONE Menu If you are the master user of smart lock, you can let anybody unlock the door via application or wireless keypad, even if you are far away. Internet connection is not needed for this function to work.
  • Page 15 NOTE: For Android phones, all the requested permissions need to be given without any restriction during installation of app. NEW MOBILE PHONE, search “Desi Utopic” on application stores. Download, install and run the application. - With - Choose language and confirm.

  • Page 16: Locking The Door

    4. USAGE 4.1. UNLOCKING AND OPENING THE DOOR If you touch to Unlock button on application screen, system automatically unlocks and opens the door. You can unlock/open the door by using the knob or the key as well. If semi-automatic working is enabled, when you rotate the knob or the key to unlocking way, it will sense the movement and continue automatically.

  • Page 17: Maintenance

    In this way, the motorized cylinder will shift to Night Mode. To exit from night mode, turn the knob through unlocking way. It will automatically unlock the door and shift to normal working mode. You can shift to or exit from night mode by using key as well.
  • Page 18 5.2. HOW TO RESET MOTORIZED CYLINDER If you want to change master controller of motorized cylinder, you need to reset motorized cylinder. To do this, follow the steps below: - Remove 1 battery of your motorized cylinder and press and hold “set/reset button”.
  • Page 19 5.3. Unlocking The Door By Using Generated Code - Copy the shared code to clipboard. (You can copy all the shared text. The app will filter the code automatically.) - Install Utopic application to your mobile phone, launch the app, choose the language. - Hold your mobile as close as possible to the door that smart lock is installed and on the main screen, touch to “Use One Time Pass Code”...
  • Page 20 After enabling OTP mode on keypad, follow the steps below to enroll it to the smart lock: - Launch the app on the master phone and connect to the smart lock. - Touch to “Settings” icon located on upper right corner and go to “Users” tab. - Touch to “Enroll New Controller”...
  • Page 21 From: You can choose beginning date of the period which the generated password will be valid. To: You can choose ending date of the period which the generated password will be valid. After choosing desired settings, touch to “Create One Time Code” line. - A pop-up will appear which shows 8 digit password.

  • Page 22: Important Notes

    IMPORTANT NOTES - You can generate time limited access codes while you are away. Bluetooth or internet connection is not necessary. Besides, if you want to change check-in/out times, you should connect to the smart lock via bluetooth. - “Single” usage codes can be used “1 time only”. “Multi” usage code will be valid during selected period. - You can generate both “single”...
  • Page 23 6. TROUBLESHOOTING SMART LOCK CANNOT FULLY LOCK/UNLOCK THE DOOR - There can be high friction on the lock or latch bold. It may be caused by sag of the door or unadjusted locking mechanism. Check if you can open the lock and the latch with a key easily. If there is a problem on door or lock, that need to be fixed.
  • Page 24 - If you have this issue during enrolling your phone to the smart lock, maybe you foget to shift the smart lock to enrolling mode. Please check pages 8, 14, and 16 for details about enrolling your phone to smart lock. Please see the FAQ section for more http://en.desi.com.tr/faqutopicr.pdf...
  • Page 25 If your smart lock software/firmware version is below 87, you cannot create a temporary access code via application. To use this feature, you need to upgrade your smart lock to latest firmware. Please see the FAQ section for more http://en.desi.com.tr/faqutopicr.pdf...
  • Page 26 7. HOW TO UPDATE FIRMWARE OF SMART LOCK Please follow the steps below: Menu Button - Connect to the smart lock via master phone and touch to menu button. - On “Device Info” tab, touch to ‘”Software Version” line. - If a new firmware is available, the application will inform you. - Touch the Start button and follow the instructions on application.
  • Page 27 8. HOW TO FIX CONNECTION PROBLEM IN SOME ANDROID PHONES Some Android phones may have problems when pairing to the smart lock for the first time. These problems are due to the difference of Android versions. To solve this problem, just follow the steps below. 1.
  • Page 28 © DESi Alarm and Security Systems Inc.
