INVT Goodrive18 Series Operation Manual page 77

Goodrive18 series two-in-one VFD
Function
Name
code
Analog
calibration
P08.20
function
selection
DEC time of
P08.21
emergency stop
Set counting
P08.25
value
Designated
P08.26
counting value
P08.27 Set running time
Automatic fault
P08.28
reset times
Automatic fault
P08.29
reset interval
Function parameters and function terminal reuse
1: One
0: Invalid
1: Valid
0.0–6553.5s
0.0 indicates coast to stop.
The counter works by the input pulse signals of
the HDI terminals.
When the counter achieves a fixed number, the
multifunction output terminals will output the
signal of "Designated counting number arrival"
and the counter go on working; when the counter
achieves a set number, the multifunction output
terminals will output the signal of "Set counting
number arrival", the counter will clear all
numbers and stop to recount before the next
pulse.
The designated counting value
no more than the set counting value P08.25.
S terminal
Y1
RO1, RO2
P08.25 setting range: P08.26–65535
P08.26 setting range:
This function code indicates the preset running
time of the VFD. When the accumulative running
time achieves the set time, the multifunction
digital output terminals will output the signal of
"running time arrival".
Setting range: 0–65535min
Automatic fault reset times: When the VFD
selects automatic fault reset, it is used to set the
times of automatic reset. If the number of
continuous reset times exceeds the value, the
VFD will report a fault and stop.
Automatic fault reset interval: Time from when a
-72-
Description
P08.26
Reach the designated
0–P08.25
Default
value
1
0.0s
0
0
should be
Reach the set
counting value
counting value
0m
0
1.0s
Modify
◎
○
○
○
○
○
○
