Goodrive18 series two-in-one VFD
Function
Name
code
ACC time at the
P01.06 S-curve start
phase
DEC time at the
P01.07 S-curve end
phase
P01.08 Stop mode
Starting
P01.09 frequency of DC
braking while
Function parameters and function terminal reuse
linearly.
Output frequency
fmax
Output frequency f
fmax
t1
1: S curve
The output frequency increases or decreases
t1
according to the S curve.
Output frequency f
fmax
t1
The S curve is generally applied to elevators,
conveyors, and other application scenarios
where smoother start or stop is required.
Setting range: 0.0–50.0s
Note: Valid when
0: Decelerate to stop. After the stop command
becomes valid, the VFD decelerates to reduce
the output frequency during the set time. When
the frequency decreases to 0Hz, the VFD stops.
1: Coast to stop. After the stop command
becomes valid, the VFD ceases the output
immediately. And the load coasts to stop at the
mechanical inertia.
Starting frequency of DC braking while stop:
Start DC braking for stop when running
-37-
Description
T
t2
t2
t2
P01.05 is set to 1.
Default
value
Timet
Time t
0.1s
0.1s
0
0.00Hz
Modify
◎
◎
○
○
