  • Page 2 Goodrive18 series two-in-one VFD Change history Change description Version Release date First release V1.0 October 2019...

  • Page 3: Table Of Contents

    Goodrive18 series two-in-one VFD Contents Contents Contents ............................ i Safety Precautions ...................... 1 Safety definition ....................... 1 Warning symbols ...................... 1 Safety guidelines ...................... 2 1.3.1 Delivery and installation ................2 1.3.2 Commissioning and running ................. 3 1.3.3 Maintenance and component replacement ..........3 1.3.4...
  • Page 4 Goodrive18 series two-in-one VFD Contents 4.3.3 How to set the VFD user password ............26 4.3.4 Viewing VFD status ..................26 4.3.5 How to copy function parameters ............... 27 Function parameters and function terminal reuse ..........28 Function parameter list ..................28 Function terminal reuse ..................
  • Page 5 C.6.1 C3 filter model ....................149 C.6.2 C3 filter model selection ................... 150 Appendix D Further information ................151 D.1 Product and service queries ..................151 D.2 Feedback on INVT VFD manuals................151 D.3 Documents on the Internet ..................151...

  • Page 6: Safety Precautions

    Goodrive18 series two-in-one VFD Safety Precautions 1 Safety Precautions Read the manual carefully before moving, installing, running and servicing the variable-frequency drive (VFD), and follow all safety precautions contained. Otherwise, device damage or personal injury or even death can result.

  • Page 7: Safety Guidelines

    Goodrive18 series two-in-one VFD Safety Precautions 1.3 Safety guidelines Only trained and qualified electricians can operate on the device. Do not perform any wiring, inspection, or component changing when power is applied. Ensure all input power supplies are disconnected before wiring or checking, and always wait at least the time designated on the VFD or until the DC bus voltage is less than 36V.

  • Page 8: Commissioning And Running

    Goodrive18 series two-in-one VFD Safety Precautions 1.3.2 Commissioning and running  Disconnect all power sources applied to the VFD before terminal wiring, and wait for at least the time designated on the VFD after disconnecting the power sources.  High voltage presents inside the VFD during running. Do not carry out any operation on the VFD during running except for keypad setup.

  • Page 9: Product Overview

    Whether the accessories (including the manual and keypad) inside the packing box are complete. If any problems are found, contact the local dealer or INVT office. 2.1.2 Checking before applying Check the following before applying the VFD.

  • Page 10: Installation Confirmation

    Goodrive18 series two-in-one VFD Product overview 3. When the altitude exceeds 1000m, derate by 1% for every increase of 100m. When the altitude exceeds 2000m, configure an isolation transformer at the VFD input end. It is not recommended that the VFD be used at the altitude higher than 5000m.

  • Page 11: Product Specifications

    Goodrive18 series two-in-one VFD Product overview rotational direction is correct. If not, change the rotation direction by swapping any two phase wires of the motor. 4. Set all control parameters and then operate. 2.2 Product specifications Function Specifications Rated input For the -4 type: 3PH 380V(-15%)–440V(+10%)
  • Page 12 Goodrive18 series two-in-one VFD Product overview Function Specifications Overload 150% for 1min, 180% for 10s, 200% for 1s capacity Settings can be implemented through digital, analog, pulse Frequency frequency, multi-step speed running, simple PLC, PID, setting MODBUS communication, and so on.

  • Page 13: Product Nameplate

    Shenzhen INVT Electric Co.,Ltd Figure 2.1 Product nameplate Note: This is a nameplate example for a standard Goodrive18 series two-in-one VFD model. The mark such as CE/TUV/IP20 will be applied according to the actual certification situation. 2.4 Model designation code A model designation code contains product information.

  • Page 14: Product Ratings

    Goodrive18 series two-in-one VFD Product overview Field Description Example Abbreviation of Abbreviation of ① GD18: short for Goodrive18 product series product series Power range + load ② Rated power 7R5: 7.5kW type ③ Voltage class Voltage class 4: AC 3PH 380V(-15%)–440V(+10%) Number of devices ④...
  • Page 15 Goodrive18 series two-in-one VFD Product overview Figure 2.3 Structural diagram Item Description External keypad Used to connect an external keypad. interface External keypad Used to protect the external keypad interface. interface cover Lower cover Used to protect the internal components.

  • Page 16: Installing

     VFD installation must be designed and performed according to applicable local laws and regulations. INVT is not liable or responsible for any installation that breaches local laws and regulations. If recommendations given by INVT are not followed, the VFD may experience problems that the warranty does not cover.

  • Page 17: Installation Direction

    The VFD can be installed on the wall or in a cabinet. The VFD must be installed vertically. Check the installation position according to following requirements. For details about outline dimensions, see Appendix B "Dimensional drawing". 3.1.3 Installation method Goodrive18 series 2-in-1 VFD supports wall mounting. -12-...

  • Page 18: Main Circuit Wiring Diagram

    Goodrive18 series two-in-one VFD Installing Figure 3.1 Installation method Step 1 Mark the positions of the installation holes. For details about the positions, see Appendix B "Dimensional drawing". Step 2 Mount the screws or bolts onto the marked positions. Step 3 Place the VFD against the wall.

  • Page 19: Main Circuit Terminal Diagram

    Goodrive18 series two-in-one VFD Installing 3.1.5 Main circuit terminal diagram Figure 3.3 Main circuit terminal diagram Terminal sign Terminal function R, S, T 3PH AC input terminals, connected to the grid U1, V1, W1 First channel of 3PH AC output terminal, connected to the motor...

  • Page 20: Control Circuit Wiring Diagram

    Goodrive18 series two-in-one VFD Installing 3.1.7 Control circuit wiring diagram Multifunction input terminal 1 Multifunction input terminal 2 Multifunction input terminal 3 Analog output 0-10V/0-20mA Multifunction input terminal 4 Multifunction input terminal 5 Analog output 0-10V/0-20mA Multifunction input terminal 6...
  • Page 21 Goodrive18 series two-in-one VFD Installing Assigned Category Sign Function Specifications default 485+ RS485 RS485 communication terminals, using Communication Shared communication the MODBUS protocol 485- Inverter  Internal impedance: 3.3kΩ unit  12–30V voltage input is acceptable Digital input  Bi-direction input terminals ...

  • Page 22: Input/Output Signal Connection Diagram

    Goodrive18 series two-in-one VFD Installing Assigned Category Sign Function Specifications default Analog Shared reference Analog reference ground ground  Output range: 0–10V or 0–20mA  Whether the terminals use voltage Inverter unit or current as output is set through Analog output the dial switch.
  • Page 23 Goodrive18 series two-in-one VFD Installing +24V and PW are short connected through the jumper Figure 3.6 Jumper based short connection If the input signal comes from NPN transistor, set the jumper according to the used power supply. + 24V + 24V...

  • Page 24: Wiring Protection

    Goodrive18 series two-in-one VFD Installing 3.2 Wiring protection 3.2.1 Protecting the VFD and input power cable in short circuit In case of short circuit, the VFD and input power cable can be protected, preventing thermal overload. Take protective measures according to the following rule.
  • Page 25 Goodrive18 series two-in-one VFD Installing  Do not connect the power supply to VFD output terminals U1, V1, W1, U2, V2, and W2. The voltage applied to the motor cable may cause permanent damage to the VFD. If frequent switchover is needed, you can use the switch/contactor that carries mechanical interlock to ensure motor terminals are not connected to both the input power cable and VFD output end simultaneously.

  • Page 26: Operating

    4 Operating 4.1 Keypad introduction Goodrive18 series two-in-one VFD does not provide a keypad but contains eight indicators, as shown in Figure 4.1. You need to use an external keypad (optional part) for parameter commissioning and use a standard RJ45 network cable to connect the external keypad to the VFD.
  • Page 27 Goodrive18 series two-in-one VFD Operating RUN/TUNE FWD/REV LOCAL/REMOT TRIP DATA QUICK SHIFT STOP Figure 4.2 External keypad diagram Item Description VFD running status indicator. On: The VFD is running. RUN/TUNE Off: The VFD is stopped. Blinking: The VFD is autotuning parameters.

  • Page 28: Keypad Display

    The external keypad for operating Goodrive18 series two-in-one VFD displays the stopped-state parameters, running-state parameters, function parameter editing status, and fault alarm status. Goodrive18 series two-in-one VFD has two channels of inverting output, which are distinguished by the prefix letters P/F. Function codes in group P correspond to the output (U1/V1/W1) of #1 inverter unit, while function codes in group F correspond to the output (U2/V2/W2) of #2 inverter unit.

  • Page 29: Displaying Running-State Parameters

    Goodrive18 series two-in-one VFD Operating frequency, bus voltage, input terminal status, output terminal status, PID reference value, PID feedback value, torque setting, AI2, AI3, PLC and the current step of multi-step speed, pulse counting value, and length value. You can press >>/SHIFT to shift selected parameters from left to right or press QUICK/JOG (P07.02=2) to shift selected parameters from right to left.

  • Page 30: Operations On The Keypad

    Goodrive18 series two-in-one VFD Operating 4.3 Operations on the keypad 4.3.1 How to switch between the P and F function groups You can switch between the P function group and F function group by using either of the following methods: Method 1: Using the combined keys: PRG/ESC +>>/SHIFT...

  • Page 31: How To Set The Vfd User Password

    Note: When setting the value, you can press to modify the value. SHIFT Figure 4.5 Setting a password 4.3.4 Viewing VFD status Goodrive18 series two-in-one VFD provides group P17 for status viewing. You can enter group P17 for viewing. -26-...

  • Page 32: How To Copy Function Parameters

    Figure 4.6 Viewing parameter setting 4.3.5 How to copy function parameters The external keypad for operating Goodrive18 series two-in-one VFD supports common parameter copying and embedded parameter copying. The embedded parameter copying function means that the keypad housing contains the icon and parameters can be uploaded and downloaded after P07.01 is set.

  • Page 33: Function Parameters And Function Terminal Reuse

    5 Function parameters and function terminal reuse 5.1 Function parameter list The function parameters of Goodrive18 series two-in-one VFD are divided into 30 groups (P00–P29) by function, and each function group includes several function codes (each function code identifies a function parameter). A three-level menu style is applied to function codes.
  • Page 34 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse correct factory password to enter the interface. (You are not advised to modify the factory parameters. Incorrect parameter setting may cause operation exceptions or even damage to the VFD.) When password protection does not take effect, you can change the password any time.
  • Page 35 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value Carry out command control by using RUN or STOP/RST on the keypad. When the multifunction key QUICK/JOG is set to FWD/REVC shifting function (P07.02=3), the key can be used to change the running direction.
  • Page 36 3: Analog AI3 setting (corresponding terminal AI3) Set the frequency by analog input terminals. Goodrive18 series VFD provides 3 channels of analog input terminal as the standard configuration, of which AI2 can select voltage or current (0–10V/0–20mA) by jumper; while AI3 is voltage input (-10V–+10V).
  • Page 37 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value current running stage, and set P10 to select the current running frequency. The multi-step speed has the priority when P00.06 P00.07 is not equal to 6, but the steps can only be steps 1–15.
  • Page 38 (P00.03). DEC time means the time needed if the VFD speeds down from the max. output frequency (P00.03) to 0Hz. Goodrive18 series VFD has four groups of Model ○ ACC/DEC time, which can be selected by P05. P00.12 DEC time 1...
  • Page 39 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value with caution if the change of rotation direction is disallowed after commissioning. 2: Forbid to run in reverse direction: It can be used in some special cases if the reverse running is disallowed.
  • Page 40 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 10% for each increase of 1k carrier frequency. Setting range: 1.0–15.0kHz 0: No operation 1: Rotary autotuning Comprehensive motor parameter autotune It is recommended to use rotating autotuning when high control accuracy is needed.
  • Page 41 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value This function code indicates the initial frequency Starting during VFD start. See P01.02 for detailed ◎ P01.01 frequency at 0.50Hz information. direct start Setting range: 0.00–50.00Hz...
  • Page 42 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value linearly. Output frequency fmax Output frequency f fmax 1: S curve Timet The output frequency increases or decreases according to the S curve.
  • Page 43 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value frequency reaches the starting frequency stop determined by P01.09. Wait time before ○ P01.10 0.00s Wait time before DC braking: The VFD blocks DC braking the output before starting DC braking.
  • Page 44 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value This function code indicates the mode of switching between FWD and REV rotations. FWD/REV 0: Switch at zero frequency ◎ P01.14 running 1: Switch at the starting frequency...
  • Page 45 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value started automatically after the initialization. Note: Exercise caution before using this function. Otherwise, serious result may follow. This function code determines the running state...
  • Page 46 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value power outage re-powered on. Output frequency t1=P01.22 t2=P01.23 Running Running Power off Power on Setting range: 0.0–3600.0s (valid when P01.21=1) After a VFD running command is given, the VFD is in standby state and restarts with the delay ○...
  • Page 47 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value standard motor configuration of the VFD. If the power of the motor is greatly different from that of the standard motor configuration, the control performance of the VFD degrades significantly.
  • Page 48 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value saturation coefficient 3 for the iron core of Magnetic saturation ◎ P02.14 coefficient 4 for 0.0–100.0% 40.0% the iron core of 0: No protection 1: Common motor (with low speed compensation).
  • Page 49 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value immediately. Time (min) Current overload multiple 150% 180% 200% 116% Setting range: 20.0%–120.0% P03 Vector control The speed loop dynamic response ○ P03.00...
  • Page 50 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value PI parameter P03.00, P03.01 P03.03, P03.04 Output frequency f P03.02 P03.05 PI parameters have a close relationship with the inertia of the system. Adjust PI parameters depending on different loads to meet various demands.
  • Page 51 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 1: Keypad (P03.12) 2: Reserved 3: Analog AI2 4: Analog AI3 5: Reserved 6: Multi-step speed 7: Modbus communication 8–10: Reserved Note: Setting mode 2–7, 100% corresponds to 3 times of the motor rated current Note: For setting methods 2–7, 100%...
  • Page 52 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value in torque control Setting source The function codes are used to select the of electromotion sources for setting electromotion and braking ○ P03.18 torque upper torque upper limits.
  • Page 53 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value Flux-weakening coefficient of motor Min. flux-weakening limit of motor Setting range of P03.22: 0.1–2.0 Setting range of P03.23: 10%–100% P03.24 sets the max. output voltage of the VFD, Max.
  • Page 54 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value load 1: Multi-points V/F curve 2: Torque step-down V/F curve (1.3 order) 3: Torque step-down V/F curve (1.7 order) 4: Torque step-down V/F curve (2.0 order) Curves 2 –...
  • Page 55 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value heat-up, thus decreasing the efficiency. When torque boost is set to 0.0%, the VFD uses automatic torque boost. Torque boost cut-off threshold: Below this...
  • Page 56 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value This function code is used to compensate the motor rotation speed change caused by load change during SVPWM control to improve the rigidity of the motor. The rated slip frequency of the motor needs to be calculated.
  • Page 57 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 8–10: Reserved Note: For setting methods 1 to 7, 100% corresponds to the rated voltage of the motor. This function code is the voltage digital setting...
  • Page 58 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value S1 terminal Note: By default, S1–S4 are assigned to #1 ◎ P05.01 function inverter unit, and S5–S8 are assigned to #2 selection inverter unit. If you want to change the configuration, see section 5.2 for details.
  • Page 59 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 29: Torque control prohibition 30: ACC/DEC prohibition 31: Counter trigger 32: Reserved 33: Cancel the frequency change setting temporarily 34: DC brake 35: Reserved...
  • Page 60 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value sampling of S1–S8. If the interference is strong, increase the parameter to avoid wrong operation. 0.000–1.000s This function code is used to enable virtual terminals in communication mode.
  • Page 61 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value Running FWD REV command Stopping Forward running Stopping Reverse running 2: 3-wire control 1. This mode defines Sin as the enabling terminal, and the running command is generated by FWD, the direction is controlled by REV.
  • Page 62 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value generated by FWD or REV, and they control the running direction. During running, the terminal Sin should be closed, and terminal FWD or REV generates a rising edge signal to control the running and direction of VFD;...
  • Page 63 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value S1 terminal switched off. ○ P05.15 switching off 0.000s Si electrical level delay time Si valid invalid valid invalid S2 terminal Switch-on Switch-off...
  • Page 64 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value S7 terminal ○ P05.27 switching off 0.000s delay time S8 terminal ○ P05.28 switching on 0.000s delay time S8 terminal ○ P05.29 switching off 0.000s...
  • Page 65 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value upper limit of Corresponding setting 100% -10V 20mA AI1/AI2 -100% P05.32 setting range: 0.00V–P05.34 P05.33, P05.35 setting range: -100.0%–100.0% P05.34 setting range: P05.32–10.00V AI3 input filter P05.36...
  • Page 66 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 7: Frequency level test FDT2 8: Frequency arrival 9: Zero speed running 10: Upper limit frequency arrival 11: Lower limit frequency arrival 12: Ready for operation...
  • Page 67 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value RO electric level RO2 switching invalid ○ P06.13 0.000s Invalid Valid RO valid off delay time Switch on Switch off delay delay Setting range: 0.000–50.000s...
  • Page 68 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value AO1 output When the output value exceeds the range of set ○ P06.18 corresponding maximum or minimum output, it will count 0.00V to lower limit according to the low-limit or upper-limit output.
  • Page 69 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value displayed when you press the PRG/ESC key again to enter the function code editing interface. You need to enter the correct user password to enter the interface.
  • Page 70 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 1: Lock all keys 2: Lock only PRG/ESC When P07.02=6, set the switchover sequence of Running running command channels. command 0: Keypad control→Terminals control→...
  • Page 71 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value selection 2 in BIT1: AI2 value (V on) running state BIT2: AI3 value (V on) BIT3: reserved BIT4: motor overload percentage (% on)
  • Page 72 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value temperature Inverter module ● P07.12 -20.0–120.0° C temperature Software ● P07.13 1.00–655.35 version Local ● P07.14 accumulative 0–65535h running time VFD power Used to display VFD power consumption.
  • Page 73 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value Type of 2nd-last 3: Reserved ● P07.29 fault 4: Overcurrent during ACC (P-OC1) 5: Overcurrent during DEC (P-OC2) Type of 3rd-last ● P07.30...
  • Page 74 Model ○ P08.01 DEC time 2 For details, see P00.11 and P00.12. depended Goodrive18 series VFD defines four groups of Model ○ P08.02 ACC time 3 acceleration/deceleration time, which can be depended selected by multifunction digital input terminals Model ○...
  • Page 75 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value This function code is used to define the Running reference frequency during jogging. ○ P08.06 frequency of 5.00Hz Setting range: 0.00Hz–P00.03 (Max. output...
  • Page 76 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value wobbling frequency is illustrated as follows, of which the frequency traverse range is set by P08.15. When P08.15 set to 0, traverse does not function.
  • Page 77 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 1: One Analog calibration 0: Invalid ◎ P08.20 function 1: Valid selection DEC time of 0.0–6553.5s ○ P08.21 0.0s emergency stop 0.0 indicates coast to stop.
  • Page 78 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value fault occurred to the time when automatic fault reset action. P08.28 setting range: 0–10 P08.29 setting range: 0.1–3600.0s The output frequency of the VFD changes as the Frequency load changes.
  • Page 79 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value Output frequency Detection range frequency Time t RO1, RO2 Time t Setting range: 0.00Hz–P00.03 (Max. output frequency) 0: Common running mode Running mode ○...
  • Page 80 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value LED tens: frequency control selection 0: Only valid when P00.06=0 or P00.07=0 1: Valid for all frequency setting manners 2: Invalid for multi-step speed when multi-step...
  • Page 81 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 0x000–0x111 LED ones: Action selection at power outage during frequency adjusting through digitals. 0: Save the setting at power outage 1: Clear the setting at power outage...
  • Page 82 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value Brake immediately after the stop command. It does not need to wait until the magnetic flux weakens. The cooling is better. The current of the stator...
  • Page 83 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value This function code is used to select PID feedback channel. 0: Reserved 1: AI2 2: AI3 PID feedback 3: Reserved ○ P09.02 source...
  • Page 84 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value proportional effect and differential effect) to achieve the max. frequency (P00.03) or the max. voltage (P04.31). Shorter the integral time, stronger is the adjustment.
  • Page 85 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value Setting range: 0.0–100.0% Upper limit of The function codes are used to set the upper and ○ P09.09 100.0% PID output lower limits of PID adjustor output.
  • Page 86 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value source A frequency is invalid 1: A+B frequency, buffering acceleration/deceleration of main reference source A frequency is valid and the acceleration/deceleration is determined by P08.04...
  • Page 87 Multi-step speeds are in the range of -f Multi-step speed and can be set continuously. ○ P10.12 0.0% Goodrive18 series VFD can set 16 steps of Running time of speed, which are selected by the combination of ○ P10.13 0.0s step 5 multi-step terminals 1–4, corresponding to the...
  • Page 88 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value Output frequency Running time of ○ P10.17 0.0s step 7 Multi-step speed ○ P10.18 0.0% Terminal Running time of ○ P10.19 0.0s step 8...
  • Page 89 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value ACC/ ACC/ ACC/ ACC/ selection for Function Binary Step steps 0–7 in code time1 time2 time3 time4 simple PLC BIT1 BIT0 running BIT3...
  • Page 90 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value input side lower) 0: Disable 1: Enable LED tens: Phase loss software protection on the output side 0: Disable (4kW 1: Enable LED hundreds: Phase loss hardware protection...
  • Page 91 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 0: Disallow 1: Allow DC bus voltage V Overvoltage stall threshold Overvoltage ○ P11.03 stall protection Time t Output frequency Time t Overvoltage 110–150%(standard bus voltage)(380V)
  • Page 92 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value Output current A Current-limit threshold Time t Output frequency f frequency Constant speed Acceleration Time t P11.05 setting range: 0x00–0x12 P11.06 setting range: 50.0–200.0% P11.07...
  • Page 93 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 0: The VFD continues to work after OL/UL pre-alarm 1: The VFD continues to work after underload pre-alarm and stops running upon an overload...
  • Page 94 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value Speed deviation ○ P11.14 0.0–50.0% 10.0% detection value See the following figure. Speed Actual detection value Set detection value Speed deviation ○ P11.15 0.5s...
  • Page 95 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value Setting range: 1–247 When the master is writing a frame, the communication address of the slave is set to 0; the broadcast address is the communication address.
  • Page 96 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 9: No check (N, 7, 2) for ASCII 10: Even check (E, 7, 2) for ASCII 11: Odd check (O, 7, 2) for ASCII...
  • Page 97 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 0x000–0x111 LED ones: Responding to write operations 0: Yes 1: No Communication LED tens: Communication encryption ○ P14.06 processing 0: Disable 0x000 action selection...
  • Page 98 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value 0: Invalid 1: Valid When it is invalid, #1 inverter unit cannot control output of RO2, and #2 inverter unit cannot control output of RO1.
  • Page 99 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value When it is 1, if the dual system is running properly, but #2 inverter unit (or #1 inverter unit) encounters a fault, #1 inverter unit (or #2 inverter unit) coasts to stop and displays the fault code of #2 inverter unit (or #1 inverter unit).
  • Page 100 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value power. A positive value indicates electrical driving state, and a negative value indicates electricity generation state. Range: -300.0–300.0% (relative to the motor rated power) This function code displays the present output torque of the VFD, for which 100.0% is relative to...
  • Page 101 Goodrive18 series two-in-one VFD Function parameters and function terminal reuse Function Default Name Description Modify code value AI2 input This function code displays the AI2 input signal. ● P17.20 voltage Range: 0.00–10.00V AI3 input This function code displays the AI3 input signal.

  • Page 102: Function Terminal Reuse

    5.2 Function terminal reuse Goodrive18 series two-in-one VFD is configured with two channels of inverter output. The use of function terminals is more flexible — function terminals can be reused, meeting requirements in different application scenarios. The default configuration of function terminals has been described in section 3.1.8.

  • Page 103: Troubleshooting

    If the VFD is installed in an environment that meets requirements, only a little maintenance workload is needed. The following table describes the routine maintenance periods recommended by INVT. For more detailed information on maintenance, please contact us. Subject Item...
  • Page 104 Goodrive18 series two-in-one VFD Troubleshooting Subject Item Method Criterion damaged, or their color changes due to overheating and aging. No exception occurs. Note: Copper bar Check whether there are Visual decoloring does stains and dust attached. inspection not indicate performance deterioration.
  • Page 105 Goodrive18 series two-in-one VFD Troubleshooting Subject Item Method Criterion Check whether the Use instruments Electrostatic capacity ≥ initial electrostatic capacity is to measure the measured as required. capacity. value * 0.85 Check whether there is Olfactory and No exception displacement caused due to visual inspection occurs.

  • Page 106: Cooling Fan

    Goodrive18 series two-in-one VFD Troubleshooting Subject Item Method Criterion Visual inspection, and Check whether there is determine the No exception electrolyte leakage or service life occurs. deformation. based on the maintenance information. Auditory and visual Check whether there are inspection, and The rotation is unusual sounds or vibration.

  • Page 107: Capacitor

    VFD, as shown in the following figure. Rotation direction direction Figure 6.1 Fan maintenance for Goodrive18 series VFD Step 5 Power on the VFD. 6.1.3 Capacitor 6.1.3.1 Capacitor reforming If the VFD has been left unused for a long time, you need to follow the instructions to reform the DC bus capacitor before the reuse.

  • Page 108: Power Cable

    Otherwise, device damage or physical injuries or even death may result. The electrolytic capacitor inside the VFD must be replaced if the service time exceeds 35,000 hours. For details about the replacement, contact the local INVT office. 6.1.4 Power cable ...

  • Page 109: Fault Handling

    VFD at the last three faults, respectively. You can find out causes and solutions for most of the alarms or faults based on the information provided in this chapter. If you cannot find out the cause of an alarm or fault, contact the local INVT office. 6.2.2 Fault reset The VFD can be reset by pressing the keypad key STOP/RST, through digital input, or by cutting off the VFD power supply.
  • Page 110 Goodrive18 series two-in-one VFD Troubleshooting When both inverter units encounter faults, each inverter unit shows the respective fault. Fault code Fault type Possible cause Solutions ACC overvoltage Check the input power; Check if the DEC time of DEC overvoltage the load is too short or the...
  • Page 111 Goodrive18 series two-in-one VFD Troubleshooting Fault code Fault type Possible cause Solutions The acceleration is too fast; Increase the ACC time; Reset the rotating motor; Avoid the restarting after The voltage of the power stopping; supply is too low; Check the power of the VFD overload The load is too heavy;...
  • Page 112 Goodrive18 series two-in-one VFD Troubleshooting Fault code Fault type Possible cause Solutions The motor capacity does Change the VFD mode; not comply with the VFD Set the rated parameter capability; according to the motor The rated parameter of the name plate;...
  • Page 113 Goodrive18 series two-in-one VFD Troubleshooting Fault code Fault type Possible cause Solutions The keypad is not in good Check the environment and connection or offline; eliminate the interference The keypad cable is too source; Parameter upload long and there is strong...

  • Page 114: Other Status

    Goodrive18 series two-in-one VFD Troubleshooting 6.2.4 Other status Fault code Fault type Possible cause Solutions System power off or low DC Check whether the input P.oFF System power off voltage voltage is normal. -109-...

  • Page 115: Communication

    Goodrive18 series two-in-one VFD Communication 7 Communication 7.1 Modbus protocol introduction Modbus is a software protocol, a common language used in electronic controllers. By using this protocol, a controller can communicate with other devices through transmission lines (such as RS485). It is a general industrial standard. With this standard, control devices produced by different manufacturers can be connected to form an industrial network and be monitored in a centralized way.

  • Page 116: Two-Wire Rs485

    Goodrive18 series two-in-one VFD Communication Otherwise, one of the two communication channels fail. 7.2.1 Two-wire RS485 The two-wire RS485 interface works in half-duplex mode and sends data signals in the differential transmission way, which is also referred to as balanced transmission. The two-wire RS485 interface uses a twisted pair, in which one wire is defined as A (+), and the other B (-).
  • Page 117 Goodrive18 series two-in-one VFD Communication Shielded twisted pair RS485 line 485- 485+ RS 232 – RS485 adapter Figure 7.1 RS485 wiring diagram for the network with one VFD 7.2.1.2 When multiple VFDs are used In the network with multiple VFDs, chrysanthemum connection and star connection are commonly used.

  • Page 118: Rtu Mode

    Goodrive18 series two-in-one VFD Communication Figure 7.3 Star connection Use shielded cable, if possible, in multi-VFD connection. The baud rates, data bit check settings, and other basic parameters of all the devices on the RS485 line must be set consistently, and addresses cannot be repeated.
  • Page 119 Goodrive18 series two-in-one VFD Communication Check Stop Start bit BIT1 BIT2 BIT3 BIT4 BIT5 BIT6 BIT7 In a character frame, only the data bits carry information. The start bit, check bit, and stop bit are used to facilitate the transmission of the data bits to the destination device. In practical applications, you must set the data bits, parity check bits, and stop bits consistently.
  • Page 120 Bit check on individual bytes (odd/even check) You can select the bit check mode as required, or you can choose not to perform the check, which will affect the check bit setting of each byte. Goodrive18 series two-in-one VFD uses the even parity check by default.
  • Page 121 Goodrive18 series two-in-one VFD Communication A frame in the RTU format includes an error detection domain based on the CRC calculation. The CRC domain checks all the content of the frame. The CRC domain consists of two bytes, including 16 binary bits. It is calculated by the sender and added to the frame. The receiver calculates the CRC of the received frame, and compares the result with the value in the received CRC domain.

  • Page 122: Ascii Mode

    Goodrive18 series two-in-one VFD Communication crc_value=crc_value>>1; return(crc_value); In the ladder logic, CKSM uses the table look-up method to calculate the CRC value according to the content in the frame. The program of this method is simple, and the calculation is fast, but the ROM space occupied is large.
  • Page 123 Goodrive18 series two-in-one VFD Communication ASCII data frame format Modbus message Start character: End character: Slave Function Checkout Data “0x3A” address code “0*0D”“0*0A” Standard structure of an ASCII frame: ‘:’ (0x3A) START Address Hi Communication address: An 8-bit address is formed by the combination of two ASCII Address Lo codes.

  • Page 124: Command Codes And Communication Data

    Goodrive18 series two-in-one VFD Communication return((unsigned char)(–((char)uchLRC))); 7.3 Command codes and communication data 7.3.1 RTU mode 7.3.1.1 Command code 03H (0000 0011), reading N words (continuously reading a maximum of 16 words) The command code 03H is used by the master to read data from the VFD. The count of data to be read depends on the "data count"...
  • Page 125 Goodrive18 series two-in-one VFD Communication CMD=03H means the command message is sent to read data from the VFD and CMD occupies one byte. "Start address" means reading data from the address and it occupies two bytes with the MSB on the left and LSB on the right.
  • Page 126 Goodrive18 series two-in-one VFD Communication RTU master command (from the master to RTU slave response (from the VFD to the the VFD) master) address address MSB of to-be-written MSB of to-be-written data data LSB of to-be-written LSB of to-be-written data...
  • Page 127 Goodrive18 series two-in-one VFD Communication can be continuously written. For example, to write 5000 (1388H) to 0004H and 50 (0032H) to 0005H of the VFD whose slave address is 02H, the frame structure is as follows: RTU master command (from the master to the VFD): T1-T2-T3-T4 (time gap with a min.

  • Page 128: Ascii Mode

    Goodrive18 series two-in-one VFD Communication 7.3.2 ASCII mode 7.3.2.1 Command code 03H (0000 0011), reading N words (continuously reading a maximum of 16 words) For example, for the VFD whose slave address is 01H, the start address of internal storage is...
  • Page 129 Goodrive18 series two-in-one VFD Communication ASCII master command (from the master ASCII slave response (from the VFD to the to the VFD) master) ‘0’ ‘0’ MSB of data writing MSB of data writing ‘0’ ‘0’ address address ‘0’ ‘0’ LSB of data writing LSB of data writing ‘4’...
  • Page 130 Goodrive18 series two-in-one VFD Communication ASCII master command (from the master ASCII slave response (from the VFD to the to the VFD) master) ‘A’ ‘A’ LRC CHK Lo LRC CHK Lo END Hi END Hi END Lo END Lo 7.3.2.4 Command code 10H, continuous writing Command code 10H means that the master writes data to the VFD while the number of data pieces depends on the "data count"...

  • Page 131: Data Address Definition

    Goodrive18 series two-in-one VFD Communication ASCII master command (from the master ASCII slave response (from the VFD to the to the VFD) master) ‘1’ LRC CHK Hi ‘7’ LRC CHK Lo END Hi END Lo 7.4 Data address definition This section describes the address definition of communication data. The addresses are used for controlling the running, obtaining the status information, and setting function parameters of the VFD.

  • Page 132: Address Description Of Other Function Codes

    Goodrive18 series two-in-one VFD Communication • Besides, EEPROM is stocked frequently, which may shorten the usage time of EEPROM. For users, some functions are not necessary to be stocked on the communication mode. The needs can be met on by changing the value in RAM. Changing the MSB of the function code form 0 to 1 can also realize the function.
  • Page 133 Goodrive18 series two-in-one VFD Communication Function Address Description forward rotation (0–Fmax (unit: 0.01Hz)) The upper limit frequency setting during 2006H reverse rotation (0–Fmax (unit: 0.01Hz)) The upper limit torque of electromotion torque 2007H (0–3000, 1000 corresponds to the 100.0% of the rated current of the motor) The upper limit torque of braking torque (0–...
  • Page 134 Goodrive18 series two-in-one VFD Communication Function Address Description AO output setting 1 200DH (-1000–1000, 1000 corresponds to 100.0%) AO output setting 2 200EH (-1000–1000, 1000 corresponds to 100.0%) 0001H: forward running 0002H: reverse running 0003H: stop SW 1 of the VFD...
  • Page 135 Goodrive18 series two-in-one VFD Communication Function Address Description Set frequency 3001H 0–Fmax, unit: 0.01Hz communication addresses of GD, Bus voltage 3002H 0.0–2000.0V, unit: 0.1V CHF100A, and CHV100 series Output voltage 3003H 0–1200V, unit: 1V Output current 3004H 0.0–3000.0A, unit: 0.1A...

  • Page 136: Fieldbus Scale

    Goodrive18 series two-in-one VFD Communication only, and "W" indicates that a function code is written only. Note: Some parameters in the preceding table are valid only after they are enabled. Take the running and stop operations as examples, you need to set "Channel of running commands"...

  • Page 137: Error Messages

    Goodrive18 series two-in-one VFD Communication (5.0=50/10). To set "Delay for recovery from hibernation" to 5.0s through Modbus communication, you need first to multiply 5.0 by 10 according to the scale to obtain an integer 50, that is, 32H in the...
  • Page 138 Goodrive18 series two-in-one VFD Communication Error code Name Description value not allowed. The value indicates the error of the remaining structure in the combined request. Note: It does not mean that the data item submitted for storage in the register includes a value unexpected by the program.

  • Page 139: Reading And Writing Examples

    Goodrive18 series two-in-one VFD Communication describes the cause of the exception. After receiving the exception response, the typical processing of the master is to send the request message again or modify the command based on the fault information. For example, to set the "Channel of running commands" (P00.01, the parameter address is...

  • Page 140: Example Of Writing Command 06H

    Goodrive18 series two-in-one VFD Communication ASCII mode The command sent to the VFD is as follows: Read Parameters Data address address command number check If the operation is successful, the following response is returned: Data Byte Read content number check...
  • Page 141 Goodrive18 series two-in-one VFD Communication Parameters Forward Write CRC check address address running command If the operation is successful, the following response is returned (same as the command sent from the master): Parameters Forward Write CRC check address address running...

  • Page 142: Example Of Continuous Writing Command 10H

    Goodrive18 series two-in-one VFD Communication If the operation is successful, the following response is returned (same as the command sent from the master): Write Parameters Forward running CRC check address command address ASCII mode The command sent from the master is as follows:...
  • Page 143 Goodrive18 series two-in-one VFD Communication The command sent from the master is as follows: Continuous Parameters Data Byte Forward 10Hz CRC check writing address address number number running command If the operation is successful, the following response is returned:： Continuous...

  • Page 144: Common Communication Faults

    Goodrive18 series two-in-one VFD Communication Continuous Parameters Data CRC check address writing address number command ASCII mode The command sent from the master is as follows: Continuous Parameters Data writing address check address number command If the operation is successful, the following response is returned:：...

  • Page 145: Appendix A Technical Data

    Goodrive18 series two-in-one VFD Technical data Appendix A Technical data A.1 Derated application A.1.1 Capacity Choose a VFD model based on the rated current and power of the motor. To endure the rated power of the motor, the rated output current of the VFD must be larger or equal to the rated current of the motor.

  • Page 146: Ce Marking

    When the altitude exceeds 2000 m, configure an isolation transformer at the VFD input end. When the altitude is higher than 3000 m but lower than 5000 m, consult INVT for technical issues. It is not recommended that the VFD be used at the altitude higher than 5000 m.
  • Page 147 Goodrive18 series two-in-one VFD Technical data Category II: All environments except those in Category I. VFD categories: C1: Rated voltage lower than 1000 V, applied to enviroments of Category I. C2: Rated voltage lower than 1000 V, non-plug, socket, or mobile devices; power drive...

  • Page 148: Appendix B Dimensional Drawing

    Goodrive18 series two-in-one VFD Dimensional drawing Appendix B Dimensional drawing This chapter provides the dimensions (unit: mm) for Goodrive18 serires two-in-one VFD that is wall mounted. Φ D Figure B.1 Wall mounting drawing Hole diameter VFD model GD18-0R7-4-2 107.5 195.3 164.5...

  • Page 149: Appendix C Optional Peripheral Accessories

    Goodrive18 series two-in-one VFD Optional peripheral accessories Appendix C Optional peripheral accessories This chapter describes how to select optional accessories for Goodrive18 serires two-in-one VFD. C.1 Wiring of peripheral accessories The following figure shows the external wiring of Goodrive18 serires two-in-one VFD.

  • Page 150: Power Supply

    Goodrive18 series two-in-one VFD Optional peripheral accessories Item Name Description RUN/TUNE FWD/REV LOCAL/REMOT TRIP The external keypads include keypads with and External DATA keypad without parameter copying. QUICK SHIFT STOP Cable Accessory for signal transmission. Accessory for electric shock prevention and protection against short-to-ground that may cause current leakage and fire.

  • Page 151: Cables

    Goodrive18 series two-in-one VFD Optional peripheral accessories C.3 Cables C.3.1 Power cables The sizes of the input power cable and motor cable must meet the local regulation. Note: If the conductivity of the motor cableshield layer cannot meet the requirements, separate PE conductors must be used.
  • Page 152 Goodrive18 series two-in-one VFD Optional peripheral accessories Screw specifications Tightening torque (Nm) VFD model U1V1W1/ U1V1W1/ U2V2W2 U2V2W2 GD18-5R5-4-2 2.26 GD18-7R5-4-2 2.26 Figure C.1 Y-type terminal diagram Table C.3 Y-type terminal dimensions Applicable conductor Dφ dφ Terminal cross section model Unit: mm Unit: mm²...
  • Page 153 VFD. If the distance between the VFD and motor is 50 m to 100 m, select the reactor according to the following table. If the distance is longer than 100 m, contact INVT technical support. -148-...
  • Page 154 Goodrive18 series two-in-one VFD Optional peripheral accessories Input reactor Output reactor VFD model Input reactor Output reactor GD18-0R7-4-2 ACL2-1R5-4 OCL2-1R5-4 GD18-1R5-4-2 ACL2-004-4 OCL2-1R5-4 GD18-2R2-4-2 ACL2-004-4 OCL2-2R2-4 GD18-004-4-2 ACL2-7R5-4 OCL2-004-4 GD18-5R5-4-2 ACL2-011-4 OCL2-5R5-4 GD18-7R5-4-2 ACL2-015-4 OCL2-7R5-4 Note:  The rated input voltage drop of input reactors is 2%±15%.
  • Page 155 FLT-P04016L-B GD18-2R2-4-2 FLT-P04016L-B GD18-004-4-2 FLT-P04032L-B GD18-5R5-4-2 FLT-P04032L-B GD18-7R5-4-2 FLT-P04045L-B The preceding table lists external accessories. You need to specify the ones you choose when purchasing accessories. If you need C2 filters, consult INVT technical personnel for detailed configuration solutions. -150-...
  • Page 156 D.1 Product and service queries If you have any queries about the product, contact the local INVT office. Provide the model and serial number of the product you query about. You can visit www.invt.com to find a list of INVT offices.
  • Page 157 E-mail: overseas@invt.com.cn Website: www.invt.com The products are owned by Shenzhen INVT Electric Co.,Ltd. Two companies are commissioned to manufacture: (For product code, refer to the 2nd/3rd place of S/N on the name plate.) INVT Power Electronics (Suzhou) Co.,Ltd. (origin code: 06) Shenzhen INVT Electric Co.,Ltd.

This manual is also suitable for:

Gd18-0r7-4-2Gd18-1r5-4-2Gd18-2r2-4-2Gd18-004-4-2Gd18-5r5-4-2Gd18-7r5-4-2

Table of Contents
