Goodrive18 series two-in-one VFD
Function
Name
code
Polarity
P05.10 selection of the
input terminals
P05.11 Switch filter time This function code is used to set the filter time of 0.010s
Function parameters and function terminal reuse
29: Torque control prohibition
30: ACC/DEC prohibition
31: Counter trigger
32: Reserved
33: Cancel the frequency change setting
temporarily
34: DC brake
35: Reserved
36: Shift the command to the keypad
37: Shift the command to the terminals
38: Shift the command to the communication
39: Pre-magnetized command
40: Clear the power consumption
41: Keep the power consumption
42: Emergency stop
43–60: Reserved
61: PID pole switching
62–63: Reserved
When terminals use the ACC/DEC time selection
function, it is required to select four groups of
ACC/DEC time via state combination of these
two terminals.
Tml1 Tml2
OFF OFF
ON OFF
OFF O N
ON ON
This function code is used to set the polarity of
the input terminals.
When the bit is 0, the input terminal is anode.
When the bit is 1, the input terminal is cathode.
BIT8 BIT7
S8
BIT3 BIT2
S4 S3
Setting range: 0x000–0x1FF
-54-
Description
ACC/DEC Function code
ACC/DEC time1 P00.11/P00.12
ACC/DEC time2 P08.00/P08.01
ACC/DEC time3 P08.02/P08.03
ACC/DEC time4 P08.04/P08.05
BIT6 BIT5
S7 S6
BIT1 BIT0
S2 S1
Default
value
BIT4
0x000
S5
Modify
○
○
