- Page 1 ® R&S ZN-Z15x Calibration Units User Manual (=UÉÍ2) 1337596302 Version 03...
- Page 2 This User Manual describes the following R&S ZN-Z15x models: ● R&S ® ZN-Z150, N (f), 2 ports, 5 kHz to 6 GHz (1335.6710.72) ● R&S ® ZN-Z151, SMA (f), 2 ports, 100 kHz to 8.5 GHz (1317.9134.32) ● R&S ® ZN-Z151, N (f), 2 ports, 100 kHz to 8.5 GHz (1317.9134.72) ●...
- Page 3 ® Contents R&S ZN-Z15x ESD Protective Measures Contents 1 Safety Instructions..............3 2 Introduction................5 3 Establishing the USB Connection........6 4 Function of the Status LED...........6 5 Performing an Automatic Calibration........7 6 User Characterization............8 7 Mounting the Calibration Unit..........8 Safety Instructions General safety considerations This calibration unit has been designed and tested in accordance with the...
- Page 4 ® Safety Instructions R&S ZN-Z15x RF Connections USB Connection The calibration unit is equipped with a 5 pin ruggedized (R&S ZN-Z156) or a USB Type-B connector at the rear. The USB connection is used to power-supply and ® ® control the unit from a network analyzer of the R&S ZVx or R&S ZNx family.
- Page 5 ® Introduction R&S ZN-Z15x microSD Card On the rear of the R&S ZN-Z152 and R&S ZN-Z153 calibration units, there is a microSD card slot. The microSD card can be used to store user characterization data. The factory data is always stored on the internal memory. ●...
- Page 6 ® Establishing the USB Connection R&S ZN-Z15x Establishing the USB Connection To establish the USB connection between calibration unit and network analyzer, proceed as follows: 1. Switch on and start up your network analyzer. 2. Connect the USB Type-A connector of the USB cable to any of the USB Type- A connectors on the front or rear panel of the analyzer.
- Page 7 ® Performing an Automatic Calibration R&S ZN-Z15x Performing an Automatic Calibration Once the USB connection between calibration unit and network analyzer has been established, an automatic calibration can be performed as follows: 1. Start the automatic calibration function of your network analyzer. 2.
- Page 8 ® User Characterization R&S ZN-Z15x User Characterization The calibration unit offers the possibility to store multiple user characterization data files either on its internal flash memory or on the microSD card (R&S ZN- Z152, R&S ZN-Z153). Use the "Characterize Cal Unit" function of your network analyzer for this purpose.
