WCS position encoding system
Mounting the Code Rail
Read Head with WCS3 Profile Rail
1. WCS3 profile system with rail holder mounted on C profile rail, with read head
2. WCS3 profile system with rail holder mounted on C profile rail, with outdoor protective en-
closure
Rail Holder Overview
Figure 6.11
Item
1
2
3
Note
Support distance for perpendicular/suspended mounting: < 2.5 m.
Support distance for lateral mounting: < 2 m.
44
90
1
32
1
32
Overview
Designation
Rail holder
Rail holder with screw connection
Rail holder with screw connection for C profile rails
M12
2
32
M12
119
2
32
3
32
Product name
WCS3-MH
WCS3-MH1
WCS3-MH2
