42,000 Lm - Cart Mount - Quick Change Mount - C1D1 - 100' 12/3 SOOW -
Thank you for your purchase of the Larson Electronics EPL-QC-16C-2X150LED-RT-X24V-C1D1-12.3-100-EPP.
)
WARNING:
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CRITICAL SAFETY INSTRUCTIONS:
•
INSTALLATION SHOULD ONLY BE CONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY
RELEVANT LOCAL BUILDING CODES.
•
RISK OF FIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL
SYSTEMS. IF NOT QUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.
BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•
MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.
•
TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP
•
OBJECTS. SUITABLE FOR DAMP LOCATIONS.
IMPORTANT
READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. THE EPL-QC-16C-2X150LED-RT-X24V-C1D1-12.3-100-EPP MUST BE WIRED IN ACCORDANCE WITH
NATIONAL ELECTRICAL CODE AND ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR
SAFETY.
WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS
PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,
CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
RISK OF FIRE/ELECTRIC SHOCK –
RISK OF PERSONAL INJURY –
RISK OF BURN –
ALLOW FIXTURE TO COOL BEFORE SERVICING.
WARNING:
USER SHOULD BE TRAINED IN THE PROPER USE AND MAINTENANCE OF THIS DEVICE.
CORD IS INTENDED TO ALLOW OPERATORS TO EXTEND POWER TO EQUIPMENT WHEN STATIONARY OUTLETS ARE NOT
READILY AVAILABLE.
IMPROPER USE OF THIS CORD, PLUG, AND RECEPTACLE CAN LEAD TO SERIOUS INJURIES OR DEATH TO
PERSONNEL.
PERIODIC INSPECTION OF THE CORD IS NECESSARY.
THE CORD MUST BE ROUTINELY CHECKED FOR CUTS, BREAKS, OR ANY SEVERE ABRASIONS, AND IF ANY ARE FOUND,
THE CORD MUST BE REPLACED BEFORE RESUMING USE.
Larson Electronics, LLC
300W EXP LED Light
Instruction Manual
DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.
FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.
Phone: (800) 369-6671
EPL-QC-16C-2X150LED-RT-X24V-C1D1-12.3-100-EPP
Inline
Fax: (903) 498-3364
www.larsonelectronics.com
THIS LINE
1 of 5
Advertisement
Table of Contents
Related Manuals for Larson Electronics EPL-QC-16C-2X150LED-RT-X24V-C1D1-12.3-100-EPP
Summary of Contents for Larson Electronics EPL-QC-16C-2X150LED-RT-X24V-C1D1-12.3-100-EPP
- Page 1 42,000 Lm - Cart Mount - Quick Change Mount - C1D1 - 100' 12/3 SOOW - Inline Instruction Manual Thank you for your purchase of the Larson Electronics EPL-QC-16C-2X150LED-RT-X24V-C1D1-12.3-100-EPP. WARNING: READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
- Page 2 The EPL-QC-16C-2X150LED-RT-X24V-C1D1-12.3-100-EPP Portable Explosion Proof LED Tank Light with Wheelbarrow Cart from Larson Electronics produces 42,000 lumens of light capable of illuminating an area 20,000 square feet in size. This adjustable Cree LED unit is designed for maximum portability and durable, versatile operation. This unit is part of the QC Series, providing a quick disconnect mounting system and compatibility with several additional mounting solutions.
- Page 3 Electronics addresses this issue with the Iron X series with field serviceability, allowing operators to perform service work without having to return the fixture to the manufacturer in the event of damage or failure. 3 of 5 Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364...
- Page 4 QUICK CHANGE MOUNTING SYSTEM The Quick Change (QC Series) mounting system from Larson Electronics features an innovative quick change design platform, allowing operators to quickly mount and dismount the light head assembly from the mounting base. To mount a QC Series compatible light fixture, operators simply slide the male end mounting section of the light assembly into the female end mounting section on the mounting base, then tighten the locking ring to ensure the light assembly has been secured.
- Page 5 Should the need for replacement parts arise, please contact Larson Electronics. THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS. SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT SALES@LARSONELECTRONICS.COM OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.
