- Page 1 USER MANUAL SPEED DOME CAMERAS SD-xxx-5 Page: 1 SD-xxx-5 SERIES Cameras motorized AHD / analog WWW.DSE.EU...
- Page 2 Control of PTZ cameras cameras. They allow an operator to rotate the camera The speed-dome cameras can be controlled with special in all directions and zoom in on the most interesting control consoles or through DSE digital video recorders. scenes desired. They...
-
Page 3: Installing The Camera
SPEED DOME CAMERAS SD-xxx-5 Page: 3 INSTALLING THE CAMERA The SD series cameras are carefully packed to prevent to 1200 meters in length and the devices are connected damage during transport. First of all, it is necessary to in cascade along it. The section of the cables strictly check the material received. - Page 4 DEVICE ID It proceeds as follows: 1 - Call PRESET 95 to open the OSD menu WWW.DSE.EU...
- Page 5 7 - Exit with the left arrow several times Once the protocol address or speed has been changed, the camera will no longer respond to commands and it will be necessary to change the settings of the control unit in a manner consistent with the new settings. WWW.DSE.EU...
-
Page 6: Wall Mounting
Call preset 138 twice Double call preset 139 Wall mounting The SD series speed dome cameras are equipped with a bracket for wall mounting. The camera cable in this Connect the camera and fix it to the bracket with case must pass through the bracket. In the photos that the screws provided. -
Page 7: Basic Operations
Consult the documentation attached to the control unit for the exact sequence to be composed. Automatic movements The cameras can perform automatic movements such Manual ZOOM command as panoramic scans or preposition sequences. The setting of these movements is carried out in the WWW.DSE.EU... - Page 8 USER MANUAL SPEED DOME CAMERAS SD-xxx-5 Page: 8 programming menu which is described below. These movements are started with the commands of the control unit or using the system presets. WWW.DSE.EU...
-
Page 9: System Preset
CALL Set up AHD video Call the preset twice to set the video signal in AHD, used by 2 times DSE DVR CALL Set TVI video Call the preset twice to set the TVI video signal, used by 2 times... - Page 10 System PRESET 95. Typically, you must first select the address of the camera you want to program, then type 95 and then press CALL or PREVIEW or GO TO (consult the console manual on how to recall a preset) WWW.DSE.EU...
- Page 11 ILLUMINATION ON - It is the activation threshold reduction with zooming in of the LEDs on a scale from 0 to 15 AUTOFLIP - It must be enabled if during the vertical movement (TILT) the camera, when it reaches the vertical position, rotates 180 ° and WWW.DSE.EU...
- Page 12 IRIS - Sets the aperture of the camera to CAM DATA - Restore factory settings of the automatic or manual. camera module BLC - Enables backlight compensation for shooting PRESET - Delete all presets a dark subject against a light background. WWW.DSE.EU...
- Page 13 ADJUST -in this section the following parameters settings. are set: To exit the camera menu go to SAVE & END and recall NR: Digital Noise Reduction is a digital video preset 102 twice to exit. noise reduction function. Thanks to this function, WWW.DSE.EU...
- Page 14 Time) and NRT (Non Real Time) for maximum resolution VIDEO OUT: It is possible to choose between European PAL format and NTSC US format APPLY SET: Closes the menu by saving the settings RETURN: Return to the main menu WWW.DSE.EU...
