EA242F
Monitor Specifications
LCD Module
Viewable Image Size:
Input Signal
VNA:
DisplayPort:
DisplayPort Connector:
HDMI:
Output Signal
DisplayPort:
DisplayPort Connector: Digital RNB
Display Colors
Synchronization Range
Viewing Angle
Response Time
Active Display Area
USB Hub
AUDIO
AUDIO Input:
STEREO Mini Jack:
DisplayPort Connector:
USB-C Port (DisplayPort Alt. Mode):
Headphone Output: STEREO Mini Jack:
Speakers
Practical Audio Output: 1.0 W + 1.0 W
ControlSync
(available up to 5 sub monitors)
Power Supply
Current Rating
Dimensions
Stand adjustable range
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
NOTE:
Technical specifications are subject to change without notice.
MultiSync EA242F
Diagonal:
60.47 cm/23.8 inches
60.47 cm/23.8 inches
Native Resolution:
1920 x 1080 60 Hz
Mini D-Sub 15-pin: Analog RNB
Sync
Digital RNB
USB-C Port:
Digital RNB
HDMI Connector: Digital RNB/YUV
16777216
Horizontal:
31.5 kHz to 83.0 kHz
Vertical:
50 Hz to 75 Hz
Left/Right:
±89° (CR > 10)
Up/Down:
±89° (CR > 10)
6 ms (Nray to Nray Typ.)
Landscape: Horiz.:
527.0 mm/20.7 inches
Vert.:
296.5 mm/11.7 inches
Portrait: Horiz.:
296.5 mm/11.7 inches
Vert.:
527.0 mm/20.7 inches
I/F:
SuperSpeed USB (USB 3.1 Nen 1)
Port:
Upstream 2 (USB-C Port)
Downstream 3
Load Current:
Downstream Port: 5V/0.9A (Max.)
USB-C Port: 65 W (Max.)
Analog Audio
Digital Audio
Digital Audio
HDMI Connector:
Digital Audio
IN:
Stereo Micro jack 2.5
OUT:
Stereo Micro jack 2.5
AC 100-240 V, 50/60 Hz
1.40 - 0.70 A
Landscape:
537.7 mm (W) x 336.2 - 486.2 mm (H) x 250.0 mm (D)
21.2 inches (W) x 13.2 - 19.1 inches (H) x 9.8 inches (D)
Portrait:
319.1 mm (W) x 555.4 - 615.4 mm (H) x 250.0 mm (D)
12.6 inches (W) x 21.9 - 24.2 inches (H) x 9.8 inches (D)
150 mm/5.91 inches (Landscape orientation)
60 mm/2.36 inches (Portrait orientation)
Tilt / Pivot / Swivel:
Up 35° Down 5° / ± 90° / 340°
7.0 kg (15.4 lbs) (with monitor stand)/4.5 kg (9.9 lbs) (without monitor stand)
5°C to 35°C/41°F to 95°F
Humidity:
20 % to 80 %
Altitude:
0 to 16,404 Feet/0 to 5,000 m
-10°C to 60°C/14°F to 140°F
Humidity:
10 % to 85 %
Altitude:
0 to 40,000 Feet/0 to 12,192 m
Notes
Active matrix; thin film transistor (TFT) liquid crystal
display (LCD); 0.275 mm (H) x 0.275 mm (V) dot pitch;
250 cd/m
white luminance; 1000:1 contrast ratio (typical),
2
(5000:1 Contrast ratio, Dynamic).
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
Composite sync.TTL level Positive/Negative
Sync on Nreen (Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
Up to 1920 x 1080 60 Hz, 8 bit, DisplayPort V1.2 (HDCP 1.3)
Up to 1920 x 1080 60 Hz, 8/10 bit, DisplayPort V1.2
(HDCP 1.3)
Up to 1920 x 1080 60 Hz, HDMI (HDCP 1.4)
DisplayPort Complies with Standard V1.2, applicable to HDCP
Depends on display card used.
Automatically
Automatically
Stereo L/R 500mV rms 20 Kohm
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
Headphone Impedance 32 Ohm
φ
φ
English−36
