Desktop Monitor
MultiSync EA244UHD
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for NEC MultiSync EA244UHD-BK

Summary of Contents for NEC MultiSync EA244UHD-BK

  • Page 1 Desktop Monitor MultiSync EA244UHD User’s Manual...

  • Page 2: Table Of Contents

    Index Warning, Caution ..........................English-1 Registration Information .......................English-2 Recommended use ........................English-3 Contents ............................English-5 Quick Start ............................English-6 Controls ............................English-11 Using the PICTURE MODE function ....................English-19 Specifi cations ..........................English-20 Features ............................English-21 Troubleshooting ..........................English-22 Using Multi Picture Function ......................English-24 Using the Zoom Function ......................English-26 Using the Auto Brightness function ....................English-28 ControlSync ..........................English-29 DisplayPort compatibility for 3840 x 2160 resolution ..............English-30...
  • Page 3 This product can only be serviced in the country where it was purchased. Windows is a registered trademark of Microsoft Corporation. NEC is a registered trademark of NEC Corporation. ErgoDesign is a registered trademark of NEC Display Solutions, Ltd. in Austria, Benelux, Denmark, France, Germany, Italy, Norway, Spain, Sweden, U.K.

  • Page 4: Registration Information

    This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. U.S. Responsible Party: NEC Display Solutions of America, Inc. Address: 500 Park Boulevard, Suite 1100 Itasca, Illinois 60143 Tel.

  • Page 5: Recommended Use

    NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
  • Page 6 CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE FOLLOWING WHEN YOU POSITION THE MONITOR: • For optimum performance, allow 20 minutes for the display to warm up. • Adjust the monitor height so that the top of the screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen.

  • Page 7: Contents

    Contents Your new NEC monitor box* should contain the following: • MultiSync monitor with tilt/swivel/pivot/height adjust stand • Power Cord* • Video Signal Cable (DisplayPort cable) • USB Cable* • ControlSync Cable (ø 2.5 stereo micro plug) • Setup Manual.

  • Page 8: Quick Start

    Quick Start To connect the LCD monitor to your system, follow these instructions: NOTE: Make sure to read “Recommended Use” (page 3) before installation. 1. Turn off the power of your computer. 2. For a PC with DisplayPort output: Connect the DisplayPort cable to the connector of the display card in your system (Figure A.1).
  • Page 9 5. To keep the cables neatly organized, place them into the cable management system that is built into the stand. Place the cables in the hooks fi rmly and evenly (Figure C.2 and Figure C.3). NOTE: Cable cover is not removable. 6.
  • Page 10 Raise and Lower Monitor Screen The monitor may be raised or lowered in either portrait or landscape mode. To raise or lower screen, place a hand on each side of the monitor and lift or lower to the desired height (Figure RL.1). NOTE: Handle with care when raising or lowering the monitor screen.
  • Page 11 Flexible Arm Installation This LCD monitor is designed for use with a fl exible arm. To prepare the monitor for alternate mounting purposes: • Follow the instructions provided by the manufacturer of the display mount. • To meet the safety requirements, the mounting stand must be able to support the weight of the monitor and be UL-certifi ed. Remove Monitor Stand for Mounting To prepare the monitor for alternate mounting purposes: 1.
  • Page 12 Mount Flexible Arm This LCD monitor is designed for use with a fl exible arm. 1. Follow the instructions on how Remove Monitor Stand for Mounting to remove the stand. 2. Use the 4 screws removed from the stand to attach the arm to the monitor (Figure F.1). Caution: Use ONLY the screws (4 pcs) that were removed from the stand to avoid damage to the monitor or stand.

  • Page 13: Controls

    Controls OSD (On-Screen Display) control keys on the front of the monitor function are as follows: To access OSD menu, touch any of the control keys. To change signal input, touch the SELECT key. NOTE: Exit OSD in order to change signal input. 1 Ambient Light Sensor Detects the level of ambient lighting and the presence of a user, allowing the monitor to Human Sensor...
  • Page 14 ECO TOOLS BRIGHTNESS Adjusts the overall image and background screen brightness. If ECO MODE is set to 1 or 2, a bar for CARBON FOOTPRINT will appear. CONTRAST Adjusts the overall image and background screen brightness by input signal level. ECO MODE Decreases the amount of power consumption by reducing the brightness level.
  • Page 15 HUMAN SENSING The sensor on the front side of the monitor detects the movement of a person by using the HUMAN SENSING function. The HUMAN SENSING has three settings: OFF: No human sensing. 1 (LIGHT): After it is detected that there is no person after a period of time, the monitor shifts to low brightness mode automatically to reduce the power consumption.
  • Page 16 EXPANSION Sets the Zoom method. FULL: The image is expanded to full screen regardless of the resolution. ASPECT: The image is expanded without changing the aspect ratio. OFF: The image is not expanded. NOTE: FULL works only when MULTI PICTURE is OFF. RESPONSE IMPROVE Turns the Response Improve function on or off.
  • Page 17 SOUND INPUT This function selects AUDIO INPUT, HDMI or DISPLAYPORT. NOTE: According to the screen type, you can change which audio input signal is routed through the built-in speakers. 1 screen (MULTI PICTURE is OFF): Outputs the audio signal from HDMI, DisplayPort or the audio from the input audio jack (AUDIO INPUT).
  • Page 18 PICTURE PATTERN Selects split screen mode. You can select up to 4 split screen types. NOTE: This function is only available when MULTI PICTURE is “ON”. Only 2 split screen mode, you can choose AUTO or CENTER display mode. 2 split screen (CENTER) Splits 2 screens divided evenly from the center.
  • Page 19 MENU Tools LANGUAGE Selects the language used by the OSD. OSD TURN OFF The OSD control menu will stay on as long as it is in use. You can select how long the monitor waits after the last touch of a key to shut off the OSD control menu. The preset choices are 10-120 seconds by 5-second increments. OSD LOCK OUT This control completely locks out the access to all OSD control functions except for Brightness, Contrast and Volume.
  • Page 20 ECO Information CARBON SAVINGS: Displays the estimated carbon savings information in kg. CARBON USAGE: Displays the estimated carbon usages information in kg. This is the arithmetic estimation, not actual measurement value. COST SAVINGS: Displays the electricity cost savings in balance. CARBON CONVERT SETTING: Adjusts the carbon footprint factor in the carbon saving calculation.

  • Page 21: Using The Picture Mode Function

    Medical settings for X-ray imaging view. Setting that conforms to the DICOM simulation for the Grayscale Standard Display Function. PROGRAMMABLE For the Hardware Calibration settings by NEC Display Solutions software (some OSD settings are disabled). NOTE: When the selected PICTURE MODE is different from your computer’s ICC color profi le, you may experience inaccurate color reproduction.

  • Page 22: Specifi Cations

    1920 x 1080 @ 60 Hz (DVI-D) 2560 x 1440 @ 60 Hz 3840 x 2160 @ 30 Hz (HDMI) 3840 x 2160 @ 60 Hz (DisplayPort)....NEC DISPLAY SOLUTIONS cites recommended. Active Display Area Landscape: Horiz.: 527.0 mm/20.7 inches Vert.:...

  • Page 23: Features

    - conversion factor is based on OECD publication of global CO2 emissions 2008 Edition). This monitor has a manufacturing carbon footprint of approximately 34.6 kg. Note: The manufacturing and operating carbon footprints are calculated by a unique algorithm developed exclusively by NEC for its monitors.

  • Page 24: Troubleshooting

    NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
  • Page 25 No Video • If no video is present on the screen, turn the Power button off and on again. • Make certain the computer is not in a power-saving mode (touch the keyboard or mouse). • Some display cards do not output video signal when monitor is turned OFF/ON or disconnect/connect from the AC power cord under low resolution with DisplayPort.

  • Page 26: Using Multi Picture Function

    Using Multi Picture Function This monitor can display up to 4 split screens for 6 input signals. NOTE: Please see MULTI PICTURE (page 15), PICTURE PATTERN (page 16) and ACTIVE PICTURE (page 16). The following settings are set to be the same for all screens: BRIGHTNESS, OFF MODE SETTING, HUMAN SENSING, VIDEO LEVEL, OVER SCAN, PROGRAMMABLE, VOLUME, SOUND INPUT, VIDEO DETECT, MULTI PICTURE, PICTURE PATTERN, ACTIVE PICTURE, RESPONSE IMPROVE, OFF TIMER, POWER SAVE TIMER, LED BRIGHTNESS, DDC/CI, USB POWER,...
  • Page 27 4. Select ACTIVE PICTURE and choose the adjutable screen. Touch SELECT. 5. Set the input signal shown on the key guide. The adjustable screen is shown on the top of key guide. Then set other settings for the screen. NOTE: If the OSD menu may disappear, touch MENU to show OSD menu.

  • Page 28: Using The Zoom Function

    Using the Zoom Function Allows you to use the entire screen area, signifi cantly expanding the size. Allows the picture displayed in the center to expand. NOTE: When in MULTI PICTURE, the sub picture is expanded or reduced automatically. SETUP 1.
  • Page 29 B. The left image is set to be the main one. In this case, the priority image is set to be on the left side. The size of the image on the right side with black area is reduced. To enlarge the split images: use the following procedures to reduce the black area and enlarge the split images. 1.

  • Page 30: Using The Auto Brightness Function

    Using the Auto Brightness function The brightness of the LCD screen can be set to increase or decrease depending on the amount of ambient lighting within the room. If the room is bright, the monitor becomes correspondingly bright. If the room is dim, then the monitor will dim accordingly. The purpose of this function is to make the viewing experience more comfortable to the eye in a variety of lighting conditions.

  • Page 31: Controlsync

    ControlSync 1. Connect the master monitor with a sub monitor via a ControlSync cable (ø 2.5) into ControlSync IN/OUT. 2. Follow the steps of DATA COPY. When the setting of the master monitor is adjusted, it will be copied and sent to the connected sub monitor(s) automatically.

  • Page 32: Displayport Compatibility For 3840 X 2160 Resolution

    6. Reboot computer. NOTE: NEC has noted that some higher resolution DisplayPort signals can occasionally become unreliable. The typical symptom is that no image is displayed or the image is corrupted. The described OSD menu option offers additional fi rmware processing for DisplayPort signals to optimize the native resolution support and therefore improve signal reliability.

  • Page 33: Tco Certifi Ed Edge Displays 1.2

    TCO Certifi ed Edge Displays 1.2 Congratulations! This product is TCO Certifi ed – for Sustainable IT TCO CertiÞ ed is an international third party sustainability certiÞ cation for IT products. TCO CertiÞ ed ensures that the manufacture, use and recycling of IT products reß...

  • Page 34: Manufacturer's Recycling And Energy Information

    Dedicated recycling sites ensure that environmentally harmful components are properly handled and securely disposed. To ensure the best recycling of our products, NEC DISPLAY SOLUTIONS offers a variety of recycling procedures and gives advice on how to handle the product in an environmentally sensitive way, once it has reached the end of its life.
