M-system Sentronic Mini-M M2XPA3 Series Manual page 5

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM
1
4
INPUT * 1
5
8
CONFIGURATOR JACK
*1. Input Connection Examples
Open Collector
or Mechanical Contact
+ 1
–
4
–
PWR
+
5
5kΩ
2-Wire Current Pulse
• Built-in Excitation
100Ω
4
+
5
2-WIRE
PICK-UP
–
8
EXPLANATIONS OF TERMS
Low-end cutout:
The function where the output signal is forced to 0% below the setpoint input. Hysteresis is fixed at 1%.
[Example] Input zero frequency 0 Hz
Input span frequency 1 kHz
Low-end cutout 10 %
OUTPUT
0% 10% 11%
0 Hz 100 Hz 110 Hz
