Super-mini Signal Conditioners Mini-M Series
FREQUENCY TRANSMITTER
(PC programmable)
Functions & Features
• Converts the output from a pulse-type transducer into a
standard process signal
• PC programmable
• Sensor excitation
• Direct RS-422 input
• CE marking
• UL approval
Typical Applications
• Positive displacement flowmeters, turbine flowmeters and
vortex flowmeters
• Measuring rotation speed of a machine generating dry
contact signals
23 (.91)
76
(2.99)
124
(4.88)
mm (inch)
MODEL: M2XPA3-[1][2][3]-[4][5]
ORDERING INFORMATION
• Code number: M2XPA3-[1][2][3]-[4][5]
Specify a code from below for each [1] through [5].
(e.g. M2XPA3-A14Z1-R/CE/Q)
• Specify the specification for option code /Q
(e.g. /C01/S01)
• Non-specified orders will be shipped at the default factory
settings as shown in below. However, a power suffix code
must be specified.
If you specify a full code number without specific calibration
ranges, the input and output ranges are factory set to the
default range.
Use Ordering Information Sheet (No. ESU-5104).
[Factory default setting]
PARAMETER: DEFAULT
Input type: Open collector
Input amplitude: ----
Pulse sensing: DC coupled
Noise filter: None
SEN TRONIC
AG
Produkte, Support und Service
Detecting level: 2 V
Frequency range: 0 – 200 kHz
Input zero frequency: 0 Hz
Input span frequency: 100 kHz
Linearization: No linearization
Low-end cutout: 0 % (No cutout)
Moving averaging samples: 1
Sensor excitation: 12 V DC / 20 mA
Output type: DC current
Output 0%: 4mA
Output 100%: 20mA
[1] INPUT
A1: Open collector
A2: Mechanical contact
B: Voltage pulse
G: Two-wire current pulse
J: RS-422 line driver pulse
Configurator software is used to change the frequency
range. The input type can be switched to other than the one
of the selected suffix code by selecting the input type
selectors inside the unit before software adjustment.
[2] EXCITATION
2: 4 V DC / 20 mA
3: 8 V DC / 20 mA
4: 12 V DC / 20 mA
Configurator software is used to change the excitation
value.
[3] OUTPUT
Current
Z1: Range 0 – 20 mA DC
Voltage
V1: Range -2.5 – +2.5 V DC
V2: Range -10 – +10 V DC
(Configurator software is used to adjust the output range
and to change the output over the described range of the
selected suffix code.)
[4] POWER INPUT
AC Power
M2: 100 – 240 V AC (Operational voltage range 85 – 264 V,
47 – 66 Hz)
(90 – 264 V for UL)
DC Power
R: 24 V DC
(Operational voltage range 24 V ±10 %, ripple 10 %p-p max.)
P: 110 V DC
(Operational voltage range 85 – 150 V, ripple 10 %p-p max.)
Rugghölzli 2
Tel. +41 (0)56 222 38 18
CH - 5453 Busslingen
Fax +41 (0)56 222 10 12
MODEL: M2XPA3
mailbox@sentronic.com
www.sentronic.com
