(110 V ±10 % for UL)
[5] OPTIONS (multiple selections)
Standards & Approvals (must be specified)
/N: Without CE or UL
/CE: CE marking
/UL: UL approval, CE marking
Other Options
blank: none
/Q: Option other than the above (specify the specification)
(UL not available)
SPECIFICATIONS OF OPTION: Q (multiple selections)
COATING (For the detail, refer to M-System's web site.)
/C01: Silicone coating
/C02: Polyurethane coating
/C03: Rubber coating
TERMINAL SCREW MATERIAL
/S01: Stainless steel
RELATED PRODUCTS
• JX configurator connection kit (model: JXCON)
GENERAL SPECIFICATIONS
Construction: Plug-in
Connection: M3 screw terminals (torque 0.8 N·m)
Housing material: Flame-resistant resin (black)
Isolation: Input to output to power
Overrange output: Approx. -15 to +115 % at 1 – 5 V
Zero adjustment: -5 to +5 % (front)
Span adjustment: 95 to 105 % (front)
Configuration: Via PC Configurator Software (model: JXCON)
on the Windows PC connected to the front jack.
Programmable features include:
· I/O type and range
· Detecting level
· Sensor excitation
· Zero and span adjustments
· Low-end cutout
· Linearization
· Sample number for the moving average
DIP switch settings:
• Input Type
• Pulse Sensing (Capacitor coupled, DC coupled)
• Noise Filter (High, Low, None)
Status indicator LED: Flashing patterns indicate different
operating status of the transmitter.
Excitation adjustment: 4 V, 8 V or 12 V DC
Configurator connection: 2.5 dia. miniature jack;
RS-232-C level
SEN TRONIC
AG
Produkte, Support und Service
Low-end cutout: 0 – 115 % programmable;
No cutout with 0 % setting; hysteresis fixed at 1 % (factory
set to: No cutout)
INPUT SPECIFICATIONS
Excitation: Shortcircuit protection; 30 mA max. at
shortcircuit
Frequency ranges:
0 – 10 mHz, 0 – 100 mHz, 0 – 1 Hz, 0 – 10 Hz, 0 – 100 Hz,
0 – 1 kHz, 0 – 10 kHz, 0 – 200 kHz
(up to 10 Hz for mechanical contact)
Minimum pulse width time requirement: 2.5 μsec. for both
ON and OFF. (50 msec. for mechanical contact)
Minimum span: 10 % of the selected frequency range
(5 % of the selected frequency range when the range is
0 – 200 kHz.)
Noise filter: See table 2
Choose the noise filter type appropriate for the selected
frequency range to ensure the described accuracy.
■ Open Collector & Mechanical Contact
Input requirements
EXC
4V
Approx. 3V/0.7mA
8V
Approx. 6V/1.5mA
12V
Approx. 9V/2.3mA
Detecting level:
0.6 V (4 V excitation)
2 V (8 V / 12 V excitation)
If not specified, the input range is shown below.
A1 Open collector: 0 – 100 kHz
A2 Mechanical contact: 0 – 10 Hz
■ Voltage Pulse
Waveform: Square or sine
Input impedance: ≥ 10 kΩ
Input amplitude: Min. 0.1 Vp-p, max. 100 Vp-p
Max. voltage between input terminals: See table 1.
Detecting levels: -2 – +4 V (internal detecting voltage)
If not specified, the input range is 0 – 100 kHz.
■ Two-wire Current Pulse
Input resistance: Receiving resistor 100 Ω
Input range: 0 – 25 mA
Input amplitude: Min. 10 mAp-p, max. 25 mAp-p
Detecting levels: -2 – +4 V (internal detecting voltage)
If not specified, the input range is 0 – 100 kHz.
■ RS-422 Line Driver Pulse
Receiver: Conforms to RS-422
If not specified, the input range is 0 – 100 kHz.
Rugghölzli 2
Tel. +41 (0)56 222 38 18
CH - 5453 Busslingen
Fax +41 (0)56 222 10 12
MODEL: M2XPA3
SENSING
OFF
≥2kΩ/1V
≥4kΩ/3V
≥2kΩ/3V
mailbox@sentronic.com
ON
≤200Ω/0.2V
≤600Ω/1V
≤400Ω/1V
