a digital processor, and therefore they do not interact.
However, if ZERO value is changed, repeat the above
procedure 1) – 3).
CHANGING I/O TYPE & RANGE
n LEFT SIDE VIEW (with cover removed)
Input type and range, and output type and range can be
n DIP SWITCH SETTINGS
• Input Type
INPUT
Open collector
Mechanical contact
Voltage pulse
Two-wire current pulse
RS-422 line driver pulse
• Pulse Sensing
SENSING
Capacitor coupled
DC coupled
• Noise Filter
FILTER
High
Low
None
