for FlexPak Plus and MinPak Plus DC Drives
ATTENTION: Only qualified electrical personnel familiar with the construction and operation of
this equipment and the hazards involved should install, adjust, operate, and/or service this
!
equipment. Read and understand this manual and other applicable manuals in their entirety
before proceeding. Failure to observe this precaution could result in severe bodily injury or loss
of life.
Product Description
Installation of the Dynamic Braking kit enables a single-phase FlexPak™ Plus or MinPak™ Plus DC drive to
provide rapid, smooth stopping of the motor. If the Dynamic Braking kit is not used, the drive causes the motor
to coast to rest when the contactor opens.
The Dynamic Braking kit includes a resistor that is automatically switched across the motor's armature when
the drive is stopped. The rotating mechanical energy of the motor is converted into electrical energy that is
rapidly dissipated as heat. The resistor is sized for infrequent stops, so time must be allowed between stops for
the heat to dissipate.
Important: The dynamic brake is not a mechanical holding brake. It will not hold the motor shaft in place. It will
not prevent the motor from turning once motion has stopped.
The Dynamic Braking kit must be rated for the drive's horsepower and voltage rating, as shown in table 1. Refer
to your drive's nameplate for the horsepower and voltage rating. The Dynamic Braking kit contents are also
listed in table 1.
Description
Dynamic Braking Resistor
Mounting Screw, 4-40 x 3/8
Instruction Manual
Reliance and MinPak are trademarks of Rockwell Automation.
© 1998 Rockwell International Corporation
Dynamic Braking Kit
Model Numbers 14C214, 14C215, 14C216
Instruction Manual D2-3378
Table 1 – Contents of the Dynamic Braking Kit
Quantity
Kit Model Number and Rating
1
1/4 to 1/2 HP @ 115 VAC
2 to 3 HP @ 230 VAC
1
1
1/2 to 1-1/2 HP and 5 HP @ 230 VAC
2
1
14C214
14C215
3/4 HP @ 115 VAC
14C216
All
All
Reliance Part Number
63481-150QHC
63481-150QCC
63481-150QNC
601741-74C
D2-3378

Advertisement

loading

Summary of Contents for Rockwell Automation 14C214

  • Page 1 63481-150QCC 3/4 HP @ 115 VAC 14C216 63481-150QNC 1/2 to 1-1/2 HP and 5 HP @ 230 VAC Mounting Screw, 4-40 x 3/8 601741-74C Instruction Manual D2-3378 Reliance and MinPak are trademarks of Rockwell Automation. © 1998 Rockwell International Corporation...
  • Page 2 Installing the Dynamic Braking Kit in a FlexPak Plus DC Drive ATTENTION: Do not install modification kits with power applied to the drive. Disconnect, lock out, and tag all sources of incoming AC power to the drive before attempting such installation. Verify that no voltage is present at the drive’s AC input terminals, L1 and L2.
  • Page 3 Dynamic Braking Resistor M-Contactor or Forward Contactor Figure 1 – Dynamic Braking Resistor Connections for Regenerative FlexPak Plus Drives and Non-Regenerative FlexPak Plus Drives Without a Reversing Contactor Dynamic Braking Kit for FlexPak Plus and MinPak Plus DC Drives...
  • Page 4 Forward Contactor A1 (+) Forward Contactor DB 1 Dynamic Braking Motor Resistor Armature DB 2 Forward Contactor 45/52 A2 (–) Forward Contactor Figure 2 – Dynamic Braking Resistor Schematic for Regenerative Drives and Non-Regenerative Drives Without a Reversing Contactor Step 6. For non-regenerative FlexPak Plus DC drives with a Reversing Contactor: Connect the dynamic braking resistor between the corresponding normally closed ( ) contacts on the forward contactor and the reversing contactor.
  • Page 5 '\QDPLF %UDNLQJ 5HVLVWRU -XPSHU  -XPSHU  0&RQWDFWRU RU 5HYHUVLQJ &RQWDFWRU )RUZDUG &RQWDFWRU -XPSHU $ -XPSHU $ 7R 0RWRU $UPDWXUH Figure 3 – Dynamic Braking Resistor Connections for Non-Regenerative FlexPak Plus Drives With a Reversing Contactor Dynamic Braking Kit for FlexPak Plus and MinPak Plus DC Drives...
  • Page 6 )RUZDUG &RQWDFWRU $  5HYHUVLQJ &RQWDFWRU )RUZDUG &RQWDFWRU '%  '\QDPLF '& 0RWRU %UDNLQJ $UPDWXUH 5HVLVWRU '%  5HYHUVLQJ &RQWDFWRU 5HYHUVLQJ &RQWDFWRU  $  )RUZDUG &RQWDFWRU Figure 4 – Dynamic Braking Resistor Schematic for Non-Regenerative Drives with a Reversing Contactor ATTENTION: If a reversing contactor is installed, ensure jumper J9 is removed from the Regulator board (near the top of board).
  • Page 7 Installing the Dynamic Braking Kit in a MinPak Plus DC Drive ATTENTION: Do not install modification kits with power applied to the drive. Disconnect, lock out, and tag all sources of incoming AC power to the drive before attempting such installation. Verify that no voltage is present at the drive’s input terminals, L1/181 and L2/182.
  • Page 8 '\QDPLF %UDNLQJ 5HVLVWRU 0&RQWDFWRU Figure 5 – Dynamic Braking Resistor Connections for MinPak Plus Drives Without a Reversing Contactor '\QDPLF %UDNLQJ 5HVLVWRU 5HYHUVLQJ 0&RQWDFWRU &RQWDFWRU Figure 6 – Dynamic Braking Resistor Connections for MinPak Plus Drives With a Reversing Contactor ©...
  • Page 10 U.S. Drives Technical Support Tel: (1) 262.512.8176, Fax: (1) 262.512.2222, Email: support@drives.ra.rockwell.com, Online: www.ab.com/support/abdrives Publication D2-3378– November 1998 Copyright © 1998 Rockwell Automation, Inc. All Rights Reserved.
