Technical Data Original Instructions PowerFlex 755 On-Machine Drive Specifications Catalog Number 26G Topic Page Product Overview Catalog Number Explanation Compliance Certifications Drive Enclosure Ratings Logix, Firmware, and AOP Compatibility Design Considerations – Mechanical Design Considerations – Electrical Additional Resources... -
Page 2: Topic Page
This publication contains the following new or updated information. This list includes substantive updates only and is not intended to reflect all changes. Translated versions are not always available for each revision. Topic Page Added factory installed battery information Added WEEE label Rockwell Automation Publication 750-TD003B-EN-P - May 2020... -
Page 3: Product Overview
This equipment is intended for use in overvoltage Category III applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) at the default carrier frequency without derating. See Derating Guidelines for more information. Rockwell Automation Publication 750-TD003B-EN-P - May 2020... -
Page 4: Catalog Number Explanation
20° Coded male Code Resistor Transistor None None (1) Option E51, E53, E54, and E 56 are for use with AC induction motors. Option E52 and E55 are for use with Allen-Bradley servo motors. Rockwell Automation Publication 750-TD003B-EN-P - May 2020... -
Page 5: Compliance Certifications
F; Assurance Level II Vibration - packaged for shipment Per ASTM D999 Test Methods for Vibration Testing of Shipping Containers - Method A1 or A2, 1 g input UV radiation Not UV rated. Rockwell Automation Publication 750-TD003B-EN-P - May 2020... - Page 6 Factory-installed CR1220 lithium coin cell battery provides power to the real-time clock (supplied). Preserves the clock setting Battery in the event power to the drive is lost or cycled. Approximate life is 4.5 years with drive unpowered, or lifetime if drive is powered. Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 7 (1) All ratings to support continuous duty. There is no derate for duty cycle variations. All ratings are for normal duty except for the variation that has 14 A Heavy-Duty rating. (2) Selecting Option M2 with Drive Rating 022 will set up the drive for Heavy Duty (HD) rating. (3) M2 and M3 are only available in 480V, 60Hz. Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
-
Page 8: Drive Enclosure Ratings
Version 14 GuardLogix® 5570, Compact GuardLogix 5370, Version 30 Version 31 Version 31 Not supported Minimum Controller Firmware Armor™ GuardLogix® 5570 Controllers Required GuardLogix 5580, Version 31 Version 31 Compact GuardLogix 5380 Controllers Rockwell Automation Publication 750-TD003B-EN-P - May 2020... -
Page 9: Design Considerations - Mechanical
Packaging dimensions (H X W x D) with product 475 mm x 800 mm x 800 mm (18.69 in. x 31.5 in. x 31.5 in.) inside Weight 47.62 kg (approx. 105 lb) Weight with packaging 63.95 kg (approx. 141 lb) Rockwell Automation Publication 750-TD003B-EN-P - May 2020... - Page 10 Front View Left View Back View Bottom View On-Machine Drive Dimensions Millimeters 711.2 391.9 260.5 527.0 33.5 136.9 391.9 673.0 649.8 Inches 28.0 15.3 10.26 20.75 1.32 5.39 15.43 26.5 25.58 Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 11 Watt Loss Watt Loss Amps Amps 400 Volts 480 Volts 26G…C8P7 26G…D8P0 26G…C011 11.5 26G…D011 26G…C015 15.4 26G…D014 26G…C022 26G…D022 22 (14 A HD) (1) Select the watts loss based on the catalog number. Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 12 % Load 26G…C015 15.4 500 1000 1500 2000 2500 3000 3500 4000 4500 4800 Altitude (m) % Load 26G…C022 500 1000 1500 2000 2500 3000 3500 4000 4500 4800 Altitude (m) % Load Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 13 Altitude (m) % Load 26G…D014 500 1000 1500 2000 2500 3000 3500 4000 4500 4800 Altitude (m) % Load 26G…D022 500 1000 1500 2000 2500 3000 3500 4000 4500 4800 Altitude (m) % Load Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 14 IMPORTANT The On-Machine drive has multiple grounding locations. See the electrical schematics for specific information about the grounding for your specific configuration. See the Catalog Number Explanation for more information about configuration type. Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 15 Also, the suitable fuses for this circuit must be capable of delivering not more than 65,000 RMS symmetrical amperes at 480V AC maximum when protected by CC, J, and T classes. Branch Circuit Protection IMPORTANT The motor branch circuit protection is provided by the main circuit breaker, which complies with UL508 and CSA guidelines. Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 16 IMPORTANT used in wash-down environments apply a sealant or other corrosion inhibitor on the external ground terminal to minimize any negative effects of galvanic or electro-chemical corrosion. Ground connections must be inspected regularly. Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 17 Receptacles CP (24V DC auxiliary power), CPBR (24V DC brake option B2 and B3), and L123 (source brake option SB). The brake circuit breaker will vary in design and operation based on it being a 24V DC mechanical brake or 480V source mechanical brake. Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 18 PowerFlex 755 On-Machine Drive User Manual, publication 750-UM006. 1. 400/480V AC rotary power disconnect 2. 24V DC mechanical brake circuit breaker (shown) or 480V AC source mechanical brake circuit breaker 3. 24V DC control power circuit breaker. Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 19 PIN + 5BC130-T1 #18 AWG BLACK PIN - 5BC130-T2 #14 AWG GREEN/YELLOW PIN 1 PE BUS-3 380V…480V AC #14 AWG BLACK PIN 2 5BC130-T1 Source EMB1 Mechanical #14 AWG BLACK PIN 3 5BC130-T2 Brake Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 20 #18 AWG GRAY PIN 5 #18 AWG BROWN PIN 1 DI-0DC #18 AWG WHITE PIN 2 TB2-6 load Brake Resistor #18 AWG BLUE PIN 3 Thermostat DBRT Temperature #18 AWG BLACK PIN 4 Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 21 #24 AWG WHITE/ORANGE PIN 1 RJ45-PIN 1 #24 AWG WHITE/GREEN PIN 2 RJ45-PIN 3 Communication EtherNet/IP #24 AWG ORANGE PIN 3 RJ45-PIN 2 ETH1 / ETH2 Link #24 AWG GREEN PIN 4 RJ45-PIN 6 Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 22 BLACK PIN 7 Rotary Encoder #24 AWG BLUE PIN 8 #24 AWG BLACK PIN 9 #24 AWG YELLOW PIN 10 #24 AWG BLACK PIN 11 #24 AWG BROWN PIN 12 #22 AWG SHIELD Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 23 #22 AWG GRAY PIN 9 Hiperface #22 AWG ORANGE PIN 11 Encoder #22 AWG WHITE/GRAY PIN 10 #18 AWG WHITE/GRAY PIN 12 #18 AWG WHITE/GRAY PIN 14 #22 AWG WHITE/ORANGE PIN 13 SHIELD Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 24 V-Cable, DC Micro (M12), Female, Right Angle, 4-Pin, PVC 879D-R4ACDM-* Cable, Yellow, Unshielded, 22 AWG, DC Micro (M12), Straight Male DC micro (M12), Male, Straight, 4-Pin, PVC Cable, Yellow, 889D-M4AC-* Unshielded, IEC Color coded, No Connector Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 25 CPBM SpeedTEC Cable, Motor Power With Brake Wires, SpeedTEC Output Power #10 and Brake, #18, (for drive rating 2090-CPBM7E7-10AF** DIN Connector, Extension Receptacle (SpeedTEC ready), 10 Receptacle, 6-pin = 22 A) AWG, Continuous-Flex Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 26 (1) For recommended connectors/cables that contain an (*), the asterisk represents variance in cable lengths and configuration options. (2) Rockwell Automation only supplies unshielded motor cables for the M35 Motor Receptacles. Contact your local Rockwell Automation® distributor directly for shielded motor cables.
- Page 27 PowerFlex 750-Series drive with the appropriate servo motor data. For information about compatibility and configuration of Allen-Bradley servo motors (including Bulletin RDB or RDD-Series™ Direct Drive™ motors) and third-party PM motors, contact Rockwell Automation technical support. Allen-Bradley Servo Motors Compatible with PowerFlex 750-Series Drives...
- Page 28 26.8 3500 MPM-B2152C-MJ74AA MPM-B2152C 12.3 133.3 2000 39.2 36.7 2500 MPM-B2153B-MJ74AA MPM-B2153B 12.7 116.7 1750 42.4 2000 For motor power and feedback cable information, see the Kinetix® Motion Control Selection Guide, publication GMC-SG001. Rockwell Automation Publication 750-TD003B-EN-P - May 2020...
- Page 29 PowerFlex 755 On-Machine Drive Specifications Technical Data Additional Resources These documents contain additional information concerning related products from Rockwell Automation. Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 Provides general guidelines for installing a Rockwell Automation industrial system. ArmorConnect Power and Control Media Selection Guide, This manual describes how to select the ArmorConnect power and control media cables.
- Page 30 Allen-Bradley, Armor GuardLogix, ArmorConnect, Connected Components Workbench, DeviceLogix, Direct Drive, DriveExplorer, DriveExecutive, GuardLogix, LISTEN. THINK. SOLVE, Logix 5000,On- Machine, PowerFlex, RDD-Series, Rockwell Software, Rockwell Automation, RSLinx, RSLogix 5000, and Studio 5000 Logix Designer are trademarks of Rockwell Automation, Inc. EtherNet/IP is a trademark of ODVA, Inc.
