Inner Range Inception Security Controller

System Capacities

Entity
Areas
Inputs
Outputs
Doors
Lifts (V1.1.0 or later)
Lift Floors
SIFER Readers
Wiegand Readers
Users
Events
Up to 512 Outputs can be programmed. Note that all types of 'hardware outputs' & 'custom outputs'
#
count towards this total including door locks, DOTL, valid & invalid (for wiegand readers), lift floor
button enables, siren outputs, strobes, automation devices, etc.
* The Inception controller has 4 relay outputs in total. These can be used as lock relays for doors,
floor button enable contacts for lifts or general purpose dry contact outputs.
†
Inception Firmware prior to V2.0.0 only supports 32 Doors and 2000 Users.
Inception Firmware prior to V3.1.1 only supports 50,000 Events.
Inception Firmware prior to V4.0 only supports 32 Areas.
‡
256 Wiegand readers (In & Out Readers) requires a combination of up to 127 SLAMs (i.e. 1 per
door) and up to 8 OSDP<>Wiegand Converters.
Main Parts
Inception Security Controller.
Inception Power Supply. 24V DC. 2.5A
IEC power cable. Right angle.
Accessory Kit (See below)
Accessory Kit contents
4 x Metal PCB Mounting Clip. M3.
4 x M3 x 25mm pan head screw.
4 x M3 brass spacer. 8mm.
Self-adhesive Hook & Loop tape, 50 x 25mm.
2 x Cable Ties 350 x 4.8mm.
20 x 2k2 End-of-line Resistors.
4 x 1N4004 Diodes (for locks. *See note below)
NOTES:
* See "Output Relays (OUT1-4)" in the 'WIRING DIAGRAMS' section of this manual.
© 2016 - 2020. Inner Range Pty Ltd.
Total On-board Controller
96†
512 8
512 # 4 *
128 # †
4 *
32 See V1.1.0 Release notes.
512 # 4 *
256 8
256 ‡
8 (Via 8 OSPD<>Wiegand Conv.)
10,000 †
250,000†

Parts List

Installation manual (This document).
Beginners Guide to Inner Range Systems.
Inception Quickstart Guide
Inception User Manual
3 x 2-way 5mm Screw Terminal.
4 x 3-way 5mm Screw Terminal.
3 x 4-way 5mm Screw Terminal.
2 x 6-way 5mm Screw Terminal.
2 x Female 6.3mm QC Connectors.
Battery cable pair. 40cm. Red/Black.
Ethernet patch cable. 1m
5
Installation Manual. Rev. 4.0
With LAN Expansion
512
512
128
32
512
256 (Up to 4 per SLAM)
254 ‡
