Webasto Ford Transit Manual page 23

Ford Transit
17.Drill a 1.25 inch (32 mm) hole in the rear of the
left foam panel, approximately centered between
the two indents.
18.Route the following harnesses from the area
above the rear-view mirror through the hole and
down the b-pillar:
• coolant pump (35)
• coolant valve (28)
• blower harness (33)
• a/c compressor harness (29)
• extreme wiring harness (32)
19.Insert the blue wire labeled AC BLOWER ON from
the NEO adapter harness (34) into cavity C of the
blower harness X1 connector.
23
