4.4

Installing/Removing Power Modules

Figure 4.4
Contamination hazard – risk of equipment damage
Prevent the ingress of water, dirts and other debris that may lead to premature
equipment failure. Always make sure slots are not left empty.
Removing a Power Module
To remove a power module, do the following:
Electrocution hazard – risk of serious personal injury or death
Make sure power to the module is turned off before servicing the power supply
terminal.
1.
2.
3.
RUGGEDCOM RX1536
Installation Manual, 04/2021, C79000-G8976-1488-02
1
NOTICE
DANGER
Turn off power to the module.
Loosen the screws that secure the module to the chassis until the module can be
removed.
1
2
3
Figure 4.5 Removing a Power Supply
Slide the module out of the chassis.
4.4 Installing/Removing Power Modules
Modules
41
