Modules
4.2 Available Modules
Electrical hazard – risk of power failure
Power fluctuations or irregular shut downs may occur if the total power
consumption of all installed modules exceeds the power budget of the device.
Power Budget
Total Power Budget for the Device
Power Budget for Line Modules (@ 9 W Used For the System)
Module Power Consumption
RUGGEDCOM APE1808
RUGGEDCOM APE1402
RUGGEDCOM APE1404
2-Port Fiber Optic (FG50 + SFPs)
6-Port Fiber Optic (6FX50)
WAN Cell (3G, LTE)
2-Port Copper (M12, RJ45)
4-Port Copper (M12, RJ45)
6-Port Copper (M12, RJ45)
WAN T1, E1
Serial (S01)
Example
A device with the following modules installed would exceed the power budget for
line modules (41.5 W):
RUGGEDCOM APE1808
2-Port Fiber Optic (FG50 + SFPs)
6-Port Copper (M12, RJ45)
4.2

Available Modules

The following is a list of all power and line modules available for use in the
RUGGEDCOM RX1536. For more information about individual modules, refer to the
RUGGEDCOM RX1500 Series Modules Catalog [https://support.industry.siemens.com/
cs/ca/en/view/109747072].
26
NOTICE
Module Type
Module
50 W
41.5 W
Power Consumption
12 W
10 W
10 W
7 W
7 W
7 W
4 W
5 W
5 W
3 W
3 W
Quantity
2
2
1
Total Consumption 43 W
Installation Manual, 04/2021, C79000-G8976-1488-02
Consumption
24 W
14 W
5 W
RUGGEDCOM RX1536
