General Instructions
01PTOSBA0806SDFW-V1 & 01PTOSBA0806SDFW-V1-NW
8X6 PRESSURE TREATED OSB APEX SHED
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
TIMBER
BUILDING A BASE
TYPES OF BASE
Whilst all products manufactured are made to the highest standards of Safety and in the case of
childrens products independently tested to EN71 level, we cannot accept responsibility for your safety
whilst erecting or using this product.
Refer to the instructions pages for your speci c product code
Please retain product label and instructions for future reference
x2
MUST
2mm Drill bit
Pressure Treated Timber
Copper Azole CA
Micronized Copper Quaternary MCQ
Safety:
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
Alkaline Copper Quaternary ACQ
P 1
Advertisement
Table of Contents
Related Manuals for Mercia Garden Products 01PTOSBA0806SDFW-V1
Summary of Contents for Mercia Garden Products 01PTOSBA0806SDFW-V1
- Page 1 General Instructions Please retain product label and instructions for future reference 01PTOSBA0806SDFW-V1 & 01PTOSBA0806SDFW-V1-NW 8X6 PRESSURE TREATED OSB APEX SHED BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY CAUTION MUST 2mm Drill bit TIMBER Pressure Treated Timber Alkaline Copper Quaternary ACQ...
- Page 2 01PTOSBA0806SDFW-V2 Please retain product label and instructions for future reference Overall Dimensions: Nail Bag 30mm Black Screw x2 Base Dimensions: 40mm Screw x45 50mm Screw x28 Before assembly Felt Tacks x108 please make sure you have a suitable base ready to erect your 16mm Screws x12 building 20mm Screw x20...
- Page 3 Please retain product label and instructions for future reference Step 1 Step 3 9x50mm Screws Step 2 Step 4 8x20mm Screws 3x50mm Screws...
- Page 4 Please retain product label and instructions for future reference Step 7 Step 5 108 x Tacks 12 x 30mm Screws 28 x 40mm Screws Felt tacks 30mm screw Step 6 16x 50mm Screws HANDLE WITH CARE...
- Page 5 Please retain product label and instructions for future reference Step 8 Step 10 For the no window version go to step 11 12x30mm Screws *For added weather protection t your windows using silicone sealant around the outside edges. **When positioning the styrene sheets ensure there is an equal distance on all sides.
- Page 6 Please retain product label and instructions for future reference Please retain product label and instructions for future reference Step 11 It is ESSENTIAL that you apply wood treatment immediately after the building 2x 30mm Black Screw has been assembled.
- Page 7 Please retain product label and instructions for future reference...
