Summary of Contents for Puretec Tripla Elite
- Page 1 Tripla™ Elite Triple Action Tapware User Guide T A P W A R E...
-
Page 2: Table Of Contents
Pro-Switch Pty Ltd Puretec Customer Service Thank you for purchasing a Puretec Tripla Elite. Your tap is manufactured from only quality materials and will last for years, if maintained and installed properly. The system is designed for metropolitan supply water but can be used in other situations. -
Page 3: Register Your Warranty
Plated Surface - should only be cleaned with a minimal amount of liquid detergent/soap with water. Under no circumstance should any abrasive or acid-base cleaning agents be used. Copyright © Puretec Pty Ltd 2023 Puretec Tripla™ Elite | Triple Action Tapware... -
Page 4: Servicing
Introduction Servicing Periodically clean the aerator for any lodged sediment that may restrict flow. A Puretec water filter is highly recommended for product longevity. Should it be necessary to have your mixer serviced while under warranty, please carry out the following procedure:... -
Page 5: Dimensions
Dimensions Fig. 1 - Tripla™ Elite 10 Series Dimensions Model Code Colour ELITE-10CH Chrome ELITE-10BN Brushed Nickel ELITE-10BG Brushed Gold ELITE-10GM Gunmetal ELITE-10MB Matt Black Copyright © Puretec Pty Ltd 2023 Puretec Tripla™ Elite | Triple Action Tapware... - Page 6 Dimensions Fig. 2 - Tripla™ Elite 20 Series Dimensions Model Code Colour ELITE-20CH Chrome ELITE-20BN Brushed Nickel ELITE-20BG Brushed Gold ELITE-20GM Gunmetal ELITE-20MB Matt Black Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
-
Page 7: Installation Guide
Note: It is important to flush out the supply pipes to the mixer before connecting the flexible hoses, with the initial installation, so no foreign matter can enter into the cartridges. A Puretec Water Filter is highly recommended for product longevity. Fig.3 - Water Connection Patterns... -
Page 8: Assembly
Assembly Fig.4 - Assembly Mixer Tap Rubber O-ring Rubber Washer Sink Faucet Metal Washer Hole (Ø35mm) Retaining Plate & Screws COLD FILTER/RAIN Installation & Operation Manual Copyright © Puretec Pty Ltd 2023... -
Page 9: Installation
6. Finally, tighten each retaining plate screw against the metal washer to secure tap firmly into place. Washers & Retaining Plate Copyright © Puretec Pty Ltd 2023 Puretec Tripla™ Elite | Triple Action Tapware... -
Page 10: Maintenance
Insert the new spindle, tightening with the wrench. DO NOT OVERTIGHTEN. • Seat the handle cap back into position and secure the grub screw with the Allen key. • Replace the handle (hand tighten only). Installation & Operation Manual Copyright © Puretec Pty Ltd 2023... -
Page 11: Tripla Elite-10 Models - Parts Description
Parts Description Fig. 9 Parts Description - Tripla Elite 10 Models 1. Spout 2. Washer 3. Aerator Insert 4. Aerator Cap 8. Inner Tube 9. Gasket 10. Spout Spigot Assembly 11. Washer 12. O-ring 13. O-ring 14. Handle 25. Handle 15. -
Page 12: Tripla Elite-20 Models - Parts Description
Parts Description Fig. 10 Parts Description - Tripla Elite 20 Models 1. Spout 5. Washer 2. Washer 6. Filter Insert 3. Aerator Insert 7. Aerator Cap 4. Aerator Cap 8. Inner Tube 9. Gasket 10. Spout Spigot Assembly 11. Washer 12. -
Page 13: Warranty
Notes The complete range of Puretec products are developed, refined and made to meet and exceed stringent specifications for the worldwide market. Important Note: Sales of products are subject to our Terms & Conditions which are available upon request. All specifications, prices and photos are a guide only and are subject to change without notice. - Page 14 Warranty Applicable to all above, is that the warranties need to be approved by Puretec to ensure product was not incorrectly used, installed or claimed. False and incorrect claims will be pursued at Puretec’s discretion, including chargeable inspection and labour costs incurred.
- Page 15 Copyright © Puretec Pty Ltd 2023 Puretec Tripla™ Elite | Triple Action Tapware...
- Page 16 FEB2023...
