- Page 1 User Guide Quick Twist Filter System with Tripla LED Mixer Tap AS/NZS 3497 Licence No. WM 74617 Australian Certification Services QT12-TRIPLA For correct operation & installation it is essential to observe these instructions. JUL2018...
-
Page 2: Table Of Contents
Tripla T3 Parts Description ......................18 Tripla T4 Parts Description ......................19 Tripla T5 Parts Description ......................20 Tripla T6 Parts Description ......................21 Performance Data .......................... 22 Warranty ..............................23 Installation & Operation Manual Copyright © Puretec Pty Ltd 2018... -
Page 3: Operation
Puretec stockist. The system is designed for metropolitan supply water but can be used in other situations. For other types of water supply please contact your local Puretec stockist or call our Puretec Customer Service Helpline prior to installing the tap. -
Page 4: Servicing
Installation Guide Servicing Periodically clean the aerator for any lodged sediment that may restrict flow. A Puretec water filter is highly recommended on all incoming lines for product longevity. Should it be necessary to have your mixer serviced while under warranty, please carry out the... -
Page 5: Part 1 Mixer Tap Assembly
Note: It is important to flush out the supply pipes to the mixer before connecting the flexible hoses, with the initial installation, so no foreign matter can enter into the cartridges. A Puretec Water Filter is highly recommended for product longevity. Quick Twist Water Filter System with Tripla LED Mixer Tap... -
Page 6: Assembly
Then, use a wrench to lock the retainer nut. Rubber Spacer Zinc Spacer Locking Retainer Screw Installation & Operation Manual Copyright © Puretec Pty Ltd 2018... -
Page 7: Water Connection Patterns
Mixer Tap Connections Water Connection Patterns For QT12-T1 & QT12-T2 Water Filter Connection Retainer Screw HOT Water COLD Water Connection Connection Quick Twist Water Filter System with Tripla LED Mixer Tap... - Page 8 Water Connection Patterns For QT12-T3 to QT12-T6 Water Filter Connection Retainer Retainer Screw Screw HOT Water COLD Water Connection Connection Installation & Operation Manual Copyright © Puretec Pty Ltd 2018...
-
Page 9: Battery Installation
Mixer Tap Maintenance Battery Installation - LED reminder light Important note: Battery must be replaced when changing cartridges. 1. Remove the black battery seat from the Note: red light flashes faucet canopy twice and then followed by the blue light 3. -
Page 10: Replacement Of Ceramic Disc Cartridge(S)
Unscrew handle then remove cartridge by unscrewing it anti-clockwise, using 5/8” socket. Install cartridge by completing removal instructions as above, in reverse order. • Ensure cartridge is firmly tightened not over tightened. 10 Installation & Operation Manual Copyright © Puretec Pty Ltd 2018... -
Page 11: Part 2 Filter Cartridge Installation
Filter Cartridge Installation PART 2 Filter Cartridge Installation This system comes complete with an installation kit enabling it to be connected to 15mm (½”) male thread. Installation requirements 15mm (½”) Cold water line - mains only Supply pressure: 100-500 kPa. Supply temperature 3°... -
Page 12: Cartridge Installation/Changeout
Remove packaging from the new cartridge including the yellow cap on top of the cartridge. Twist in the new cartridge. Ensure firm seal to head. Replacement cartridge code: Puretec QT12R Reset LED indicator by following instructions on page 6. Restore water supply. 12 Installation & Operation Manual Copyright © Puretec Pty Ltd 2018... - Page 13 Filter Cartridge Installation Check for leaks, rectifying them, if any, before leaving the unit. After installing cartridges flush unit for 5 - 10 minutes. Use Guidelines • Minimum operating pressure 100 kPa. • Maximum operating pressure 500 kPa. • Do not allow exposure to temperatures below 3°C. •...
-
Page 14: Assembly
O-Ring seal being damaged. Tube is secured in position. DISCONNECTION PROCEDURE Push collet against body and slide tube out of fitting. 14 Installation & Operation Manual Copyright © Puretec Pty Ltd 2018... -
Page 15: Wels Ratings
WELS Rating for Tripla Taps TRIPLA-T1 TRIPLA-T2 TRIPLA-T3 TRIPLA-T4 TRIPLA-T5 TRIPLA-T6 Quick Twist Water Filter System with Tripla LED Mixer Tap... -
Page 16: Tripla T1 Parts Description
38. Handle Cap 36. Magnetic Seat 17. Housing 37. Magnet 40. Circuit Board 41. Battery Seat 18. Screw 19. Rubber 45. Flexible Washer Tube ½" Inlet/Outlet Hose Stainless Washer 21. Brass 16 Installation & Operation Manual Copyright © Puretec Pty Ltd 2018... -
Page 17: Tripla T2 Parts Description
Parts Description TRIPLA T2 Parts Description 3. Handle 1. Screw 4. Cap 2. Cap 5. Plunger 6. Stem / Cartridge 9-2. Brass Tube 7. Cover Stem 9-3. Inner Tube 9-4. C onnector 9-1. Body 8. Teflon Washer 9. Spout 10. EPDM Washer 25. -
Page 18: Tripla T3 Parts Description
31. Plunger 32. Cap 38. Housing Screw 35. Body 39. O-Ring 34. Canopy 36. Nut 37. Stopper 40. Screw washer 44. Flexible Tube Washer 43. B rass 47. Wrench 18 Installation & Operation Manual Copyright © Puretec Pty Ltd 2018... -
Page 19: Tripla T4 Parts Description
Parts Description TRIPLA T4 Parts Description 1. Spout 1-3. Inner Tube 1-4. Connector 2. Washer 1-2. Tube 3. Aerator Insert 16. Screw 4. Aerator Cap 1-1. Body 13. Display 10. Cap 5. Gasket 6. Washer 11. O-R ing 14. Handle Cap 7. -
Page 20: Tripla T5 Parts Description
23. Stem Post 24. Upper 38-2. Nut 25. Lower 26. Seat 37. Handle Cap 27. Stopper 39. Stopper 26. S eat 40. Washer 41. Screw Washer 45. Flexible Tube Washer Brass 20 Installation & Operation Manual Copyright © Puretec Pty Ltd 2018... -
Page 21: Tripla T6 Parts Description
Parts Description TRIPLA T6 Parts Description 1-4. Connector 1. Spout 1-3. Inner Tube 2. Washer 5. Washer 6. Filter Net 3. Aerator Insert 7. Filter 1-2. Tube 4. Aerator Cap 8. Aerator Cap 1-1. Body 16. Display 13. Cap 19. Screw 9. -
Page 22: Performance Data
Giardia, but will not remove or inactivate bacteria and virises unless II(a) and II(b) is passed Turbidity & Particulate Reduction Reduces cloudiness Taste & Odour Reduction Reduces taste & odours Chemical Treatment Decreases chlorine 22 Installation & Operation Manual Copyright © Puretec Pty Ltd 2018... -
Page 23: Warranty
Applicable to all above, is that the warranties need to be approved by Puretec to ensure product was not incorrectly used, installed or claimed. False and incorrect claims will be pursued at Puretec’s discretion, including chargeable inspection and labour costs incurred.
