2) Locate the part number location on the board.

Connector repair

This procedure includes HDMI, DisplayPort and Audio connectors.
The connectors are on the main board (board part number CBPRND9H0Q1).
The connectors identifiers are as follows:
Connector
HDMI 1 &2
DisplayPort
Audio
Before repairing connectors, follow these steps:
Prepare the monitor for disassembly. See Preparation for disassembly on page 9.
16
Power Board
Location
CN501/CN510
CN5301
CN603
Main Board
CN510
CN501
CN603
CN5301
