Overview
1. Menu
Opens, selects or exits the OSD menu.
2. Minus "-"
If the OSD menu is on, press to navigate
backward through the OSD menu and
decrease adjustment levels.
3. Plus"+"/Input
If the OSD menu is on, press to navigate
forward through the OSD menu and increase
adjustment levels.
If the OSD menu is inactive, press to activate
the source button that chooses the video
signal input (VGA, DVI, or DisplayPort).
DA - 14716 Worldwide — Version 2 — December 5, 2013
HP V221 21.5-inch LED Backlit Monitor
4. OK/Auto
If the OSD menu is on, press to select the
highlighted menu item. If the OSD menu is
inactive, press to activate the auto
adjustment feature to optimize the screen
image.
5. Power
Turns the monitor on or off.
6. Power LED
LED:
fully powered = blue;
sleep mode = amber;
sleep timer mode = flashing amber.
Page 1
Advertisement
Related Manuals for HP V221
Summary of Contents for HP V221
- Page 1 QuickSpecs HP V221 21.5-inch LED Backlit Monitor Overview 1. Menu Opens, selects or exits the OSD menu. 4. OK/Auto If the OSD menu is on, press to select the highlighted menu item. If the OSD menu is 2. Minus "-"...
- Page 2 QuickSpecs HP V221 21.5-inch LED Backlit Monitor Overview Boost Productivity with Dual Monitor Work Solution (Multi-monitor support depends on your PC capability. Monitors and stands are sold separately.) Model: E2T08AA DA - 14716 Worldwide — Version 2 — December 5, 2013...
- Page 3 Color Gamut (typical)* Color Support** Can display up to 16.7 million colors *All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. ** With the use of FRC technology. On Screen Display Buttons or Switches Menu, Minus ("-"), Plus ("+"), OK/Auto, Power...
- Page 4 QuickSpecs HP V221 21.5-inch LED Backlit Monitor Technical Specifications Default Color 6500 K Temperature Video/Other Inputs Plug and Play Input Connectors VGA (analog), DVI-D (HDCP support on DVI-D) Video Cables (1) VGA Video Cable Lengths VGA 1,8 m (5.9 ft)
-
Page 5: Additional Information
RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as DA - 14716 Worldwide —... - Page 6 To recycle your product, please go to: Management and http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office. Recycling Products returned to HP will be recycled, recovered or disposed of in a responsible manner. DA - 14716 Worldwide — Version 2 — December 5, 2013 Page 6...
- Page 7 Compatible with platforms using the VESA standard video modes. Recommended for use with HP products. Service and Warranty Protected by HP, including a 3 year standard limited warranty. Optional Care Pack Services are extended service contracts which go beyond your standard warranties. DA - 14716 Worldwide — Version 2 — December 5, 2013...
- Page 8 ENERGY STAR® is a US registered mark of the United States Environmental Protection Agency. The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg) for all devices mounted. Because mounting surfaces vary widely and the final mounting method and configuration may vary, mounting fasteners are not supplied (other than the VESA-compliant screws).
