- Page 1 Operators and Service Manual Product Holding Cabinet U.S. Patent 6175099, 6262394 Other U.S. and Foreign Patents Pending FWM3-51 For information or technical assistance, call: TOLL FREE (800) 735-DUKE (3853) (314) 231-1130 156112L...
-
Page 2: Table Of Contents
Because the compartments are sealed and formed to the shape of the pan, no disassembly is required Local Service # for cleaning and product changes. The unique design of the Duke Product Holding Cabinet allows single temperature operation for all Installation requirements existing product groups. - Page 3 230 V, 6.5 A, 1500 W, 50/60 Hz FWM3-51-240 240 V, 6.3 A, 1500 W, 50/60 Hz U.S. Patent 6175099, 6262394 Other U.S. and Foreign Patents Pending DUKE MANUFACTURING CO. REVISION: TOLL FREE 800-735-DUKE (3853) 314-231-1130 August 18, 2005 3 of 12...
-
Page 4: Installation Instructions
Stacking Units WARNING! TIP HAZARD! Do not stack FWM3-51 units. U.S. Patent 6175099, 6262394 Other U.S. and Foreign Patents Pending DUKE MANUFACTURING CO. REVISION: TOLL FREE 800-735-DUKE (3853) 314-231-1130 August 18, 2005 4 of 12... -
Page 5: Periodic Maintenance, Checklist And Cleaning Guide
These can damage the stainless steel and plastic surfaces. !Warning! Bottom and sides of warmer wells are very hot and cool slowly. U.S. Patent 6175099, 6262394 Other U.S. and Foreign Patents Pending DUKE MANUFACTURING CO. REVISION: TOLL FREE 800-735-DUKE (3853) 314-231-1130 August 18, 2005 5 of 12... -
Page 6: Troubleshooting
MANUAL Troubleshooting There are no user serviceable parts on the Duke Product Holding Cabinet. If a malfunction occurs, ensure unit is plugged in then check all switches and circuit breakers. If the malfunction still exists, contact your Duke Manufacturing Company authorized service agent or call 1-800-735-3853. -
Page 7: Control Programming
5. Press and hold S1 until no LED on the rear of the control is illuminated. 6. Replace cover on control side of the Holding Cabinet. U.S. Patent 6175099, 6262394 Other U.S. and Foreign Patents Pending DUKE MANUFACTURING CO. REVISION: TOLL FREE 800-735-DUKE (3853) 314-231-1130 August 18, 2005 7 of 12... -
Page 8: Parts Lists And Illustrations
Note: ICC Timer Control will need to be manually programmed at the time of installation. U.S. Patent 6175099, 6262394 Other U.S. and Foreign Patents Pending DUKE MANUFACTURING CO. REVISION: TOLL FREE 800-735-DUKE (3853) 314-231-1130 August 18, 2005 8 of 12... - Page 9 PRODUCT HOLDING CABINET MANUAL Parts Lists and Illustrations (Continued) Figure 5, FWM3-51 Product Holding Cabinet Exploded View U.S. Patent 6175099, 6262394 Other U.S. and Foreign Patents Pending DUKE MANUFACTURING CO. REVISION: TOLL FREE 800-735-DUKE (3853) 314-231-1130 August 18, 2005 9 of 12...
-
Page 10: Wiring Schematic
1 0 0 /1 2 0 V A C U N I T S U S E A 1 2 0 V T R A N S F O R M E R Figure 6, FWM3-51 Internal Wiring Schematic U.S. Patent 6175099, 6262394 Other U.S. and Foreign Patents Pending DUKE MANUFACTURING CO. REVISION: TOLL FREE 800-735-DUKE (3853) 314-231-1130 August 18, 2005 10 of 12... - Page 11 RESTAURANT EQUIPMENT PRODUCT HOLDING CABINET MANUAL Interface Cable Connection U.S. Patent 6175099, 6262394 Other U.S. and Foreign Patents Pending DUKE MANUFACTURING CO. REVISION: TOLL FREE 800-735-DUKE (3853) 314-231-1130 August 18, 2005 11 of 12...
