- Page 1 ExtremeAccess Series: Hardware Installation Guide 9036016-00 Published August 2019...
- Page 2 Copyright © 2019 Extreme Networks, Inc. All rights reserved. Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
-
Page 3: Table Of Contents
Appendix B: Safety and Regulatory Information..............45 Considerations Before Installing..........................45 General Safety Precautions............................46 Maintenance Safety................................46 Cable Routing for LAN Systems..........................47 Installing Power Supply Units and Connecting Power..................48 Selecting Power Supply Cords............................ 49 Battery Notice..................................49 Regulatory Notices................................49 Index............................54 ExtremeAccess Series: Hardware Installation Guide... -
Page 4: Preface
See the VOSS software documentation for information about configuring XA1400 Series hardware. Note If the information in an installation note or release note shipped with your Extreme Networks equipment differs from the information in this guide, follow the installation or release note. -
Page 5: Documentation And Training
Hardware/Software Compatibility Matrices https://www.extremenetworks.com/support/compatibility-matrices/ White papers, data sheets, case studies, https://www.extremenetworks.com/resources/ and other product resources Training Extreme Networks offers product training courses, both online and in person, as well as specialized certifications. For more information, visit www.extremenetworks.com/education/. ExtremeAccess Series: Hardware Installation Guide... -
Page 6: Getting Help
4 Click Submit. Providing Feedback to Us Quality is our first concern at Extreme Networks, and we have made every effort to ensure the accuracy and completeness of this document. We are always striving to improve our documentation and help... - Page 7 If you would like to provide feedback to the Extreme Networks Information Development team, you can do so in two ways: • Use our short online feedback form at https://www.extremenetworks.com/documentation- feedback/. • Email us at documentation@extremenetworks.com. Please provide the publication title, part number, and as much detail as possible, including the topic heading and page number if applicable, as well as your suggestions for improvement.
-
Page 8: Chapter 1: Overview Of The Xa1400 Series
• LEDs to indicate port status and switch operating conditions. For a description of the LEDs and their operation, see XA1400 Switch LEDs on page 38. Figure 1: XA1400 Series Series Switch - Front Panel ExtremeAccess Series: Hardware Installation Guide... -
Page 9: Vsp License Options
7 = 10G SFP+ input port Ethernet ports 2 = Power button 4 = RJ45 Console port 6 = 10/100/1000BASE-T Ethernet ports VSP License Options For information about licensing options for VOSS, see Administering VSP Operating System Software. ExtremeAccess Series: Hardware Installation Guide... -
Page 10: Chapter 2: Power Supply For Use With Your Switch
Plug the supply's input jack into the DC power adapter input. LEDs on the 12V 60W DC power adapter provide information on the unit's operational status. See 12V 60W DC PSU LEDs on page 39 ExtremeAccess Series: Hardware Installation Guide... -
Page 11: Chapter 3: Preparing To Install
Meeting Power Requirements Following Applicable Industry Standards Before you install your Extreme Networks equipment, careful planning can help ensure that it is used effectively and help prepare you for future growth. Only qualified service personnel should install, maintain, or remove a switch, chassis, or its components. -
Page 12: Operating Environment Requirements
“UL Approved” or “UL Listed.” National Electrical Manufacturing Association (NEMA) (USA NEMA www.nema.org only) 1300 N. 17th Street Organization of electrical product manufacturers. Members Rosslyn, VA 22209 develop consensus standards for cables, wiring, and electrical components. ExtremeAccess Series: Hardware Installation Guide... - Page 13 Controlling the Temperature Extreme Networks equipment generates a significant amount of heat. It is essential that you provide a temperature-controlled environment for both performance and safety. Install the equipment only in a temperature- and humidity-controlled indoor area that is free of airborne materials that can conduct electricity.
-
Page 14: Rack Specifications And Recommendations
Alternately, you can restart the system immediately by removing and then restoring all line power to the system. Safeguards are built into all Extreme Networks switches and power supply units to minimize the risk of fire. Controlling the Humidity Level To maximize equipment life, keep operating humidity between 50% and 70% relative humidity (non- condensing) during typical operation. - Page 15 This will ensure good grounding between the chassis, rack, and earth ground. Note Because building codes vary worldwide, Extreme Networks strongly recommends that you consult an electrical contractor to ensure proper equipment grounding for your specific installation.
-
Page 16: Evaluating And Meeting Cable Requirements
Evaluating and Meeting Cable Requirements Use professional consultants for site planning and cabling. Extreme Networks recommends using the Building Industry Consulting Service International (BICSI) Registered Communications Distribution Designer (RCDD), which is globally recognized as a standard in site planning and cabling. - Page 17 Assign a unique block of sequential numbers to the group of cables that run between each pair of wiring closets. • Assign a unique identification number to each equipment rack. • Identify all wiring closets by labeling the front panel of your Extreme Networks equipment and other hardware. • Keep accurate and current cable identification records. •...
- Page 18 Fiber optic cable must be handled carefully during installation. Every cable has a minimum bend radius, example, and fibers will be damaged if the cables are bent too sharply. It is also important not to stretch the cable during installation. Extreme Networks recommends ExtremeAccess Series: Hardware Installation Guide...
- Page 19 Table 5: Cable Distances and Types Standard Media Type MHz•km Maximum Distance Rating (Meters) 1000BASE-SX 50/125 µm multimode fiber (850nm optical window) 50/125 µm multimode fiber 62.5/125 µm multimode fiber 62.5/125 µm multimode fiber ExtremeAccess Series: Hardware Installation Guide...
- Page 20 Table 7 on page 21 list direct-attach cables available from Extreme Networks. Proprietary to Extreme Networks. Connections between two Extreme Networks 1000BASE-LX interfaces that use 10/125 µm single-mode fiber can use a maximum distance of 10,000 meters. ExtremeAccess Series: Hardware Installation Guide...
- Page 21 Preparing to Install Table 6: Extreme Networks 100Gb Direct-Attach Cables Cable Type Part Number Length QSFP28-QSFP28 Direct attach passive copper cable 10411 or AA1405029-E6 1 meter 10413 or AA1405031-E6 3 meters 10414 or AA1405032-E6 5 meters QSFP28-4xSFP28 (4x25Gb) Direct attach passive copper...
- Page 22 Figure 6: RJ45 Connector Jacket Types Proprietary to Extreme Networks. Connections between two Extreme Networks 1000BASE-LX interfaces that use 10/125 µm single-mode fiber can use a maximum distance of 10,000 meters.
-
Page 23: Meeting Power Requirements
For detailed power specifications for your equipment, see "Technical Specifications." Requirements for Power Cords Most ExtremeSwitching switches do not ship with power cords. Visit www.extremenetworks.com/ product/powercords/ for information on selecting and purchasing the correct power cords for use with ExtremeAccess Series: Hardware Installation Guide... - Page 24 Preparing to Install specific Extreme Networks equipment. The web page provides specifications for power cords in each country so that you can purchase cords locally. UPS (Uninterruptible Power Supply) Requirements A UPS (uninterruptible power supply) is a device that sits between a power supply (such as a wall outlet) and a device (such as a switch) to prevent outages, sags, surges, and bad harmonics from adversely affecting the performance of the device.
-
Page 25: Following Applicable Industry Standards
UPS transfer time. UPS transition times vary between UPS models and implementations, but shorter transition times are preferred. For Extreme Networks stacking products, we recommend a UPS transition time of 20 milliseconds or less to ensure optimum performance and minimize service interruptions. -
Page 26: Chapter 4: Installing Your Switch
What You Will Need for the Installation Attaching the Switch to a Two-Post Rack Installing Optional Components Connecting Network Interface Cables Before you attempt to install or remove an Extreme Networks switch, read the precautions in Safety Considerations for Installing Power Supplies on page 26. -
Page 27: What You Will Need For The Installation
Warning Extreme Networks AC power supplies do not have switches for turning the unit on and off. To disconnect the power to an Extreme Networks AC power supply, remove the wall plug from the electrical outlet. -
Page 28: Attaching The Switch To A Two-Post Rack
Brackets for a two-post mount are not included in the box with your switch. However, they can be ordered separately using part number XN-2P-RMKIT-XA. To attach your switch to a two-post rack, follow these steps: Remove all contents of the rack-mount kit. Figure 7: Rack-Mount Kit Components ExtremeAccess Series: Hardware Installation Guide... - Page 29 Installing Your Switch 2 With the front of the XA1400 Series switch facing you, Align the A bracket to the left side of the switch. Figure 8: Align Left (A) Bracket ExtremeAccess Series: Hardware Installation Guide...
- Page 30 Secure the A bracket using the 3 (b) screws and 1 (a) screw. Figure 9: Secure Left (A) Bracket 3 With the front of the XA1400 Series switch facing you, align the B bracket to the right side of the switch. Figure 10: Mount Right (B) Bracket ExtremeAccess Series: Hardware Installation Guide...
- Page 31 Secure the B bracket using 3 (b) screws. Figure 11: Secure Right (B) Bracket 4 With the rear of the XA1400 Series switch facing you, align the C bracket to the left side of the switch. Figure 12: Align C Bracket ExtremeAccess Series: Hardware Installation Guide...
- Page 32 Installing Your Switch a Secure the C bracket using 2 (a) screws. Figure 13: Secure C Bracket ExtremeAccess Series: Hardware Installation Guide...
- Page 33 5 Insert the zip ties (D) into the slots of the B and C brackets. Figure 14: Insert Zip Ties 6 Secure the external power supply and close the zip ties appropriately. Figure 15: Secure External Power Supply ExtremeAccess Series: Hardware Installation Guide...
-
Page 34: Installing Optional Components
Hardware/Software Compatibility and Recommendation Matrices. Pluggable Transceiver Modules Extreme Networks offers several optical transceiver modules for transmitting and receiving data over optical fiber rather than through electrical wires. Install these modules using the instructions in Extreme Networks Pluggable Transceivers Installation Guide. -
Page 35: Connecting Network Interface Cables
35 through step for the remaining cables on this or other switches or I/O modules. 6 Dress and secure the cable bundle to provide appropriate strain relief and protection against bends and kinks. ExtremeAccess Series: Hardware Installation Guide... -
Page 36: Chapter 5: Activating And Verifying The Switch
Be sure that your serial connection is set properly: • Baud rate: 115200 • Data bits: 8 • Stop bit: 1 2 Press [Enter] one or more times until you see the login prompt. ExtremeAccess Series: Hardware Installation Guide... - Page 37 4 Follow the steps for provisioning and verifying the switch in Quick Start Configuration for VOSS. The switch is ready for use. To configure security, see Configuring Security. To configure other switch features, see Documentation Reference. ExtremeAccess Series: Hardware Installation Guide...
-
Page 38: Chapter 6: Monitoring The Switch
Internal/External PSU 2 Fail (if present) RJ45 Port LEDs Table 10: RJ45 Port LEDs RJ45 Port LEDs Color and Activity Definition Link/Act (left) No link GRN - Solid Link is established GRN - Flash Link activity ExtremeAccess Series: Hardware Installation Guide... -
Page 39: Xa 12V 60W Dc Psu Leds
Table 12: 12V 60W DC Power Supply LED Status Indications Label and Description State Meaning Color Fault Indicator On PSU fault Amber (Solid) No PSU fault OUT OK DC output DC output OK (Green) Good (solid) Off or DC output fail Blinking ExtremeAccess Series: Hardware Installation Guide... - Page 40 Monitoring the Switch Table 12: 12V 60W DC Power Supply LED Status Indications (continued) Label and Description State Meaning Color IN OK DC input Good DC input OK (Green) "IN OK" DC input fail ExtremeAccess Series: Hardware Installation Guide...
-
Page 41: Appendix A: Technical Specifications
Height: 8.38 cm (3.3 in) Width: 19.81cm (7.8 in) Length: 28.57cm (11.25 in) Table 15: XA1400 Series Packaged Weight XA1440 3.1 kg (6.83 lb) XA1480 3.1 kg (6.83 lb) Two-post rack mount kit (separately orderable) 0.8 kg (1.76 lb) ExtremeAccess Series: Hardware Installation Guide... - Page 42 EN 60950-1:2006 + A11:2009 + A1:2010+A12:2011 + A2:2013 EN 60825-1:2007, EN 60825-2:2004+A1+A2 or later (Lasers Safety) 2014/35/EU Low Voltage Directive International Safety of ITE CNS 14336-1 AS/NZX 60950-1 (Australia /New Zealand) IEC 62368-1:2014/AA:2017 IEC 60950-1:2005 (2nd Ed.) + Am1:2009+ Am2:2013 GB 4943.1-2011 ExtremeAccess Series: Hardware Installation Guide...
- Page 43 EN/ETSI 300 386:2008 (EMC Telecommunications) EN/ETSI 300 019 (Environmental for Telecommunications) MEF9 and MEF14 certified for EPL, EVPL, and ELAN Table 22: IEEE 802.3 Media Access Standards IEEE 802.3 IEEE 802.3bz IEEE 802.3at IEEE 802.3bt ExtremeAccess Series: Hardware Installation Guide...
- Page 44 62 to 500 Hz at 0.2 G Packaged random vibration: 5 to 20 Hz at 1.0 ASD w/–3 dB/oct. from 20 to 200 Hz 14 drops minimum on sides and corners at 42 in (<15 kg box) ExtremeAccess Series: Hardware Installation Guide...
-
Page 45: Appendix B: Safety And Regulatory Information
Only trained and qualified service personnel (as defined in IEC 60950-1 and AS/NZS 3260) should install, replace, or perform service to Extreme Networks switches and their components. Qualified personnel have read all related installation manuals, have the technical training and experience necessary to be aware of the hazards to which they are exposed in performing a task, and are aware of measures to minimize the danger to themselves or other persons. -
Page 46: General Safety Precautions
Make sure that your power supplies meet the site DC power or AC power requirements of all the network equipment. • Racks for Extreme Networks equipment must be permanently attached to the floor. Failure to stabilize the rack can cause the rack to tip over when the equipment is removed for servicing. •... -
Page 47: Cable Routing For Lan Systems
Install all cables in a manner that avoids strain. Use tie wraps or other strain relief devices. Cable Routing for LAN Systems Extreme Networks equipment meets the requirements for LAN system equipment. LAN systems are designed for intra-building installations; that is, cable runs between devices must be in the same building as the connected units, except under the conditions listed in the next paragraph. -
Page 48: Installing Power Supply Units And Connecting Power
When you install DC power supplies or connect DC power: • Extreme Networks DC power supplies do not have switches for turning the unit on and off. Make sure that the DC circuit is de-energized before connecting or disconnecting the DC power cord at the DC input power socket. -
Page 49: Selecting Power Supply Cords
Extreme Networks product. Fiber Optic Ports and Optical Safety The following safety warnings apply to all optical devices used in Extreme Networks equipment that are removable or directly installed in an I/O module or chassis system. ExtremeAccess Series: Hardware Installation Guide... - Page 50 Never alter, modify, or change an optical device in any way other than suggested in this document. GBIC, SFP (Mini-GBIC), QSFP+, XENPAK, and XFP Regulatory Compliance Extreme Networks pluggable optical modules and direct-attach cables meet the following regulatory requirements: •...
- Page 51 This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. ExtremeAccess Series: Hardware Installation Guide...
- Page 52 Veuillez communiquer avec l’assistance technique pour du soutien. Il y a risque d’explosion si la pile est remplacée par un type de pile incorrect. Éliminez les piles usées en conformité aux règlements locaux d'élimination des piles. ExtremeAccess Series: Hardware Installation Guide...
- Page 53 Hazardous Substances- China and Taiwan BSMI RoHS Guidance concerning the China and Taiwan BSMI RoHS (Restriction of Hazardous Substances) directive for this Extreme Networks product can be found on the following web page: www.extremenetworks.com/support/documentation/restriction-hazardoussubstances/ The page contains tables detailing the presence of 10 substances defined by the RoHS directive.
-
Page 54: Index
21 system protection 14 category 5 cable 17 Class A ITE Notice 51 commercial building standards 25 components fiber optic cable optional 34 bend radius 18 configuring the switch 36 connecting 35 connecting handling 18 to management console 36 installing 18 ExtremeAccess Series: Hardware Installation Guide... - Page 55 RFI, see radio frequency interference (RFI) connecting to switch 36 RJ45 cable 22 settings 36 mounting brackets attaching to two-post rack 28 mounting kit safety two-post rack 28 requirements 45 when installing PSUs 26 ExtremeAccess Series: Hardware Installation Guide...
- Page 56 UTP cable UPS (uninterruptible power supply) requirements 24 selecting 24 transition time 25 UTP cable bend radius 17 category 5 17 discharge ESD 17 preventing RFI 23 virtualization license 9 VOSS initial login 36 license options 9 VSP Series switches license options 9 ExtremeAccess Series: Hardware Installation Guide...
