SETUP MENU

Modulation Select

RX FORMAT:
ZHD 96
The modulation menu is where the receive format is set. Modulation is simply the way a transmitter
"modulates", or sends, its signal to the URX50. This setting needs to match the modulation mode that the
corresponding transmitter is set to - if the two setting do not match the URX50 will not be able to receive and
decode the signal from the transmitter.
Modulation types
MONO XR - Select when receiving audio from a transmitter sending mono, stereo or XR modulation.
•
ZHD 96 - Select when receiving signal from a ZHD transmitter set to ZHD-96.
•

Unit Code

URX CODE: 1
This is where the code is set to identify the URX. Each URX needs to have a unique identifier code so it can be
controlled by the remote GUI.

IFB Voting

IFB VOTING: ON
200KHZ OFFSET
The IFB voting feature will allow the URX50 to automatically switch to a secondary frequency when it loses its
signal from the primary transmitter. One purpose of this is, on a large set, a second transmitter can be placed at
a distant location, so if the URX50 loses the signal from one transmitter it will automatically switch to the other
transmitter.
To use IFB voting just set the offset in this menu. Then set the second transmitters frequency to the primary
frequency + the offset. So, for example if the primary frequency is 560.000 MHz and the offset is 200 KHz then
the second transmitter should be set to 560.200 MHz
