Refrigerator Service Manual
i.Series
and Horizon Series™
®
Model Group
Blood Bank
Laboratory
Pharmacy
HELMER SCIENTIFIC
14400 Bergen Boulevard
Noblesville, IN 46060 USA
PH +1.317.773.9073
FAX +1.317.773.9082
USA and Canada 800.743.5637
360127-D/D
i.Series
iB111 (Version D)
iB120, iB125, iB245, iB256 (Version D)
iLR111 (Version D)
iLR120, iLR125, iLR245, iLR256 (Version D)
iPR111 (Version D)
iPR120, iPR125, iPR245, iPR256 (Version D)
Horizon Series
HB111 (Version D)
HB120, HB125, HB245, HB256 (Version D)
HLR111 (Version D)
HLR120, HLR125, HLR245, HLR256 (Version D)
HPR111 (Version D)
HPR120, HPR125, HPR245, HPR256 (Version D)
0086
ISO 13485:2003 CERTIFIED
