- Page 1 Steelcase, Inc. Grand Rapids, MI 49501 U.S.A. 1-888-783-3522 Kickplate Onto A 2” Panel Package Contents Screws Panel kickplate retainers Retainer clips Kickplate Tools Assembly Directions Printed In U.S.A. 93-9501070 A Page 1 of 4...
- Page 2 Lay kickplate on it’s back. Attach retainer clips into open fold channels. Attach one clip on each end of kickplate and one clip in the center of plate. RETAINER CLIP RETAINER CLIP PANEL SURFACE CENTER OF PANEL PANEL KICKPLATE RETAINERS HOLE FOR STANDARD PANEL HOLE FOR...
- Page 3 PANEL SURFACE KICKPLATE RETAINERS PANEL KICKPLATE PANEL SURFACE PANEL KICKPLATE Press panel kickplate toward panel surface in direction of arrow “A”. Slide panel kickplate down in direction of arrow “B”, thus engaging top return flange over top edge of kickplate retainer and engaging hooks into panel upright.
- Page 4 NOTE: Because of differences in fabric thickness it may be necessary to open attaching hooks on panel kickplates. If kickplate fails to fully engage into panel uprights, us a flat tip screwdriver to open kickplate hooks by rotating screwdriver. Assembly Directions Page 93-9501070 REV A 4 of 4...
