■ chapter 1 getting to know the basics
Ethernet
Your computer is equipped with a 10/100Base-TX Fast Ethernet network adapter. Connect the active LAN cable
to the RJ-45 LAN port located on the right side of the computer. This allows you to access and transmit data in
the local area network.
Connecting to the Network
Use Unshielded Twisted Pair (UTP) Ethernet cable only.
1. Insert one end of the UTP cable into the network connector until the connector snaps securely into the
receptacle.
2. Either connect the other end of the cable to an RJ-45 jack wall outlet or to an RJ-45 port on a UTP
concentrator or hub in the network.
Cabling Restriction for Networks
The following restrictions should be observed for 100BASE-TX networks:
The maximum cable run length is 100 meters(m) (328 feet[ft]).
For 100-Mbps operations, use Category 5 wiring and connections.
Note:
Consult Windows manual and / or Novell Netware user's guide for the software installation, configuration and operation of the
network.
1-15
