Summary of Contents for AVERATEC AV2150-EH1
- Page 1 Preface Chapter 1 General Introductions Getting Started Chapter 2 Customizing this Notebook Chapter 3 BIOS setup Chapter 4...
-
Page 2: Preface
Notebook Regulations Information FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 3: Fcc Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. AVERATEC, Inc. I4L-MS6833 Preface... -
Page 4: Safety Guideline For Using Lithium Battery
Notebook Preface Safety Guideline for Using Lithium Battery (Danish) ADVARSEL! Lithiumbatteri --- Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af same fabrikat og type. Levé det brugte batteri tilbage til leverandøren. (Deutsch) VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der Batterie. -
Page 5: Caution On Using Modem
Notebook Caution on Using Modem Never install telephone wiring during a lightning storm. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. Use caution when installing or modifying telephone lines. -
Page 6: Safety Instructions
Notebook Safety Instructions Read the safety instructions carefully and thoroughly. Save this User Guide for possible use later. Keep this equipment away from humidity and high temperature. Lay this equipment on a stable surface before setting it up. The openings on the enclosure are used for air convection and to prevent the equipment from overheating. - Page 7 Notebook 11. Never pour any liquid into the opening that could damage the equipment or cause an electrical shock. 12. Do not leave the equipment in an unconditioned environment with a storage temperature of 60 equipment. 13. To prevent explosion caused by improper battery replacement, use the same or equivalent type of battery recommended by the manufacturer only.
-
Page 8: Trademarks
Notebook Trademarks All trademarks are the properties of their respective owners. Microsoft is a registered trademark of Microsoft Corporation. Windows®98/ME, 2000/XP are registered trademarks of Microsoft Corporation. ® is a registered trademark of American Megatrends Inc. PCMCIA and CardBus are registered trademarks of the Personal Notebook Memory Card International Association. -
Page 9: Copyright Notice
Preface Copyright Notice The material in this guide is the intellectual property of AVERATEC, INC. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are under continual improvement and we reserve the right to make changes without notice. -
Page 10: Table Of Contents
Notebook Table of Content Preface Regulations Information FCC-B Radio Frequency Interference Statement FCC Conditions Safety Guideline for Using Lithium Battery Caution on Using Modem CD-ROM Drive Notice Safety Instructions Trademarks Release History Copyright Notice Technical Support Chapter 1: Introductions How to Use This Manual Unpacking Chapter 2: Getting Started Specification... -
Page 11: Chapter 3: Customizing This Notebook
Notebook Product View Top-open View Front View Right-side View Left-side View Rear View Bottom View Power Management AC Adapter Battery Pack Using the Battery Pack Basic Operations Knowing the Keyboard Knowing the Touchpad About Hard Disk Drive Using the Optical Storage Chapter 3: Customizing this Notebook Connecting the External Devices Connecting the Peripheral Devices... - Page 12 Notebook Safely Remove Hardware Chapter 4: BIOS Setup About BIOS Setup When to Use BIOS Setup How to Run BIOS Setup Control Keys BIOS Setup Menu Main menu Advanced menu Security menu Boot menu Exit menu Preface...
- Page 13 Preface Chapter 1 General Introduction Getting Started Chapter 2 Customizing this Notebook Chapter 3 BIOS setup Chapter 4...
-
Page 14: How To Use This Manual
Notebook General Introductions How to Use This Manual This User’s Manual provides instructions and illustrations on how to operate this notebook. It is recommended to read this manual carefully before using this notebook. Chapter 1, General Introduction, includes the descriptions of all the accessories of this notebook. -
Page 15: Unpacking
Notebook Unpacking First, unpack the shipping carton and check all items carefully. If any item contained is damaged or missing, please contact the store where you purchased this notebook. Also, keep the box and packing materials in case you need to ship the unit in the future. -
Page 16: Chapter 2 Getting Started
Preface Chapter 1 General Introductions Getting Started Chapter 2 Customizing this Notebook Chapter 3 BIOS setup Chapter 4... -
Page 17: Specification
Notebook Specification Physical Characteristic Dimension Weight Processor Type Processor L2 Cache Core Chips North Bridge South Bridge Memory Technology Memory Maximum Power AC Adapter Battery Type I Storage HDD form factor 11.9” (L) x 8.86” (D) x 1.2” (H) 4.4 lbs. Mobile AMD Turion 64 MT-28 or MT-30 or Mobile Sempron 3000+... - Page 18 Notebook IDE Controller Optical Device I/O Port Monitor(VGA) Headphone Out IEEE1394 Mic-in RJ11 RJ45 Communication Port 56K Fax/MODEM MDC (AC’97) Wireless LAN PCMCIA Controller Slot Display LCD Type Brightness Ultra DMA ATA-100 DVD+/-RW Dual Layer 15 pin Mini D-Sub x 1 x 3 (USB version 2.0) I/F --- AC97 S/W Modem Controller --- AC 97 Embedded...
- Page 19 Notebook Video Controller VRAM CRT Support Display Detect Audio Sound Controller Sound Codec chip Internal Speaker SoundBlaster Sound Volume Software & BIOS Support OS USB Flash Boot BIOS Others Kensington Lock Hole Compliance RS482M Shared System Memory 1280 x 800 WXGA 800x600, max, 32bit color 1024x768, max, 32bit color 1280x800, max, 32bit color...
-
Page 20: Product Overview
Notebook Getting Started Product Overview This section provides you the description of basic aspects of your Notebook. It will help you to know more about the appearance of this Notebook before using Top-open View Press the Cover Latch to open the top cover (LCD Panel). Cover Latch (Internal View) - Page 21 Notebook Rubber Pads Protects the display when closing the top cover. Stereo Speakers Outputs sound. Quick Launch Buttons and Power Button Power Button: To turn your Notebook ON and OFF. Quick Launch Buttons: Simply click the quick launch buttons to speed up the starting of the programs in common use.
-
Page 22: Front View
Notebook Front View Cover Latch (External View) Slide the cover latch towards the right and lift the cover. IEEE 1394 The IEEE 1394 port allows you to connect high-end digital devices such as a digital video camera or connect to another computer that has a 1394 port. Audio Port Connectors Line In: Use for external CD player, tape recorder or other audio devices. - Page 23 Notebook Status LED Num Lock: Glowing Blue when the Num Lock function is activated. Caps Lock: Glowing Blue when the Caps Lock function is activated. Scroll Lock: Glowing Blue when the Scroll Lock function is activated. Hard Disk In-use: Blinking Blue when Notebook is accessing the hard disk drive.
-
Page 24: Right-Side View
Notebook Right-side View USB Port The USB 2.0 ports allow you to connect USB devices such as a mouse, keyboard, MP3 player, portable hard drive, printer and more. RJ-11 Connector This is the connector of the built-in modem that allows you to connect to an Internet Service Provider (ISP) or send and receive fax. -
Page 25: Left-Side View
Notebook Left-side View Optical Storage Device The slim DVD+/-RW Dual Layer drive allows you to burn on CD-R, CD-RW, DVD-R, DVD+R, DVD-RW, DVD+RW and Dual Layer DVD media. The multi-purpose optical drive also allows you to install software and play music and movies. -
Page 26: Rear View
Notebook Rear View Kensington Lock Slot This is used to lock the Notebook to an immovable object for security purposes. Battery Pack (Rear View) Supplies power to your Notebook when the AC adapter is not connected Getting Started... -
Page 27: Bottom View
Notebook Bottom View Battery Lock/Unlock Button Secures the battery when the latch is in the lock position. Once the latch is pushed to the unlock position, the battery can be removed. Vent Getting Started... - Page 28 Notebook The vent is designed to cool the system. DO NOT block the vent for air circulation. Battery Release Button Releases the battery pack. Slide with one hand and pull the battery pack out carefully. Battery Pack Supplies power to your Notebook when the AC adapter is not connected. Screw hold for removal of the Optical Device Getting Started...
-
Page 29: Connecting The Ac Power
Notebook Power Management AC Adapter Please be noted that it is strongly recommended to connect the AC adapter and use the AC power while using this Notebook for the first time. When the AC adapter is connected, the battery will be charged. NOTE that the AC adapter included in the package is approved for your Notebook;... -
Page 30: Disconnecting The Ac Power
Notebook Disconnecting the AC Power When you disconnect the AC adapter, you should: Unplug the power cord from the electrical outlet first. Unplug the connector from the Notebook. Disconnect the power cord and the connector of AC adapter. When unplugging the power cord, always hold the connector part of the cord. - Page 31 Notebook Getting Started...
-
Page 32: Replacing The Battery Pack
Notebook Replacing the Battery Pack Insert the right side of battery pack into the compartment. Slightly slide and press the battery pack into the right place. After the right side of the battery pack fitting the right track, then slightly press the left side of battery pack into the battery chamber. Make sure the Lock/Unlock Button is in the lock position. -
Page 33: Conserving Battery Power
Notebook Using the Battery Pack Battery Safety Tips Replacing or handling the battery incorrectly may present a risk of fire or explosion, which could cause serious injury. Only replace the main battery pack with the same or equivalent type of battery. -
Page 34: Charging The Battery Pack
Notebook Charging the Battery Pack The battery pack can be recharged while it is installed in the Notebook. Please pay attention to the following tips before recharging the battery: If a charged battery pack is not available, save your work and close all running programs and shut down the system or Hibernate. -
Page 35: Knowing The Keyboard
Notebook Basic Operations Knowing the Keyboard The Notebook’s keyboard provides all the functions of a full size keyboard and an additional [Fn] key for specific notebook functions. The keyboard can be divided into four categories: Typewriter keys, Cursor keys, Numeric keys and Function keys. -
Page 36: Typewriter Keys
Notebook Typewriter Keys The function of these Typewriter keys is the major function of the keyboard, which is similar to the keys on a typewriter. It also provides several keys for special purposes, such as the [Ctrl], [Alt] and [Esc] key. When the lock keys are pressed, the corresponding LEDs will light up to indicate their status: Num Lock: Press and hold the [Fn] key and press this key to toggle... -
Page 37: Cursor Keys
Notebook Cursor Keys The keyboard provides four cursor (arrow) keys and [Home], [PgUp], [PgDn], [End] keys at the lower right corner, which are used to control the cursor movement. Move the cursor left for one space. Move the cursor right for one space. Move the cursor up for one line. -
Page 38: Numeric Keys
Notebook The Backspace key, [Ins] and [Del] keys at upper right corner are use for editing purpose. This key is used to switch the typing mode between “insert” and “overtype” modes. Press this key to delete one character to the right of the cursor and move the following text left for one space. -
Page 39: Function Keys
Notebook Function Keys Windows Keys You can find the Windows Logo key ( ) on the keyboard, which are used to perform Windows-specific functions, such as opening the Start menu and launching the shortcut menu. For more information of the two keys, please refer to your Windows manual or online help. -
Page 40: Knowing The Touchpad
Notebook Knowing the Touchpad The integrated touchpad in your Notebook is a pointing device that works similar to a mouse. It allows you to control the Notebook by pointing the location of the cursor on the screen and making selection with its two buttons. Cursor Movement Area This pressure-sensitive area of the touchpad, allows you to place your finger on it and control the cursor on the screen by moving your finger. -
Page 41: Using The Touchpad
Notebook Using the Touchpad Read the following description to learn how to use the touchpad: Positioning and Moving Place your finger on the touchpad (usually using the forefinger), and the rectangular pad will act as a miniature duplicate of your display. When you move your fingertip across the pad, the cursor on the screen will move simultaneously in the same direction. - Page 42 Notebook desired location; finally, release the left button to finish the drag-and-drop operation. Move the cursor by sliding your fingertip. Using the Touchpad Put your wrist on the desk comfortably. Getting Started...
- Page 43 Notebook Getting Started Configuring the Touchpad You can customize the pointing device to meet your personal needs. For example, if you are a left-hand user, you may want to swap the functions of the two buttons. In addition, you can change the size, shape, moving speed and other advanced features of the cursor on the screen.
-
Page 44: About Hard Disk Drive
Notebook About Hard Disk Drive Your Notebook is equipped with a 2.5-inch 9mm IDE hard disk drive. The hard disk drive contains the operating system and software applications. To avoid unexpected data loss in your system, please backup your critical files regularly. Do not turn off the Notebook when the Hard Disk In-use LED is on. -
Page 45: Using The Optical Storage
Notebook Using the Optical Storage Your Notebook is equipped with an optical storage device, which is known as a DVD Dual drive. CD-ROM Drive: Allows you to read CD disks, including audio CDs and CD-R/RW disks. DVD-ROM Drive: Allows you to read DVD disks and CD disks, including movie DVDs, audio CDs and CD-R/RW disks. -
Page 46: Inserting The Cd
Notebook Inserting the CD The following instruction describes the general procedure when operating the optical storage device, including the DVD-ROM drive. Confirm that the Notebook is turned on. Press the Eject Button on the drive’s panel and the CD tray will slide out partially. -
Page 47: Removing The Cd
Notebook Removing the CD Confirm that the Notebook is turned off. Press the Eject Button on the drive’s panel and the CD tray will slide out partially. Then, gently pull the tray out until fully extended. Hold the CD by its edge with your fingers and lift it up from the tray. Push the tray back into the drive. - Page 48 Chapter 1 Chapter 2 Customizing this Notebook Chapter 3 Chapter 4 Preface General Introductions Getting Started BIOS setup...
-
Page 49: Connecting External Devices
Notebook Connecting External Devices The I/O (input/output) ports on the Notebook allow you to connect peripheral devices. Modem IEEE 1394 Device Mouse/ Keyboard Customizing this Notebook Speakers/ Earphones Microphone Printer Television Monitor... -
Page 50: Connecting The Peripheral Devices
Notebook Connecting the Peripheral Devices Connecting the Mouse You can connect a mouse to your Notebook through the USB port. If your mouse has a PS/2 connector, you will need a PS/2-to-USB converter. To connect the mouse: Turn on the Notebook and install the mouse driver. Connect your mouse to the Notebook. -
Page 51: Connecting The External Monitor Or Tv
Notebook connect the Webcam: Turn on the Notebook and install the Webcam driver. Connect your Webcam to the Notebook. The Notebook may auto detect your Webcam driver and enable the Webcam function. If there is no detection of you Webcam you can manually enable the Webcam by going to Start Menu à... -
Page 52: Connecting The Ieee 1394 Devices
Notebook Turn on the Notebook and the monitor should respond by default. If not, you can switch the display mode by pressing [Fn]+[F2]. Alternately, you can change the display mode by configuring the settings in Display Properties of Windows operating system. Connecting the IEEE 1394 devices The IEEE 1394 port of your Notebook is a next-generation serial bus that features a high-speed transfer rate and the connection of up to 63 devices,... -
Page 53: Connecting The Communication Devices
Notebook Connecting the Communication Devices Using the LAN The RJ-45 connector of the Notebook allows you to connect a LAN (local area network) device, such as a hub, switch or gateway to build a network connection. The integrated 10/100 Base-T LAN module supports data transfer rate up to 100 Mbps. -
Page 54: Installing The Pc Card
Notebook PC Card Installation The PC card slot of your Notebook allows you to install a Type-II PC card or CardBus card. The following instruction provides you with a basic installation for the PC card, including how to install and remove it. For more information, please refer to the manual of your PC card. -
Page 55: Removing The Pc Card
Notebook Removing the PC card Press the Eject Button to make it stretch out. Push the Eject Button and the PC card will slide out. Pull it out of the slot. Do not hold the “golden finger” when installing the PC card; otherwise, it may cause interference or damage to the PC card. -
Page 56: Safely Remove Hardware
Notebook Customizing this Notebook Safely Remove Hardware If you connect any peripheral device to your system, the Safely Remove Hardware icon ( ) will appear on the taskbar. Double-click the icon to bring up the Safely Remove Hardware dialog box. You will see all the connected devices. - Page 57 Chapter 1 Chapter 2 Customizing this Notebook Chapter 3 Chapter 4 Preface General Introductions Getting Started BIOS setup...
-
Page 58: When To Use Bios Setup
Notebook About BIOS Setup When to Use BIOS Setup? You may need to run the BIOS Setup when: An error message appears on the screen during the system booting up and requests you to run SETUP. You want to change the default settings for customized features. You want to reload the default BIOS settings. -
Page 59: Control Keys
Notebook Control Keys You can use only the keyboard to control the cursor in the BIOS Setup Utility. Press left arrow to select one menu title. Press right arrow to select one menu title. Press up arrow to select one item under the menu title. -
Page 60: Bios Setup Menu
Notebook BIOS Setup BIOS Setup Menu Once you enter the BIOS Setup Utility, the Main menu will appear on the screen. The Main menu displays the system information, including the basic configuration. Main menu Show System Overview information about BIOS version, CPU features, Memory size and setting of System Time and Date. -
Page 61: System Overview
Notebook Main menu System Overview System Overview will show you BIOS version and other information about its build date and update notes. Following is CPU’s information about its Type and Speed. The variable settings in Main menu are Share Memory, System Time and System Date. - Page 62 Notebook System Time This item allows you to set the system time. The system clock will go on no matter you shut down the PC or get into sleep mode. The set format is [hour:minute:second]. System Date This item allows you to set the system date. [day:month:date:year].
-
Page 63: Advanced Settings
Notebook Advanced menu Advanced Settings Primary IDE Master/Slave The two items display the types of the primary master/slave IDE devices installed in the Notebook. Press [Enter] to bring up a window showing the detailed information of the device, including the device name, vendor, LBA mode, PIO mode and more. -
Page 64: Security Menu
Notebook Security menu Security Settings Change Supervisor/User Password When you select the function, a message box will appear on the screen as below: Enter New Password Type the password you want, up to six characters in length and press [Enter]. The password entered will replace any previously set password from CMOS memory. - Page 65 Notebook When the Supervisor Password is set, the new item User Access Level and Password Check will be added in the menu. You can change the user access right in the User Access Level item. Setting options: No Access, View Only, Limited and Full Access. The Password Check item is used to specify the type of BIOS password protection that is implemented.
-
Page 66: Boot Menu
Notebook BIOS Setup Boot menu 1st, 2nd and 3rd Boot Device Setting The three items allow you to set the sequence of boot devices. -
Page 67: Exit Menu
Notebook BIOS Setup Exit menu Save Changes and Exit Save the changes you have made and exit the utility. Discard Changes and Exit Exit the utility without saving the changes you have made. Discard Changes Abandon your changes and reload the previous configuration. Load Optimal Defaults Select this item to load the default settings for optimal system performance.
