AVERATEC
6200 Series Notebook PC
User Manual
I

Advertisement

Table of Contents
loading

Related Manuals for AVERATEC AV6240-EH1

Summary of Contents for AVERATEC AV6240-EH1

  • Page 1 AVERATEC 6200 Series Notebook PC User Manual...

  • Page 2: Regulations Information

    Regulations Information FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Safety Guideline For Using Lithium Battery

    Safety Guideline for Using Lithium Battery (Danish) ADVARSEL! Lithiumbatteri – Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren. (Deutsch) VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleich-wertigen Typ.

  • Page 4: Caution On Using Modem

    5. Avoid using the telephone function (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. 6. Do not use the telephone function to report a gas leak in the vicinity of the leak. 7. Use cable recommended in the User Guide.

  • Page 5: Safety Instructions

    100~240V before connecting the equipment to the power inlet. 7. Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. 8. Always unplug the power cord before inserting any add-on card or module.

  • Page 6: Release History

    Copyright Notice The material in this guide is the intellectual property of AVERATEC. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are under continual improvement and we reserve the right to make changes without notice.

  • Page 7: Table Of Contents

    Left-side View ...............1-10 Bottom View ................1-12 1.3 Preparing to Operate ............1-13 Connecting the Power ............1-13 Turning On/Off the Notebook PC .........1-15 Basics of Using Notebook PC 2.1 Safety and Comfort Tips .............2-2 Set Up Your Work Environment ..........2-2 Have a Good Work Habit ............2-3 2.2 Knowing the Keyboard ............2-4...
  • Page 8 2.4 Using the Optical Storage Device ........2-13 Inserting the CD ..............2-14 Removing the CD ..............2-15 Releasing the CD Manually ...........2-15 2.5 The Hard Disk Drive ............2-16 2.6 Using the Video Function ...........2-17 Configuring the Display Settings ..........2-17 2.7 Using the Audio Function ...........2-19 Connecting Audio Devices .............2-19...
  • Page 9 5.4 Advanced Settings ...............5-8 5.5 Security Settings ..............5-10 5.6 Boot Settings ................5-11 5.7 Power Settings..............5-12 5.8 Exit Options ................5-13 Expanding and Upgrading 6.1 Connecting the External Devices ........6-2 Connecting the Peripheral Devices ........6-2 Connecting the Communication Devices .......6-4 Installing the PC Card ............6-6...
  • Page 10 Caring Your Notebook PC 7.1 P rotecting Your Notebook PC ........7-2 Locking Your Computer ............7-2 Setting Up Password .............7-3 Using the Anti-Virus Protection ..........7-4 7.2 Tips for Traveling ..............7-5 7.3 Taking Care of Your Computer ..........7-6 Placing and Operating Your Computer ........7-6 Cleaning Your Computer ............7-7...

  • Page 11: Getting Started

    This chapter first provides a general introduction on your Note- book PC, to let you know the hardware components well and start to work easily. Why wait? Read on to learn more about the powerful features and multimedia function of your Notebook...

  • Page 12: Before You Begin

    1.1 Before You Begin Unpacking First, unpack the shipping carton and check all items carefully. If any item contained is damaged or missing, please contact your local dealer immediately. Also, keep the box and packing materials in case you need to ship the unit in the future.

  • Page 13: Features And Benefits

    LAN cable. USB 2.0 Support. The computer has four USB 2.0 ports that support data transfer rate up to 480Mb/s. The USB standard allows you to connect up to 127 devices through the single interface, including mouse, keyboard, printer, hard disk drive, digital camera, and more.

  • Page 14: Quick Components Guide

    This section provides the multi-views of your Notebook PC, and briefly intro- duces the function of each component. Top-open View Press the Cover Latch to open the top cover (see page 1-6), and you can find the main operating area of your computer. 1 - 4...
  • Page 15 Display Panel The 15.4-inch WXGA TFT color LCD screen displays the output of the computer. Quick Launch Buttons and Power Button: - Power Button: to turn the computer power ON and OFF. - Quick Launch Button: this one-touch button allows you to turn on/ off the wireless LAN function easily.

  • Page 16: Front View

    Front View Knowing the components on the front side of your computer. Volume Increase-Decrease Controller Press “+” button to increase volume level and press “-” to decrease volume level. Cover Latch Slide this button toward the right to open the top cover.
  • Page 17 Consumer Infrared It is used to transfer the Remote Controller signal to control the device. Audio Port Connectors Line Out is a connector for speakers or headphones; MIC is a connector for microphones. Line Out 1 - 7...

  • Page 18: Right-Side View

    - Wireless LAN (Green): ON - wireless LAN enabled; OFF - wireless LAN disabled. PC Card Slot The computer provides a PC card slot to support one Type-II PC card for expansion functions, such as LAN/WLAN card, modem card, memory card, etc.
  • Page 19 USB Ports: The USB 2.0 ports allow you to connect USB-interface peripheral devices, such as the mouse, keyboard, modem, external hard disk module, printer, and more. There are two of four USB ports on the right side of your laptop.

  • Page 20: Left-Side View

    RJ-45 Connector The 100/10 Ethernet connector is used to connect a LAN cable for network connection. RJ-11 Connector The computer provides a built-in modem that allows you to connect an RJ-11 telephone line through this connector.
  • Page 21 Optical Storage Device A slim CD-ROM/DVD-ROM/CD-RW/DVD Combo/DVD Dual drive is available in the computer, depending on the model you purchased. The optical device allows you to use the CD/DVD disc for installing software, accessing data, and playing music/movie on the computer.

  • Page 22: Bottom View

    Carefully put the computer upside down, and you can find the core compo- nents of the computer. Battery Pack To supply power to your computer when the AC adapter is not connected (see Introduction to the Power Source in Chapter 4 for more information). HDD Compartment Inside this compartment is the Hard Drive.

  • Page 23: Preparing To Operate

    2. Attach the power cord to the connector of the AC adapter ( ). 3. Plug the DC end of the adapter to the computer ( ), and the male end of the power cord to the electrical outlet ( ).
  • Page 24 When unplugging the power cord, al- ways hold the connector part of the cord, never pull the cord. The AC adapter included in the package is correct for your Notebook PC; using other adapter model may damage the computer or other devices on the computer.

  • Page 25: Turning On/Off The Notebook Pc

    Turning On/Off the Notebook PC Now, when the AC adapter is connected, you are ready to use your computer. Opening the Top Cover First, open the top cover by sliding the cover button on the front side of the computer, and then lifting the top cover gently.
  • Page 26 Turning Off the Computer In Windows operating system, always use the “Shut Down” command of the system to turn off the computer. This is the normal operating procedure that can prevent the system problems. Click Start ( ) from the taskbar, and then select the Turn Off Computer option ( ).
  • Page 27 If you are working on a program, such as Microsoft Word, you should save the data and close the program first, and then turn off the computer. Otherwise, you may lose your data. Confirm that the Hard Disk In-use LED is OFF before turning off the computer.

  • Page 28: Basics Of Using Notebook Pc

    Notebook PC This chapter introduces the operating basics for your Notebook PC, including the use of keyboard, touchpad, LCD panel, hard disk drive, and optical storage device. It also includes the ad- vanced features such as Direct Play and communication functions.

  • Page 29: Safety And Comfort Tips

    6200 Series Notebook PC 2.1 Safety and Comfort Tips If you are a beginner to the Notebook PC, please read the following tips to rt TiSet Up Your Wo make yourself safe and comfortable during the operation. Set Up Your Work Environment The Notebook PC is a poratble platform that allow you to work anywhere.

  • Page 30: Have A Good Work Habit

    Setting up your work environment Have a Good Work Habit Have a good work habit is important if you have to work with your Notebook PC for long periods of time; otherwise, it may cause discomfort or injury to you.

  • Page 31: Knowing The Keyboard

    2.2 Knowing the Keyboard The Notebook PC’s keyboard provides all the functions of a full-sized 87/88- key keyboard, and an additional [Fn] key for specific functions on the computer. How to use keyboard can divide into four categories: Typewriter keys, Cur- sor keys, Numeric keys, and Function keys.

  • Page 32: Typewriter Keys

    The Typewriter Keys The function of these Typewriter keys is the major function of the keyboard, which is similar to the keys on a typewriter. It also provides several keys for special purposes, such as the [Ctrl], [Alt], and [Esc] keys.

  • Page 33: Cursor Keys

    Move to the next page. Move to the beginning of the line (or document). Move to the end of the line (or document). The Backspace key, [Ins] and [Del] keys at the upper right corner are use for editing purpose. 2 - 6...

  • Page 34: Numeric Keys

    This key is used to switch the typing mode between “insert” and “overtype“ modes. Press this key to delete one character to the right of the cursor, and move the following text left for one space. Press this key to delete one character to the left of the cursor, and move the following text left for one space.

  • Page 35: Function Keys

    The keyboard provides a [Fn] key ( ) at the lower left corner, which is to be used with another key to perform the alternative function of a key. This com- bination of keys can be called “hot key” in operating your Notebook PC, which allows you to perform some special functions easily and quickly.
  • Page 36 The touchpad integrated in your computer is a pointing device that compat- ible with the standard mouse, allowing you to control the computer by point- ing the location of the cursor on the screen and making selection with its two buttons.

  • Page 37: Using The Touchpad

    When you move your fingertip across the pad, the cursor on the screen will move simultaneously in the same direction. When your finger reaches the edge of the pad, lift your finger and replace it on a proper location of the touchpad.
  • Page 38 Put your wrist on the desk comfortably. Using the Touchpad Do not place heavy/sharp objects on the touchpad; do not scratch the surface of touchpad. Clean the touchpad with soft dry cloth regularly to prevent the dust and liquids on it.

  • Page 39: Configuring The Touchpad

    You can customize the pointing device to meet your personal needs. For example, if your are a left-hand user, you may want to swap the functions of the two buttons. In addition, you can change the size, shape, moving speed, and other advanced features of the cursor on the screen.

  • Page 40: Using The Optical Storage

    2.4 Using the Optical Storage Your computer is equipped with an optical storage device, which is know as the CD/DVD-ROM, CD-RW, DVD Combo and DVD Dual drive. The actual de- vice installed in your computer depends on the model you purchased.

  • Page 41: Inserting The Cd

    DVD-ROM drive. Confirm that the computer is turned on. Press the Eject Button on the drive’s panel ( ), and the CD tray will slide out partially. Then, gently pull the tray out until fully extended ( ).

  • Page 42: Removing The Cd

    Press the Eject Button on the drive’s panel, and the CD tray will slide out partially. Then, gently pull the tray out until fully extended. Hold the CD by its edge with your fingers, and then lift it up from the tray.

  • Page 43: The Hard Disk Drive

    2.5 The Hard Disk Drive Your computer is equipped with a 2.5-inch IDE (Integrated Drive Electronics) hard disk drive. The hard disk drive is a storage device with much higher speed and larger capacity than other storage devices, such as the floppy disk drive and optical storage devices.

  • Page 44: Using The Video Function

    2.6 Using the Video Function Configuring the Display Settings Your Notebook PC has been set to a default resolution and colors when shipping: Now, you can change the settings to meet your needs through the operating system. Changing the Resolution and Colors Quality Click Start from the taskbar, and select Control Panel to open the Control Panel window.
  • Page 45 Under the Displays tab, if you have connected the external display device, such as the CRT monitor or TV, simply select the one you want to use and click OK. (You can also use the hot key [Fn]+[F2] on the keyboard to switch the display output device.)

  • Page 46: Using The Audio Function

    Volume Control Double-click the Volume Control icon on the taskbar, and the Master Volume dialog box will appear as shown below. You can move the slide bar to adjust the volume. 2 - 19...

  • Page 47: Direct Play Function

    Move down Select/Enter Press to return to Press to enter the upper-level menu. the sub-menu. Press to select the highlighted item. Press to scroll through the menu items. Example of using control keys at Setup Menu mode 2 - 20...

  • Page 48: Key Definition

    Key Definition Remote Controller : Next CH+ turn to FW, and Pre CH- turn to RW, by pressing the buttom over 1 second. MENU POWER PLAY/PAUSE CH-/<< CH+/>> STOP AUDIO VOL+ REPEAT VOL- Remote control key define in any mode...

  • Page 49: Message On The Lcm

    6200 Series Notebook PC Director play key define VOL- VOL+ PLAY/ STOP MENU POWER PAUSE Direct play key define in any mode ITEM AV_MODE MENU (DVD) PLAY/PAUSE PLAY/PAUSE OK/ENTER PLAY/PAUSE STOP/EJECT STOP/EJECT STOP/EJECT VOL+ VOL+ VOL+ VOL- VOL- VOL- MENU...

  • Page 50: Using The Software Applications

    Using the Software Applications Your Notebook PC provides you with the useful software appli- cations and the required drivers for the system in the Recovery CD, which allows you to resume your operating system easily and quickly.

  • Page 51: Using The Recovery Cd

    3.1 Using the Recovery CD The Recovery CD is a compact disk that records the sources of operating system and important data and can be used to restore the hard disk to its original state. When the operating system of your computer is damaged and can not work properly any more, you can use the Recovery CD to re- sume the system in its original state.
  • Page 52 The Recovery CD (x3) includes: Drivers provides the required drivers for the system. Utility contains the powerful utilities that can maximizing your experience in oper- ating the computer. Software Applications MS Works 7.0; CyberLink DVD Solution; Norton AntiVirus 2004; Acrobat Reader 6.0;...

  • Page 53: Activating Your System

    Next to proceed to the next step. 4. What’s your computer’s name? Choose a name for your PC that will help you identify it on your home network, if you have one. In order for your computer to appear on a network,...

  • Page 54: Power Management

    Power Management This chapter tells you how to manage the power effectively, in order to maintain the longest battery life and increase the productivity when you are using the computer. 2 - 1...

  • Page 55: Introduction To The Power Source

    100~240V AC. This allows you to use your computer at any place when traveling. The AC adapter is used as a converter that transfers the alternating current (AC) to direct current (DC), to supply power to your computer.

  • Page 56: The Battery Pack

    The Battery Pack The rechargeable Li-ion battery pack is an internal power source of the computer. A fully charged battery pack can supply power to the computer up to 2.5 hours, depending on the actual use of your computer. Charging the Battery The battery pack can be charged while it is installed in the Notebook PC.
  • Page 57 6200 Series Notebook PC If the Power Meter icon does not appear on the taskbar, you can configure the setting through Start menu. Click Start and select Control Panel to open the Control Panel window. Then, click the Performance and Maintenance item.
  • Page 58 Changing the Battery Pack You can purchase an additional battery pack from your local dealer, so that you can use it as a spare when traveling. To remove the battery pack: Confirm that the computer is turned off. Locate the Battery Unlock Button on the rear side of the computer.

  • Page 59: Managing The Power

    The Windows XP operating system supports ACPI (Advanced Configuration and Power Interface), which allows you to manage the computer power easily and efficiently. With the ACPI function, the power can be distributed to different components individually according to their needs. This is helpful to provide you with the maximum battery usage or optimal system performance.
  • Page 60 Under the Alarms tab, you can activate the battery alarm function by checking the options in Low battery alarm and Critical battery alarm fields. Once activated, adjust the slide bar to set up the low or critical power level (the default setting is 10%).
  • Page 61 6200 Series Notebook PC Under the Advanced tab, you can set up the actions when pressing the power button, sleep button, and closing the LCD panel. Set up the Power buttons’ function: Stand by, Hibernate, or Shut down. Pressing [Fn]+[F12] allows your computer to enter suspend mode immediately.
  • Page 62 Power button, you can resume the previous status when you left off. To enter the Hibernation mode, click Start and select Turn off Computer. Press and hold the [Shift] key ( ), so that the Stand By option changes to Hibernate. Click Hibernate ( ) to enter the Hibernation mode.

  • Page 63: Bios Setup

    BIOS Setup BIOS (Basic Input/Output System) is a program for setting up the configuration of the computer. To take full advantage of your computer and connected peripheral devices, you should configure the system through BIOS Setup. This chapter provides the information of BIOS Setup Utility, and guides you to configure the system for optimal use.

  • Page 64: Using Bios Setup Utility

    You want to reload the default BIOS settings. How to Run BIOS Setup? To run the BIOS Setup Utility, turn on the computer and press the [Del] key during the POST procedure. If the message disappears before you respond and you still wish to enter Setup, restart the system by turning it OFF and On, or simultaneously pressing [Ctrl]+[Alt]+[Delete] keys to restart.

  • Page 65: Control Keys

    Control Keys You can use only the keyboard to control the cursor in the BIOS Setup Utility. Move the cursor left to select one menu title. Move the cursor right to select one menu title. Move the cursor up to select one item under the menu title.

  • Page 66: Main Menu

    6200 Series Notebook PC 5.2 Main Menu Once you enter the BIOS Setup Utility, the Main menu will appear on the screen. The Main menu displays the system information, including the basic configuration. System Overview Use this menu for basic information of BIOS version and Processor and system configurations, such as time, date etc.
  • Page 67 Security Settings Use this menu to set security password and change the status of using password. Exit Menu Use this menu to choose whether saving your changes or not. Available settings for “1st/2nd Boot Device” vary depending on the bootable devices you have installed. For example, if you did not install a floppy drive, the setting “Floppy”...

  • Page 68: System Overview

    The third field shows information of System Memory Size. System Time The status is [hour:minute:second]. Use [ENTER], [TAB] or [SHIFT-TAB] to select a field and use Shift plus [+] to increase values and single [-] to decrease values. Hour The value is set from 00 to 23 in 24hr format.
  • Page 69 This allows you to set the system date you want (usually the current date). The status is <day> <month> <date> <year>. Use [ENTER], [TAB] or [SHIFT- TAB] to select a field and use Shift plus [+] to increase values and single [-] to decrease values.

  • Page 70: Advanced Settings

    Therefore, you must be careful before changing any default value. CPU Configuration To set options for CPU. Once you enter this field, you will see information about CPU manufacture and specification. Two Functions can be set by users. ACPI APIC support Include ACPI APIC table pointer to RSDT pointer list.
  • Page 71 Disable/Enable device write protection. This will be effective only if device is accessed through BIOS. USB Devices Enabled It shows enabled USB Devices if there is at least one enabled. If there is no USB Devices enabled, it will show status by None. Legacy USB Support It enables support for legacy USB.

  • Page 72: Security Settings

    To install or change Supervisor Password by enter new password. Change User Password To install or change User Password by enter new password. Clear User Password It is a quick way to clear supervisor and user password by two options: [Ok]/[Cancel]. 5 - 10...

  • Page 73: Boot Settings

    Boot Settings Press <Enter> and the following sub-menu appears. Quick Boot It allows BIOS to skip certain tests while booting. It will save time to boot the system. There are two options available: [Disabled] and [Enabled]. Default setting is [Enabled].

  • Page 74: Power Settings

    Power Settings Press <Enter> and the following sub-menu appears. Wake on LAN Wake on Broadcom LAN. There are two options: [Disabled] and [Enabled]. Default setting is [Enabled]. Wake on MDC There are two options: [Disabled] and [Enabled]. Default setting is [Enabled].

  • Page 75: Exit Options

    Save Changes and Exit Exit system with saving the changes. Discard Changes and Exit Exit system setup without saving any change. Press Enter or ESC can set up this option. Discard Changes Discard Changes without exiting. It is used when you need to change some- thing else.

  • Page 76: Expanding And Upgrading

    Expanding and Upgrading You can expand the capabilities of your Notebook PC and upgrade your system for your necessary. This chapter introduces the installation of optional devices/components for your Notebook PC. 2 - 1...

  • Page 77: Connecting The External Devices

    6200 Series Notebook PC 6.1 Connecting the External Devices The I/O (input/output) ports on the rear panel of the computer allow you to connect peripheral devices. For the information of these I/O ports, please refer to Quick Components Guide in Chapter 1.
  • Page 78 Connecting the TV (PC only) The S-Video connector of your computer allows you to use a TV to display the computer images for your specific purpose, such as enjoying your DVD movies. To connect a TV, you will need the S-Video cable (not included). Then, you can configure the display settings as described in the section Using the Video Function of Chapter 2.

  • Page 79: Connecting The Communication Devices

    Using the LAN The RJ-45 connector of the computer allows you to connect the LAN (local area network) devices, such as a hub, switch, and gateway, to build a network connection. This built-in 10/100 Base-T LAN module supports data transfer rate up to 100Mbps.
  • Page 80 Using the Modem The built-in 56Kbps fax/data modem allows you to use a telephone line to communicate with others, or to dial-up to connect the Internet. It should be noticed that Cable size has to be at least 26 or above.

  • Page 81: Installing The Pc Card

    Locate the PC card slot on your notebook computer. If there is the dummy card in the slot, remove it first. Insert the PC card into the slot (usually with its label facing up) and push it until it is firmly seated.
  • Page 82 Removing the PC card Press the Eject Button to make it stretch out. Push the Eject Button ( ) and the PC card will slide out slightly. Then, pull it out of the slot ( ). Do not hold the “golden finger” when installing the PC card;...

  • Page 83: Safely Remove Hardware

    ) will appear on the taskbar. Double-click the icon to bring up the Safely Remove Hardware dialog box. You can see all connected peripheral devices here. If you want to remove any of the devices, move the cursor to the device and then click Stop.

  • Page 84: Upgrading Your System

    6.3 Upgrading your System You can upgrade your Notebook PC through the following ways: adding memory to a maximum of 2GB. replacing the hard disk drive. replacing the CPU. 6 - 9...

  • Page 85: Caring Your Notebook Pc

    Caring Your Notebook PC To ensure a trouble-free operation and reduce the risk when working, you should take good care of your computer. This chapter provides the basic guidelines to protect your computer and critical data. 2 - 1...

  • Page 86: Protecting Your Notebook Pc

    Therefore, we provide the following suggestions to protect your system. Locking Your Computer When you use the computer in the public area, you can secure your computer on the immovable object (such as a desk) by connecting a Kensington- compatible lock.

  • Page 87: Setting Up Password

    Once the boot password is set, it will bring up a dialog box r e q u e s t i n g f o r t h e p a s s w o r d whenever the computer is turned on.

  • Page 88: Using The Anti-Virus Protection

    In one word, the computer virus is a program that replicates; therefore, it will need to attach itself to other program files, such as .exe, .com, .dll files. The virus start to wreak havoc within the computer whenever these executable programs execute.

  • Page 89: Tips For Traveling

    4 hours, you are recommended to prepare a second battery pack or an AC adapter. Store your Notebook PC in a cool and dry place if you can not bring it with you. Long-time exposure to temperature and humidity fluctuation may cause malfunction of the system.

  • Page 90: Taking Care Of Your Computer

    6200 Series Notebook PC 7.3 Taking Care of Your Computer The guidelines provided in this section are the basics to take good care of your computer. Placing and Operating Your Computer The guidelines provided in this section are the basics to take good care of your computer.

  • Page 91: Cleaning Your Computer

    Cleaning Your Computer TURN OFF the computer when you have to clean it. Clean your computer by using a soft, dry cloth ONLY; do not use the alkaline detergent to wipe the exterior of the computer. Do not clean the LCD panel by using the alcohol or detergent. Only use the soft, lint-free cloth to wipe the LCD panel gently.
  • Page 92 However, to optimized the life of your battery pack, we suggest that once a month the power is consumed entirely. If you do not use the Notebook PC for a long time, it is suggested to remove the battery pack from your computer. This may be helpful to extend your battery life.
  • Page 93 The charging time depends on the system mode. When the computer is turned on, it will take a longer time (3~4 hours) to have the battery fully charged. The Power Meter only provides an estimated value of the battery power. The operating time allowed depends on the actual use of your computer.

This manual is also suitable for:

6200 series
