2. USB Device Cover
Underneath the cover, there is a USB connector. This
connector is reserved for future use.
3. Hard Disk Drive Cover
The system's hard disk drive is located under the cover. The
HDD can be upgraded to a larger capacity. (See Chapter 4 for
instructions on upgrading the HDD.)
4. System Device Cover
The system's processor with cooling assembly, Wireless LAN
module, and DDR memory module are located under the case
cover. The system memory can be upgraded to a larger
capacity. (See Chapter 4 for instructions on upgrading the
memory.)
5. Ventilation Grill
The fan grill is where air is exchanged to dissipate the internal
heat. Do not block this airway.
Warning:
Do not block the Fan Grill outlet. Place the machine on hard
surface only. The bottom case may get very hot without proper ventilation and
air circulation.
21
