Related Manuals for Welch Allyn Solarc M21P011
Summary of Contents for Welch Allyn Solarc M21P011
- Page 1 TECHNICAL OPERATION GUIDE TECHNICAL OPERATION GUIDE Focused Innovation. Focused Innovation. L I G H T I N G P R O D U C T S D I V I S I O N...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ..........................3 S¯ olarc Lamp Overview ......................4 S¯ olarc Lamp Advantages.....................4 S¯ olarc Lamp Operating Characteristics................5 S¯ olarc Lamp Safety, Handling and Disposal ..............5 Lamp Life & Maintenance ....................6 Designing S¯ olarc Lamps into Your Products..............7 Lamp Temperature & Cooling .....................9 Optical Performance Optimization ...................10... -
Page 3: Introduction
For more detailed information on specific With Welch Allyn’s S ¯ olarc lamps, that’s precisely S ¯ olarc lamp solutions, please contact your Welch Allyn what they get. S ¯ olarc lamps, Light Engines and Light representative. -
Page 4: S¯ Olarc Lamp Overview
High-efficiency operation—combined with its lower gas Brilliant Illumination volume and miniature size—mean that S ¯ olarc lamps Thanks to Welch Allyn’s patented design, the S ¯ olarc provide solar-quality light output, yet require 1/3 less miniature arc lamp provides pure, white illumination power than halogen lamps. -
Page 5: S¯ Olarc Lamp Operating Characteristics
S¯ olarc LAMP OPERATING CHARACTERISTICS Appearance Output Ratings S ¯ olarc lamps contain small amounts of metals. These metals are in both liquid and solid forms when the lamp is cold. The industry standard for measuring output of light is the When cold, these metals may appear to be dark reddish lumen. -
Page 6: Lamp Life & Maintenance
Welch Allyn defines a Possible skin or eye irritation can result from exposure to rated “median life”... -
Page 7: Designing S¯ Olarc Lamps Into Your Products
This is how all devices manufactured System Integration Guidelines to Minimize EMI by Welch Allyn are designed. If the system cannot be Ballasts and other power conversion circuitry emit parasitic cooled using forced-air cooling, such as in a flashlight or... - Page 8 This is usually not a cause for concern. Input Wiring for Printed Circuit Board (PC) Version Ballast Welch Allyn recommends complying with IPC-A610D solder process standard or equivalent. Construct an input power connector assembly compatible with the input connector (Molex 41791 connector 2-pin series or equivalent) located on the ballast circuit board assembly.
-
Page 9: Lamp Temperature & Cooling
Welch Allyn arc lamps are designed for direct current The most important measurement of a proper S ¯ olarc lamp (DC) operation. It is vital that the lamp be installed and and ballast installation is the temperature on the ballast maintained with the correct polarity. -
Page 10: Optical Performance Optimization
To help you design sink (largest heat sink on PC board) located adjacent to the S ¯ olarc lamp into your equipment, Welch Allyn can the input power connections must be maintained below provide specially prepared lamps with Type K thermocouples 90˚C. -
Page 11: Lamp Replacement Instructions (Le, Lm, Lb Models)
Only qualified personnel should make electrical inspections 2. Rotate lamp spring retainer from lamp spring and repair Welch Allyn S ¯ olarc light engines, light modules 3. Disconnect the lamp connector and remove the lamp by pulling and light boxes. - Page 12 Figure 4: Ballast / Arc Lamp Configuration All measurements are mm [in.] Figure 5: Ballast / Arc Lamp Configuration All measurements are mm [in.]...
- Page 13 Figure 6: Parabolic Reflectorized Lamps Typical Performance Specifications LAMP P/N M21P011 M21P021 Output Performance Output (CBCP) 14,500 5,000 Beam Divergence (@ 50% Intensity) Application Information Color Temperature (˚K) 6,000 6,000 Chromaticity (x,y) 0.32, 0.32 0.32, 0.32 Median Life (Hours) Warm-up Time To 90% Output (Seconds) Restart Time To 90% Output (Seconds) Ballast B22R001...
- Page 14 Figure 8: S¯ olarc ® MR11 Elliptical Lamp Typical Performance Specifications Wattage 19 Watts 22 Watts 25 Watts Performance @ Rated Power: Luminous Flux Lumens Through a 4 mm Aperture Lumens Through a 2 mm Aperture Correlated Color Temperature (˚K) 6,900 6,200 5,200...
- Page 15 Figure 12: Spectral Output at Zero Hours Figure 13: Spectral Output at 650 Hours Spectral Distribution The plots above provide an indication of the degree of relative energy changes within the spectral distribution as the lamp ages. The curves describe the performance of a typical 21 W lamp in its reflector, operated at rated wattage and standard duty cycle.
- Page 16 Precision Arc & Halogen Lamps 4619 Jordan Road Skaneateles Falls, NY 13153-0187 Phone: 315.685.4347 Fax: 315.685.2854 Please Note: Continuous product improvement requires we reserve the right to change these specifications without notice. www.walamp.com © 2006 Welch Allyn MC3693 Rev B Printed in U.S.A.
- Page 17 Precision Arc & Halogen Lamps 4619 Jordan Road Skaneateles Falls, NY 13153-0187 Phone: 315.685.4347 Fax: 315.685.2854 Please Note: Continuous product improvement requires we reserve the right to change these specifications without notice. www.walamp.com © 2006 Welch Allyn MC3693 Rev B Printed in U.S.A.
