- Page 1 User Manual Version 1.0 2021/01 OF-215P-A1 Touch LCD Monitor...
- Page 2 MicroTouch a TES Company. The information in this document is subject to change without notice. MicroTouch TES Company makes no representations or warranties with respect to the contents herein, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose.
- Page 3 Compliance Information For FCC (USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 4 Renseignements relatifs à la conformité Pour la FCC (États-Unis). Ce matériel a fait l’objet d’essais qui ont déterminé qu’il respectait les limites d’un appareil de classe B selon la partie 15 des règlements de la FCC. Ces limites sont établies pour assurer une protection raisonnable contre les parasites nuisant à...
- Page 5 Usage Notice Warning - To prevent the risk of fire or shock hazards, and do not expose the product to moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Warning - Power cord shall be connected to a socket-outlet with earthing connection.
- Page 6 Avis d’utilisation Mise en garde — Pour prévenir les risques d’incendie ou d’électrocution, ne pas exposer le produit à l’humidité. Mise en garde — Prière de ne pas ouvrir ou démonter le produit, car cela pourrait entraîner l’électrocution. Mise en garde – Le cordon d’alimentation doit être branché à une prise pourvue d’une mise à...
-
Page 7: Table Of Contents
Table of Contents Chapter 1 ........................7 1.1 Overview ........................8 1.2 Feature ........................8 1.3 Specifications......................8 1.4 Block Diagram ......................10 1.5 Interface Connectors ..................... 11 1.5.1 Power Connector ..................... 11 1.5.2 Video Signal Connector ................... 11 1.6 Package Overview ....................13 Chapter 2 ........................ -
Page 8: Chapter 1
Chapter 1 Product Introduction... -
Page 9: Overview
1.1 Overview The OF-215P-A1 series is developed for finance industry or hospitality. The OF-215P-A1 is a 21.5 inches touch display which uses the last touch technology. 1.2 Feature ▪ Support 75mm and 100mm VESA mount ▪ 1920 x 1080 resolution ▪... - Page 10 Digitizer Technology Electro-magnetic Resonance Active Area 478.84 x 270.31mm ± 2mm Center Area Coordinate Accuracy ± 4mm Edge Area Detectable Height 7mm above the Sensor Film Center Area (Note 2) Encrypt Module Working Frequency(max) 96MHz UART： Baud Rate：38400bps ~ 115200bps(Max) Encrypt Interface Or I2C：...
-
Page 11: Block Diagram
1.4 Block Diagram... -
Page 12: Interface Connectors
1.5 Interface Connectors 1.5.1 Power Connector The DC input power via 2.0mm DC jack. All DC power cables must be latching. 1.5.2 Video Signal Connector The video signal input via D-type 15-pin female connector. Connector Pin Assignment: Signal Red video signal input Green video signal input Blue video signal input DDC ground for the VESA DDC2B function... - Page 13 HDMI (1.3a) Signal Signal TMDS Data2+ TMDS Clock Shield TMDS Data2 Shield TMDS Clock– TMDS Data2– TMDS Data1+ Reserved (N.C. on device) TMDS Data1 Shield TMDS Data1– TMDS Data0+ DDC/CEC Ground TMDS Data0 Shield +5V Power TMDS Data0– Hot Plug Detect TMDS Clock+ USB 2.0 Signal...
-
Page 14: Package Overview
12Vdc, 3A minimum, Tma = 40 degree C minimum, and the altitude of operation = 3048m minimum. If it needs further assistance with purchasing the power source, please contact to MicroTouch for further information. Mise en garde! Cet appareil est destiné à être alimenté par un adaptateur secteur homologué ou une source d'alimentation CC, d’une tension nominale de 12Vdc, 3A minimum,... -
Page 15: Chapter 2
Chapter 2 Product Installation... -
Page 16: About Vesa Mount
2.1 About VESA Mount “VESA Flat Display Mounting Interface The OF-215P-A1 series conform to the Standard” which defines a physical mounting interface for touch monitor, and corresponding with the standards of touch monitor mounting devices. The VESA mount is located on the back of this unit. - Page 17 Mise en garde! Sélectionner les vis d’origine de TES! La distance entre la surface du couvercle arrière et le bas de l’orifice de la vis est de 8 mm. Utiliser les vis quatre M4 de diamètre avec la longueur appropriée pour monter votre moniteur. Remarque : Le support de montage doit pouvoir supporter un poids d’au moins 17.6 lb (8 Kg).
-
Page 18: About Wall Mount
2.2 About Wall Mount The OF-215P-A1 series support wall mount, and this monitor can be mounted to the wooden or concrete wall with 8 screws and four brackets on the opposites. 2.2.1 Attaching the side Brackets Depending on your mounting scheme, alternately, you may use the side brackets to mount your displays onto your wall or device. -
Page 19: Customer Panel Material
2.2.2 Customer panel material Wooden wall: Ø4.5mm thru holes for M4 screws w/nuts, or no thru holes, screws for wood4mm. Sheet metal: concealed head threaded studs M4 w/nuts. Warming! This apparatus is intended to be supported by a Listed Wall Mount Bracket” or the equivalent. -
Page 20: On-Screen Display
2.3 On-Screen Display Menu off status Menu on status Fine-tune the image to full screen AUTO Auto automatically. MENU Menu appear Menu disappear/ return to main item Left CONTRAST select down/ Adjust down Right BRIGHTNESS select up/ Adjust up Exit OSD / return to main item SELECT POWER... -
Page 21: Osd Function Description
2.3.1 OSD Function Description ITEM CONTENT Default Contrast The monitor luminance level control. Brightness The monitor backlight level control. LIGHTSENSOR Auto dim function control. Moving screen image horizontal position to left H-Positon or right. Moving screen image vertical position to up or V-Positon down. -
Page 22: Timing Table Chart
2.3.2 Timing Table Chart Polarity Band Width Mode Resolution H-Freq. (KHz) (MHz) － ＋ 720x400 70Hz 31.47 28.322 － － 640x480 60Hz 31.47 25.175 － － 640x480 66Hz 30.24 － － 640x480 72Hz 37.86 31.5 － － 640X480 75Hz 37.5 31.5 ＋... -
Page 23: Dimension
2.4 Dimension 2.4.1 Front View 2.4.2 Side View... -
Page 24: Rear View
2.4.3 Rear View... -
Page 25: Appendix
Appendix... - Page 26 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：觸控螢幕 型號（型式）：OF-215P-A1 Type designation (Type) ：OF-215P-A1 Equipment name：Touch LCD Monitor 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 Unit 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Cadmium Hexavalent Polybrominated Polybrominated Lead...
