Overview of clamp position offset parameter

The clamp position offset data is sorted into a 4-column table.
• Column 1 contains the unambiguous identifier of the axis parameter called the "ID" which consists of
the prefix "P-CLMP" and a unique 5-digit number,
e.g. P-CLMP-00001.
• Column 2 represents the data structure which defines the parameter,
e.g. pzv_grp[i].achse[j].
The structure is a categorisation aid and is described in the following section.
• Column 3 contains the "parameter" with its exact description,
e.g. offset.
The important thing is that "structure"+"parameter" always belong together and must therefore be
configured in exactly the same way in the axis parameter list,
e.g. pzv_grp[i].achse[j].versatz
• Column 4 contains the "functionality" in a summarised term/short description,
e.g. Axis-specific clamp position offset.
ID
P-CLMP-00001 [} 10]
TF5200 | TwinCAT 3 CNC
Clamp position offsets
Structure
pzv_grp[i].achse[j].
Version: 1.13
Overview of clamp position offset parameter
Parameter Functionality/short
description
offset Axis-specific clamp position
offset
