Audiovox Pursuit PRO-OE3 Programming Manual

TRANSMITTER PROGRAMMING GUIDE
The transmitters included with the security system have been
pre-programmed at the factory, with each button pre-assigned to control a
specific function of the security system. Although the security system in the
vehicle has either a 3 or 4 channel receiver, depending on the model, the
transmitters included with the system are capable of transmitting 7 distinct
signals. This allows you to program each transmitter to more than one vehicle
in two car families, and also allows you to change which button(s) control
certain functions of the system.
( Example: Transmitter channel 5 can be programmed to activate Receiver
channel 2.) Refer to the chart below for access to each of the transmitter
channels, and for the standard factory button assignments.
TRANSMITTER
CHANNEL BUTTONS CHANNEL
1 ARM 1
DISARM
2 OPTION 1 2
3 OPTION 2 3
ARM 4
DISARM
4 &
OPTION 1
OPTION 1
5 &
OPTION 2
ARM
DISARM
6 &
OPTION 2
7 ALL 3
BUTTONS
Model : PRO-OE3
SYSTEM RECEIVER
FUNCTION
**Remote Arm & Disarm
**Remote Emergency Panic
Remote Door Lock & Unlock
* Pulsed Output for Accessories
* Switched Output for Accessories
* Switched Output for Accessories
