The transmitters included with the security system have been pre-programmed at the
factory, with each button pre-assigned to control a specific function of the security
system. Although the security system in the vehicle has either a 3 or 4 channel
receiver, depending on the model, the transmitters included with the system are
capable of transmitting 7 distinct signals. This allows you to program each transmitter
to more than one vehicle in two car families, and also allows you to change which
button(s) control certain functions of the system.
(Example: Transmitter channel 5 can be programmed to activate Receiver channel
2.) Refer to the chart below for access to each of the transmitter channels, and for the
standard factory button assignments.
TRANSMITTER
CHANNEL
BUTTON
CHANNEL
1
1
2
2
3
3
4
&
4
5
&
5
6
&
6
All 3
7
7
Buttons
Some of the more common accessories for these additional channels are;
AS 9554
AS 9075
AS 9153
AS 9256
TRANSMITTER PROGRAMMING GUIDE
Model : PRO-OE3C
SYSTEM RECEIVER
FUNCTION
Remote Arm
Remote Emergency Panic
Remote Door Lock
Remote Disarm
Remote Emergency Panic
Remote Door Unlock/Unlock 2
Single Push Pulsed Output for Optional Accessory
Or Double Push For Additional Optional Accessory
Single Push Pulsed Output for Optional Accessory
Or Push And Hold For Extended Output
Single Push Pulsed Output for Optional Accessory
Or Push And Hold For Extended Output
RF Channel For Options
RF Channel For Options
Remote Garage Door Interface
Remote car starter
Remote window roll up
Remote trunk release relay
