Summary of Contents for Autoglide MAGRO-35A
- Page 1 INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 1...
- Page 2 INDEX 1. Features 2. Technical Specifications 3. Mechanical Installation 4. Manual Release 5. Wiring 6. LED Diagram 7. Wiring For Optional Accessories 8. Remote Control Setting 9. Battery Wiring Instructions Flashing Light Installation INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 2...
-
Page 3: Technical Specifications
Optional Device: DC 24V gate lock, photocell, extensional receiver box Technical Specifications Electrical Operating voltage DC 24V Electronic Controller Microcontroller Based Safety Detection Over current detection Safety Barrier Infrared Beam Sensor(Optional) IP Rating IP66 INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 3... -
Page 4: Mechanical Installation
Driving Method Screw driven piston type Opening degree 0 to 110 degree 90 degree rotation time 8 to 12 seconds Temperature -25 degree C to + 55 degree C 3. Mechanical Installation INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 4... - Page 5 Diagram Installation Opener Dimension INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 5...
-
Page 6: Bracket Dimension
2. Make sure the position extend have at least 5 mm allowance when the gate in Opened / Closed position. 3. There are two small holes in the swing arm motor,please make sure this side face down when do installation for water proof purpose. INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 6... -
Page 7: Manual Release
3. Now the manual release function is enabled when maintaining or no power. 4. After maintaining, rotate 90 degree back to the locked position, then use special key to lock the moving part. www.autoglideglobal.com INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 7... -
Page 8: Control Box Setting
LED 2 Motor A close LED. LED 3 Motor B open LED. LED 4 Motor B close LED. LED 5 Power LED. LED 6 Received signall for remote control LED. LED 7 Pushbutton LED INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 8... - Page 9 (single gate) Extensional Receiver Box (dual gate) Keypad (single open ) Keypad (dual open ) Push button (two buttons) close gate only Push button (one button) single open dual open Photocell (sender) Photocell (receiver) INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 9...
-
Page 10: Remote Control Setting
Press and hold the “Enter” button until the display stops flashing “FF” this indicates all remotes have been erased and are invalid. **pedestrian opening push “p” button to perform single swing opening (Note: only valid for double swing systems) INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 10... - Page 11 (A6, B6) by 10 and then repeat the self- learning process. If the speed is not slowing down at the ends of the cycle, decrease A6 and B6 by about 5 and then repeat the self learning process INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 11...
-
Page 12: Function Adjustment
Low speed operating time during gate to Open/Close the gate opening. for the Slow Speed part Time of closing - slow speed. of the sequence. A4/B4 0~9.9s Low speed operating time during gate closing. INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 12... - Page 13 If you choose "2", motor B will delay open during opening, motor A will delay start during closing. If you choose "3", motor B and motor A will start working at the same time. INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 13...
- Page 14 2. Default settings can be reset directly from the power control box. 3. Please note that the gates open and close in the following manner: slow start, fast swing and slow finish . To adjust each of these speeds, refer to the chart above. INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 14...
- Page 15 *Recommend to use 2pcs of 12v 9Ah battery connection in series Flashing light installation Proprietary Intellectual Property. Do not Distribute without authorization. All Rights Reserved-Copyright@2015 Autoglide www.autoglideglobal.com INSTRUCTIONS MAGRO-35A SWING GATE OPENER Page 15...
