Page 1: Table Of Contents
Intelligent Remote Control Swing Door Opener Instruction Manual Model – Fero 600-M Contents Pages . Summary . Structures & Classification . Main Technical Parameters . Function Characteristics . Operating Methods . Installation Method & Debugging . Maintenance and services . Trouble shooting . -
Page 2: Summary
. Summary Dear user: Thank you for selecting of our intelligent remote control swing gate opener! Please carefully read this Instruction Manual before installation and use.If you have any problem that you can’t settle during use, please contact your local distributor of our products. . -
Page 3: Main Technical Parameters
Ⅲ . Main Technical parameters Ⅳ. Function Characteristics 1. Single-leaf or double-leaf opening: This function can be activated by pressing button. 2. Control box locking: To avoid unauthorized opening, this function can be activated by remote control. 3. Automatic detection and protection: The gate opener will automatically stop if any obstruction is detected during opening;... -
Page 4: Installation Method & Debugging
3. The gate access control system can identify and control access automatically. (II) Manual control operation 1. Manual opening: insert the clutch key into the lock hole and rotate it clockwise to disengage the clutch (the gate opener in manual mode), then push the gate open by hand. 2. - Page 5 3. Determination power of the gate op Determination power of the gate opener Measure the width, height, weight of the gate leaf and determine if Measure the width, height, weight of the gate leaf and determine if ordinary or high ordinary or high-duty motor shall be chose according to the sealing conditions and external environments (e.g.
- Page 6 Fig.5 Holes on both inner sides of the gate on the bottom frame Fig.5 Holes on both inner sides of the gate on the bottom frame Fig.5 Holes on both inner sides of the gate on the bottom frame 4. Fix the gate opener and connect the and connect the wires (whose color shall be the same as label of whose color shall be the same as label of terminal block of the control box or the color of the plug wire).
- Page 7 Manually open and close the gate to check if the stop irons are properly installed. a.Push the gate towards the stop iron when the gate is in manual mode, then use the key to switch it to electrical mode. Push the gate forward and the gate shall be reliably locked. b.Use the key to switch the gate opener back to manual mode and the gate can be easily pushed open.
-
Page 8: Maintenance And Services
a) Apply a counterforce (push or pull with hands) on one leaf during opening and the gate shall stop opening. b) Apply a counterforce on one leaf during closing and both leaves shall retreat in the opening direction. If the motor’s capacity against resistance is set to be too small the motor may easily stop operation. -
Page 9: Control Board
Installation: Wall-mounted or desktop Frequency: 433.92MHZ learning encrypted rolling code type FERO 600-M Control Board FERO 600 control board is specially designed according to 24V DC door opener, improved through D33. With soft start and soft stop low speed function, encrypted remote control ,higher confidentiality .This system can also optionally available with a back-up battery. - Page 10 under correct procedure, the circuit board do not need maintenance normally. Install the control under correct procedure, the circuit board do not need maintenance normally. Install the control under correct procedure, the circuit board do not need maintenance normally. Install the control panel as close as possible to the place w panel as close as possible to the place where the door motor is connected with minimum diameter here the door motor is connected with minimum diameter...
- Page 11 Red DIP switch 3 = Auto close function Red DIP switch 3 = Auto close function Turn on RED DIP switch 3 to OFF, without auto function. , without auto function. Turn on RED DIP switch 3 to ON with auto close function. with auto close function.
- Page 12 First mode: auto set low speed opening and closing time eed opening and closing time After completely install and adjust the motor,(when setting the door should be on the close After completely install and adjust the motor,(when setting the door should be on the close After completely install and adjust the motor,(when setting the door should be on the close position, this is very important),turn on red DIP switch 8 and 4 to ON, this is very important),turn on red DIP switch 8 and 4 to ON, and press open button of the...
- Page 13 Strength adjustment 2: (Torque 2) (Torque 2) Motor 1 running strength adjustment: the running strength can be adjusted by TORQUE 1, Motor 1 running strength adjustment: the running strength can be adjusted by TORQUE 1, Motor 1 running strength adjustment: the running strength can be adjusted by TORQUE 1, motor will stop when meet big resistance, in case clip pers motor will stop when meet big resistance, in case clip person or object.
- Page 14 during opening, motor will close and reverse 1 second, electric lock get electric and start action 2 seconds, motor start opening. Electric lock will hold electric 3 seconds and release when the motor start opening. 5. Ground sensor or infrared auto close interface: After the car (recommend to add ground sensor) or person (recommend to add Infrared) passing, motor automatically close, using this interface.
- Page 15 5. Non-professional personal is forbidden to install the controller and circuit. We are out of responsibility for any personal safeties caused. 6. If the controller has any quality problem, please send it to agent. If repaired by self, we are out of responsibility for any loss caused by self-repair.
