  • Page 1 INSTRUCTIONS VELOSE-80A SLIDING GATE OPENER Page 1...
  • Page 2 INDEX 1. Features 2. Technical Specifications 3. Mechanical Installation 4. Manual Release 5. Confirm Direction of Travel 6. Mounting the Sensor Magnets 7. Wiring 8. LED Diagram 9. Wiring For Optional Accessories 10. Remote Control Setting 11. Motor Setting 12. Flashing Light Installation 13.

  • Page 3: Technical Specifications

    Features Manufacturer has patent for manual release mechanism. use this feature in case of Power failure, during installation or maintenance Easy Self-learning feature (Page 9) Commercial power & solar energy power source can be connected at the same time Over current immediate stop function (A0~ A1/B0~B1) Adjustable time of fast speed &...
  • Page 4 Mechanical Model VELOCE 80A Max Gate weight 800Kg Motor speed 1800rpm Gate moving speed 13m/min Gate Limit type Magnetic Limit Switch Operating Distance > 50m Frequency : 433.92 MHZ Remote Control Mode Close/open/Stop/Pedestrain Open Auto Close Time 0~ 99 sec (Adjustable) Noise <...
  • Page 5 Gear & Rack Installation Mounting plate/ Base Dimension Installation Diagram INSTRUCTIONS VELOSE-80A SLIDING GATE OPENER Page 5...
  • Page 6 Motor & Rack Installation 1. Reserve a place for the mounting plate 2. Arrange all necessary electric wire in advance 3. Fix the bolt onto the mounting plate, make the threaded portion 25-35 mm higher than the plate, lock up the plate with nuts 4.

  • Page 7: Manual Release

    6. Turn the slider motor to electric mode. 4. Manual Release Place the key in key slot and position at 12 0’ clock, this will allow the allen key supplied to fit into the hole, rotate handle 90 degree anti clockwise, The gear can now be rotated manually.
  • Page 8 Change motor direction: PCB before 2013 reverse the red+ and black – terminals on the motor Pc board. PCB after 2013 ref to adjustment setting B3 Make sure power is switched off before doing this step. 6. Mounting the sensor Magnets(Magnetic Limit Switch) Gate opens and closes when the magnets pass the motor sensor With the gate motor in manual release: Ref to manual release section.

  • Page 9: Control Box Setting

    Control Box Setting 1. Wiring Power Switch. Accessories and command device’s terminals. Indicator. DC 24v Motor Function Adjustment Button. DC Light(Optional). Buzzer. Output DC 24 (Unstable Voltage). OV “-“ output. Output DC 15V stable voltage (load current can’t be over 500 MA) Backup Battery (12 v 9 ah x 2 in series).
  • Page 10 2. Wiring for Optional Accessories Item +15V OP/CS SENSOR STOP CLOSE SENSOR Remarks Open/ Stable "-" & Normally "-" & stop/ Back-up Close Open voltage opening "Concentration "Concentration Limit Limit Description close output line" signal line" Extensional Receiver Box Keypad Push button Photocell (sender)

  • Page 11: Remote Control Setting

    *Instructions for photocell: During closing, if active the signal of photocell, the PCB will activate opening operation when photocell sensed the obstacle, the door will be stopped then opened immediately after remove the obstacles, the door will operate according to the new command 7.
  • Page 12 (Repeat steps if motor does not move) Gate in the fully opened position based on your magnet placement. Holding down the “p” button &”closed” buttons together on the remote until the indicator on the PC board is blinking, Release both buttons. The motor will start moving at low speed then stop once the closed magnet reaches the motor sensor.

  • Page 13: Function Adjustment

    1. Function Adjustment (Follow the steps below) After you done” Total Timer Adjustment”, we recommend not to change the setting for A0~ B0. If you prefer to change, please refer to following steps. Step 1 : press “f” button ,the indicator will show “C8” Step 2 : press “+”...
  • Page 14 Force of opening and closing - high speed. Force adjustment for high speed operating 0~99 during open and close. Deceleration timer/distance setting when 0~99 opening gate When activated (Option Deceleration timer/distance setting when closing 0~99 “1”), the gates can’t be gate pushed open.
  • Page 15 If choose “0”, the gate system will not have auto closing function If choose”10” .it means Time Of Auto Close 0-99 the gates will automatically close 10 seconds after completing its opening If Choose “0”, the gate system will not have auto closing function If choose “10”, it means 0-99...

  • Page 16: Battery Maintenance

    Input Voltage (transformer, battery) less than DC15V Press “stop” button on remote control Motor stop working relate to any optional accessories connecting to terminal “OP/CS” Proprietary Intellectual Property. Do not Distribute without authorization. All Rights Reserved-Copyright@2015 Autoglide www.autoglideglobal.com INSTRUCTIONS VELOSE-80A SLIDING GATE OPENER...
